Low-Grade Astrocytoma Workup
- Author: George I Jallo, MD; Chief Editor: Tarakad S Ramachandran, MBBS, MBA, MPH, FAAN, FACP, FAHA, FRCP, FRCPC, FRS, LRCP, MRCP, MRCS more...
No specific laboratory test is available for the diagnosis or follow-up of low-grade gliomas. There are promising studies which aim to detect circulating tumor DNA in human malignancies. Although this technology hasn't been applied to low-grade gliomas it could potentially be implemented in the future as a screening, diagnostic or follow-up tool.
Both CT scan and MRI can aid in the diagnosis of low-grade glioma. Generally, MRI is considered the study of choice. However, in an emergency setting a noncontrast CT scan may be ordered first.
Patients with new-onset headache, seizure, weakness, or numbness frequently undergo a CT scan first. Typical CT findings of a low-grade glioma show lower attenuation than the surrounding brain (see image below). A mild mass effect may be noted. Obstructive hydrocephalus can be confirmed. Low-grade gliomas also may show evidence of calcification (more common in oligodendroglial tumors). Low-grade astrocytomas are usually non-enhancing lesions, although the presence of contrast enhancement doesn´t preclude their diagnosis.
PET and SPECT
Positron emission tomography (PET) and single-photon emission computed tomography (SPECT) imaging sometimes are used to try to differentiate low-grade gliomas from either high-grade tumors or other types of pathology. Typically, low-grade gliomas show hypometabolism via PET or SPECT while high-grade gliomas are hypermetabolic. This information may be useful in guiding further therapy.
Magnetic resonance imaging
On MRI, low-grade astrocytomas show decreased signal relative to surrounding brain on T1 sequences (see following images).
On T2 sequences, higher signal reflects both the tumor and surrounding edema (see following images). Pilocytic astrocytomas often are associated with a cyst, which may be particularly prominent on T2-weighted sequences.
MRI of the spinal cord is also the study of choice if an intramedullary low-grade astrocytoma is suspected. On MRI, widening of the spinal cord and frequently an associated cyst are noted. The tumor may show a variable degree of enhancement.
Functional magnetic resonance imaging (fMRI) can provide information about the relationship and localization of a low-grade glioma and eloquent structures such as speech centers and motor pathways. This may help in planning the operation. Recently, the use of digital tractography has allowed to pre-operatively assess the relationship of tumors to important white matter tracts (e.g. descending corticospinal tract) prior to resection.
Electroencephalography (EEG) may be performed on a patient with new-onset seizures; however, no EEG findings are specific to low-grade glioma. However, generalized, diffuse slowing and/or epileptogenic spikes can be seen over the area of the tumor.
Lumbar puncture is generally contraindicated in patients with elevated intracranial pressure, which may occur in the setting of a brain tumor. Cerebrospinal fluid (CSF) studies do not aid in the diagnosis of low-grade astrocytomas.
The histologic findings in low-grade astrocytomas vary according to the specific tumor type. As reviewed before, the absence of high-grade lesion characteristics like necrosis, microvascular proliferation and high mitotic indices are common to the group as a whole.
Pilocytic astrocytomas show the presence of bipolar piloid cells with long hair-like processes and Rosenthal fibers. Pilomyxoid astrocytomas are dominated by the presence of a mucoid matrix, monomorphous bipolar cells and an angiocentric cell arrangement. Pleomorphic xanthoastrocytomas have a variable histological appearance, hence the name. The term xanthoastrocytoma is derived from the presence of xanthomatous cells which show intracellular accumulation of lipids. Diffuse astrocytomas are composed of well differentiated fibrillary or gemistocytic neoplastic astrocytes on the background of a loosely structured microcystic tumour matrix.
There are currently no valid staging systems in clinical use.
P. Kleihues, D.N. Louis, O.D. Wiestler, P.C. Burger, B.W. Scheithauer. WHO grading of tumours of the central nervous system. David N. Louis, Hiroko Ohgaki, Otmar D. Wiestler, Webster K. Cavenee. WHO Classification of Tumours of the Central Nervous System. 4th. International Agency for Research on Cancer (IARC); 2007. 10.
Quinn T. Ostrom, Haley Gittleman, Paul Farah, Annie Ondracek, Yanwen Chen, Yingli Wolinsky, et al. CBTRUS Statistical Report: Primary Brain and Central Nervous System Tumors Diagnosed in the United States in 2006-2010. Neuro-Oncology. November/2013. 15:ii1-ii56. [Medline].
Emanuele Crocetti, Annalisa Trama, Charles Stiller, Adele Caldarella, Riccardo Soffietti, Jana Jaal, et al. Epidemiology of glial and non-glial brain tumours in Europe. European Journal of Cancer. 2012. 48:1532-1542. [Medline].
Julius Griauzde, Ahmad Khaldi, Edward Melian, Ricarchito Manera, Margaret Primeau, Darrin M. Aase, et al. Pilocytic Astrocytojma: A Comprehensive Review. Contemporary Neurosurgery. June 30, 2011. 33:1-6.
Fleury A, Menegoz F, Grosclaude P, et al. Descriptive epidemiology of cerebral gliomas in France. Cancer. 1997 Mar 15. 79(6):1195-202. [Medline].
Nader Pouratian, Ahok Asthagiri, Jay Jagannathan, Mark E Shaffrey, David Schiff. Surgery Insight: the role of surgery in the management of low-grade gliomas. Nature Clinical Practice. Neurology. November/2007. 3:628-639. [Medline].
Hiroko Ohgaki, Paul Kleihues. Epidemiology and etiology of gliomas. Acta Neuropathologica. 2005. 109:93-108. [Medline].
C. Bettegowda, M. Sausen, R. J. Leary, I. Kinde, Y. Wang, N. Agrawal, et al. Detection of Circulating Tumor DNA in Early- and Late-Stage Human Malignancies. Science Translational Medicine. February/2014. 6:1-11. [Medline].
Ajlan A, Recht L. Supratentorial low-grade diffuse astrocytoma: medical management. Semin Oncol. 2014 Aug. 41(4):446-57. [Medline].
Lunsford LD, Somaza S, Kondziolka D, Flickinger JC. Survival after stereotactic biopsy and irradiation of cerebral nonanaplastic, nonpilocytic astrocytoma. J Neurosurg. 1995 Apr. 82(4):523-9. [Medline].
Recht LD, Bernstein M. Low-grade gliomas. Neurol Clin. 1995 Nov. 13(4):847-59. [Medline].
Pedersen CL, Romner B. Current treatment of low grade astrocytoma: a review. Clin Neurol Neurosurg. 2013 Jan. 115(1):1-8. [Medline].
Sanai N, Snyder LA, Honea NJ, Coons SW, Eschbacher JM, Smith KA, et al. Intraoperative confocal microscopy in the visualization of 5-aminolevulinic acid fluorescence in low-grade gliomas. J Neurosurg. 2011 Oct. 115(4):740-8. [Medline].
Christian Senft, Andrea Bink, Kea Franz, Harmut Vatter, Thomas Gasser, Volker Seifert. Intraoperative MRI guidance and extent of resection in glioma surgery: a randomised, controlled trial. Lancet Oncology. 2011. 12:997-1003. [Medline].
Chang EF, Clark A, Smith JS, Polley MY, Chang SM, Barbaro NM. Functional mapping-guided resection of low-grade gliomas in eloquent areas of the brain: improvement of long-term survival. Clinical article. J Neurosurg. 2011 Mar. 114(3):566-73. [Medline].
Sanai N, Mirzadeh Z, Berger MS. Functional outcome after language mapping for glioma resection. N Engl J Med. 2008 Jan 3. 358(1):18-27. [Medline].
Chang EF, Clark A, Jensen RL, Bernstein M, Guha A, Carrabba G, et al. Multiinstitutional validation of the University of California at San Francisco Low-Grade Glioma Prognostic Scoring System. Clinical article. J Neurosurg. 2009 Aug. 111(2):203-10. [Medline].
Kim YH, Nobusawa S, Mittelbronn M, Paulus W, Brokinkel B, Keyvani K. Molecular classification of low-grade diffuse gliomas. Am J Pathol. 2010 Dec. 177(6):2708-14. [Medline].
Alvord EC, Lofton S. Gliomas of the optic nerve or chiasm. Outcome by patients' age, tumor site, and treatment. J Neurosurg. 1988 Jan. 68(1):85-98. [Medline].
Clark GB, Henry JM, McKeever PE. Cerebral pilocytic astrocytoma. Cancer. 1985 Sep 1. 56(5):1128-33. [Medline].
Constantini S, Houten J, Miller DC, et al. Intramedullary spinal cord tumors in children under the age of 3 years. J Neurosurg. 1996 Dec. 85(6):1036-43. [Medline].
Duffau H, Lopes M, Arthuis F, Bitar A, Sichez JP, Van Effenterre R. Contribution of intraoperative electrical stimulations in surgery of low grade gliomas: a comparative study between two series without (1985-96) and with (1996-2003) functional mapping in the same institution. J Neurol Neurosurg Psychiatry. 2005 Jun. 76(6):845-51. [Medline].
Franzini A, Leocata F, Cajola L, Servello D, Allegranza A, Broggi G. Low-grade glial tumors in basal ganglia and thalamus: natural history and biological reappraisal. Neurosurgery. 1994 Nov. 35(5):817-20; discussion 820-1. [Medline].
Hakyemez B, Erdogan C, Ercan I, et al. High-grade and low-grade gliomas: differentiation by using perfusion MR imaging. Clin Radiol. 2005 Apr. 60(4):493-502. [Medline].
Komotar RJ, Mocco J, Carson BS, et al. Pilomyxoid astrocytoma: a review. MedGenMed. 2004. 6(4):42. [Medline].
Laws ER, Taylor WF, Clifton MB, Okazaki H. Neurosurgical management of low-grade astrocytoma of the cerebral hemispheres. J Neurosurg. 1984 Oct. 61(4):665-73. [Medline].
Lote K, Egeland T, Hager B, et al. Survival, prognostic factors, and therapeutic efficacy in low-grade glioma: a retrospective study in 379 patients. J Clin Oncol. 1997 Sep. 15(9):3129-40. [Medline].
Macdonald DR. Low-grade gliomas, mixed gliomas, and oligodendrogliomas. Semin Oncol. 1994 Apr. 21(2):236-48. [Medline].
McCormack BM, Miller DC, Budzilovich GN, et al. Treatment and survival of low-grade astrocytoma in adults--1977-1988. Neurosurgery. 1992 Oct. 31(4):636-42; discussion 642. [Medline].
McCormick PC, Stein BM. Spinal cord tumors in adults. Neurological Surgery. 1996. 4:3102-122.
Morantz R A. Low-grade astrocytomas. Kaye AH, Laws ER Jr, eds. Brain Tumors: An Encyclopedic Approach. New York: Churchill Livingstone; 1995. 433-48.
Salcman M. Radical surgery for low-grade glioma. Clin Neurosurg. 1990. 36:353-66. [Medline].
Teixidor P, Gatignol P, Leroy M, Masuet-Aumatell C, Capelle L, Duffau H. Assessment of verbal working memory before and after surgery for low-grade glioma. J Neurooncol. 2007 Feb. 81(3):305-13. [Medline].
Vandenberg SR, Sampaio Lopes MB. Classification. Berger MS, Wilson CB, eds. The Gliomas. Philadelphia: WB Saunders; 1999. 172-91.
