Imaging Studies

Radiography of the chest is indicated in Merkel cell carcinoma (MCC) to rule out the alternative diagnosis of cutaneous metastasis from a primary small cell neuroendocrine carcinoma (oat cell carcinoma) of the lung.

Staging CT or MRI studies are needed to assess the possibility of dissemination of primary Merkel cell carcinoma to the lymph nodes or the viscera.

Next

Procedures

Fine-needle aspiration may be helpful to assess recurrence or metastatic spread.

Previous
Next

Histologic Findings

Tumors cells are usually located intradermally; an intraepidermal component may also be present, and a purely intraepidermal (in situ) Merkel cell carcinoma rarely may be encountered. Reactive epidermal hyperplasia is frequent.

Several architectural patterns of intradermal tumor are recognized. The classic trabecular pattern consists of interconnecting strands of tumor cells in the dermis, with formation of cellular aggregates resembling glands or neural rosettes.[17] The intermediate pattern is the most common, and it exhibits large, solid nests of neoplastic cells. The least common, diffuse pattern consists of an infiltration of tumor cells among dermal collagen bundles, without the more distinctive organoid appearance of the trabecular pattern. A particular tumor often contains elements of all architectural patterns, with individual variation in the proportions represented.

Histologic appearance of nodular Merkel cell carciHistologic appearance of nodular Merkel cell carcinoma. Dermal nodule with a cohesive, expansile growth of basophilic cells. High-power view demonstrates an open chromatin patHigh-power view demonstrates an open chromatin pattern and a high mitotic index.

The tumor is usually composed of round, small, dark cells with conspicuous nucleoli and open chromatin with peripheral heterochromatin (salt-and-pepper pattern). Less commonly, Merkel cell carcinoma cells may simulate lymphoma, or may exhibit plasmacytoid, clear cell, anaplastic, or spindle-cell features. Mitotic figures and apoptotic bodies are often numerous. Vascular or lymphatic invasion is not uncommon. Histologic variants of Merkel cell carcinoma include the desmoplastic, epidermotropic (resembling mycosis fungoides), and pagetoid (resembling Paget disease[18] or melanoma) types, and tumors with focal true glandular or squamous differentiation.[19, 20, 21] Merkel cell carcinoma has been associated with squamous cell carcinoma, basal cell carcinoma, adnexal tumors, and trichilemmal cyst.

Merkel cell carcinoma with a focus of squamous difMerkel cell carcinoma with a focus of squamous differentiation. Prominent in situ nested component of Merkel cell Prominent in situ nested component of Merkel cell carcinoma, simulating malignant melanoma.

Immunohistochemistry is very helpful. Cytokeratin 20 is expressed in a dotlike paranuclear or crescentic pattern; other low molecular weight (MW) cytokeratin antibodies (eg, CAM5.2, MNF116), while less specific, react in a similar localization pattern. Neurofilament is also expressed in the cytoplasm of most Merkel cell carcinoma. The above findings support the diagnosis of primary Merkel cell carcinoma of the skin and tend to rule out metastatic neuroendocrine carcinoma, as from a pulmonary primary. The CK20 expression is so sensitive and specific that it has largely replaced traditional markers of neuroendocrine differentiation (ie, synaptophysin, chromogranin) as the initial antibody panel of choice; however, the latter may be helpful adjuncts in difficult cases.[22]

Dotlike paranuclear pattern of cytokeratin immunolDotlike paranuclear pattern of cytokeratin immunolocalization.

Electron microscopic findings are characteristic, revealing a lobulated nucleus that may contain rodlets. The cytoplasm is electron-lucent and contains a prominent Golgi apparatus and numerous ribosomes. Intermediate filaments are numerous and often assume a parallel or whorled arrangement near the nucleus, accounting for the dotlike pattern of cytokeratin distribution visualized by immunohistochemistry.[23] Desmosomes may be present. Most diagnostic is the dense core granule (80-120 nm in diameter), the source, and the locus of the neuroendocrine peptides.

Electron micrograph of Merkel cell carcinoma showiElectron micrograph of Merkel cell carcinoma showing a dense core granule (arrow). Electron micrograph of Merkel cell carcinoma showiElectron micrograph of Merkel cell carcinoma showing whorled bundles of intermediate filaments (arrow) near nucleus in Merkel cell carcinoma.

Cytologic preparations from fine-needle aspirates (FNAs) demonstrate a loosely cohesive pattern of small to intermediate-sized cells with round nuclei, finely granular chromatin, a thin rim of cytoplasm, and (infrequently) pseudorosette formation. Immunocytochemistry may be helpful.[24]

Pseudorosette formation in Merkel cell carcinoma. Pseudorosette formation in Merkel cell carcinoma.
Previous
Next

Staging

According to the American Joint Committee on Cancer guidelines, carcinoma of the skin is staged by the status of T (primary tumor), N (lymph node), and M (metastasis). The definitions are as follows:

Table 1. Tumor Status (Open Table in a new window)

TXPrimary tumor cannot be assessed
T0No evidence of primary tumor
TisCarcinoma in situ
T1Tumor 2 cm or less in greatest dimension
T2Tumor >2 cm but not >5 cm in greatest dimension
T3Tumor >5 cm in greatest dimension
T4Tumor invades deep extradermal structures (ie, cartilage, skeletal muscle, bone)

Note: In the case of multiple simultaneous tumors, the tumor with the highest T category is classified and the number of separate tumors is indicated in parentheses, such as T2 (5).

Table 2. Node and Metastasis Status (Open Table in a new window)

NXRegional lymph nodes cannot be assessed
N0No regional lymph node metastasis
N1Regional lymph metastasis
MXDistant metastasis cannot be assessed
M0No distant metastasis
M1Distant metastasis

Table 3. Stage Grouping (Open Table in a new window)

Stage 0TisN0M0
Stage IT1N0M0
Stage IIT2N0M0
(or)T3N0M0
Stage IIIT4N0M0
(or)Any TN1M0
Stage IVAny TAny NM1

Sentinel lymph nodes may be examined by breadloafing and subsequent analysis of keratin expression with an antikeratin cocktail. Because dendritic cells in the lymph nodes may express keratin, in case of doubt anti-CK20 antibodies may be useful to rule out metastatic Merkel cell carcinoma. A recent analysis on a large number of patients indicates that, as in other solid tumors, positive sentinel lymph nodes correlate with impaired prognosis.[25]

Previous
Proceed to Treatment & Management
