Low-Grade Astrocytoma Workup

  • Author: George I Jallo, MD; Chief Editor: Tarakad S Ramachandran, MBBS, MBA, MPH, FAAN, FACP, FAHA, FRCP, FRCPC, FRS, LRCP, MRCP, MRCS  more...

Updated: Oct 27, 2014


Laboratory Studies

No specific laboratory test is available for the diagnosis or follow-up of low-grade gliomas. There are promising studies which aim to detect circulating tumor DNA in human malignancies. Although this technology hasn't been applied to low-grade gliomas it could potentially be implemented in the future as a screening, diagnostic or follow-up tool.[8]

Next

Imaging Studies

Both CT scan and MRI can aid in the diagnosis of low-grade glioma. Generally, MRI is considered the study of choice. However, in an emergency setting a noncontrast CT scan may be ordered first.

Computed tomography

Patients with new-onset headache, seizure, weakness, or numbness frequently undergo a CT scan first. Typical CT findings of a low-grade glioma show lower attenuation than the surrounding brain (see image below). A mild mass effect may be noted. Obstructive hydrocephalus can be confirmed. Low-grade gliomas also may show evidence of calcification (more common in oligodendroglial tumors). Low-grade astrocytomas are usually non-enhancing lesions, although the presence of contrast enhancement doesn´t preclude their diagnosis.

PET and SPECT

Positron emission tomography (PET) and single-photon emission computed tomography (SPECT) imaging sometimes are used to try to differentiate low-grade gliomas from either high-grade tumors or other types of pathology. Typically, low-grade gliomas show hypometabolism via PET or SPECT while high-grade gliomas are hypermetabolic. This information may be useful in guiding further therapy.

A 28-year-old male taxi driver presented to the em A 28-year-old male taxi driver presented to the emergency department after having a seizure. Noncontrast head CT scan was obtained showing the typical appearance of a low-grade astrocytoma. The lesion in the mesial left frontal lobe was hypodense on CT scan.

Magnetic resonance imaging

On MRI, low-grade astrocytomas show decreased signal relative to surrounding brain on T1 sequences (see following images).

Preoperative MRI of the brain of a 28-year-old mal Preoperative MRI of the brain of a 28-year-old male taxi driver who presented to the emergency department after having a seizure. On T1-weighted sequences, the tumor does not enhance and shows decreased signal intensity compared to normal brain. These findings are consistent with low-grade astrocytoma.
For tumors, MRI has the advantage of showing the l For tumors, MRI has the advantage of showing the lesion in multiple planes. This image, a T1-weighted sagittal image of the brain of a 28-year-old male taxi driver who presented to the emergency department after having a seizure, shows the tumor along the mesial aspect of the frontal lobe. Note that mass effect is minimal, typical of a low-grade lesion.
Coronal T1-weighted gadolinium-enhanced MRI of the Coronal T1-weighted gadolinium-enhanced MRI of the brain shows the tumor of a 9-year-old boy who presented with headaches and gradual onset of a right hemiparesis. Note the heterogeneous enhancement of the tumor.
Sagittal T1-weighted MRI of the brain shows juveni Sagittal T1-weighted MRI of the brain shows juvenile pilocytic astrocytoma of a 9-year-old boy who presented with headaches and gradual onset of right hemiparesis. Stereotactic surgery has made resection of these low-grade tumors in this deep location feasible.
A 3-year-old boy presented with speech regression. A 3-year-old boy presented with speech regression. MRI of the brain revealed a tumor in the left mesial temporal lobe. This T1-weighted gadolinium-enhanced image shows an enhancing tumor involving the hippocampus, uncus, and amygdala. The surgical pathologic studies revealed a low-grade mixed tumor of astrocytes and atypical neurons, a ganglioglioma.

On T2 sequences, higher signal reflects both the tumor and surrounding edema (see following images). Pilocytic astrocytomas often are associated with a cyst, which may be particularly prominent on T2-weighted sequences.

T2-weighted sequences of an MRI of the brain of a T2-weighted sequences of an MRI of the brain of a 28-year-old male taxi driver who presented to the emergency department after having a seizure show increased signal intensity compared with normal brain. The radiologic appearance is typical of low-grade astrocytoma.
A 9-year-old boy presented with headaches and grad A 9-year-old boy presented with headaches and gradual onset of right hemiparesis. MRI of the brain was obtained. The T2-weighted sequence in this MRI shows a tumor in the left thalamus, which is a typical location for a juvenile pilocytic astrocytoma. Note the relatively well-circumscribed nature of the lesion.

MRI of the spinal cord is also the study of choice if an intramedullary low-grade astrocytoma is suspected. On MRI, widening of the spinal cord and frequently an associated cyst are noted. The tumor may show a variable degree of enhancement.

Functional magnetic resonance imaging (fMRI) can provide information about the relationship and localization of a low-grade glioma and eloquent structures such as speech centers and motor pathways. This may help in planning the operation. Recently, the use of digital tractography has allowed to pre-operatively assess the relationship of tumors to important white matter tracts (e.g. descending corticospinal tract) prior to resection.

Previous
Next

Other Tests

Electroencephalography (EEG) may be performed on a patient with new-onset seizures; however, no EEG findings are specific to low-grade glioma. However, generalized, diffuse slowing and/or epileptogenic spikes can be seen over the area of the tumor.

Previous
Next

Procedures

Lumbar puncture is generally contraindicated in patients with elevated intracranial pressure, which may occur in the setting of a brain tumor. Cerebrospinal fluid (CSF) studies do not aid in the diagnosis of low-grade astrocytomas.

Previous
Next

Histologic Findings

The histologic findings in low-grade astrocytomas vary according to the specific tumor type. As reviewed before, the absence of high-grade lesion characteristics like necrosis, microvascular proliferation and high mitotic indices are common to the group as a whole.

Pilocytic astrocytomas show the presence of bipolar piloid cells with long hair-like processes and Rosenthal fibers. Pilomyxoid astrocytomas are dominated by the presence of a mucoid matrix, monomorphous bipolar cells and an angiocentric cell arrangement. Pleomorphic xanthoastrocytomas have a variable histological appearance, hence the name. The term xanthoastrocytoma is derived from the presence of xanthomatous cells which show intracellular accumulation of lipids. Diffuse astrocytomas are composed of well differentiated fibrillary or gemistocytic neoplastic astrocytes on the background of a loosely structured microcystic tumour matrix.[1]

Previous
Next

Staging

There are currently no valid staging systems in clinical use.

Previous


Contributor Information and Disclosures
Author

George I Jallo, MD Professor of Neurosurgery, Pediatrics, and Oncology, Director, Clinical Pediatric Neurosurgery, Department of Neurosurgery, Johns Hopkins University School of Medicine

George I Jallo, MD is a member of the following medical societies: American Association of Neurological Surgeons, American Medical Association, American Society of Pediatric Neurosurgeons

Disclosure: Received grant/research funds from Codman (Johnson & Johnson) for consulting; Received grant/research funds from Medtronic for consulting.

Coauthor(s)

Eveline Teresa Hidalgo Staub, MD Neurosurgery Attending, Division of Neurosurgery, General and Pediatric Neurosurgery, Luzerner Kantonsspital

Eveline Teresa Hidalgo Staub, MD is a member of the following medical societies: Swiss Society of Neurosurgery, Swiss Young Neurosurgeons Society

Disclosure: Nothing to disclose.

David A Chesler, MD, PhD Clinical and Research Fellow, Division of Pediatric Neurosurgery, Johns Hopkins University School of Medicine

David A Chesler, MD, PhD is a member of the following medical societies: American Association of Neurological Surgeons, American Medical Association, Congress of Neurological Surgeons

Disclosure: Nothing to disclose.

Rafael Uribe-Cardenas, MD Resident Physician in Neurosurgery, Department of Neuroscience, Hospital Universitario San Ignacio, Pontificia Universidad Javeriana, Colombia

Rafael Uribe-Cardenas, MD is a member of the following medical societies: Colombian Association of Neurosurgery

Disclosure: Nothing to disclose.

Specialty Editor Board

Francisco Talavera, PharmD, PhD Adjunct Assistant Professor, University of Nebraska Medical Center College of Pharmacy; Editor-in-Chief, Medscape Drug Reference

Disclosure: Received salary from Medscape for employment. for: Medscape.

Jorge C Kattah, MD Head, Associate Program Director, Professor, Department of Neurology, University of Illinois College of Medicine at Peoria

Jorge C Kattah, MD is a member of the following medical societies: American Academy of Neurology, American Neurological Association, New York Academy of Sciences

Disclosure: Nothing to disclose.

Chief Editor

Tarakad S Ramachandran, MBBS, MBA, MPH, FAAN, FACP, FAHA, FRCP, FRCPC, FRS, LRCP, MRCP, MRCS Professor Emeritus of Neurology and Psychiatry, Clinical Professor of Medicine, Clinical Professor of Family Medicine, Clinical Professor of Neurosurgery, State University of New York Upstate Medical University; Neuroscience Director, Department of Neurology, Crouse Irving Memorial Hospital

Tarakad S Ramachandran, MBBS, MBA, MPH, FAAN, FACP, FAHA, FRCP, FRCPC, FRS, LRCP, MRCP, MRCS is a member of the following medical societies: American College of International Physicians, American Heart Association, American Stroke Association, American Academy of Neurology, American Academy of Pain Medicine, American College of Forensic Examiners Institute, National Association of Managed Care Physicians, American College of Physicians, Royal College of Physicians, Royal College of Physicians and Surgeons of Canada, Royal College of Surgeons of England, Royal Society of Medicine

Disclosure: Nothing to disclose.

Additional Contributors

Rodrigo O Kuljis, MD Esther Lichtenstein Professor of Psychiatry and Neurology, Director, Division of Cognitive and Behavioral Neurology, Department of Neurology, University of Miami School of Medicine

Rodrigo O Kuljis, MD is a member of the following medical societies: American Academy of Neurology, Society for Neuroscience

Disclosure: Nothing to disclose.

Acknowledgements

Ethan A Benardete, MD, PhD Staff Physician, Department of Neurosurgery, New York University Medical Center

Disclosure: Nothing to disclose.

References
  1. P. Kleihues, D.N. Louis, O.D. Wiestler, P.C. Burger, B.W. Scheithauer. WHO grading of tumours of the central nervous system. David N. Louis, Hiroko Ohgaki, Otmar D. Wiestler, Webster K. Cavenee. WHO Classification of Tumours of the Central Nervous System. 4th. International Agency for Research on Cancer (IARC); 2007. 10.

  2. Quinn T. Ostrom, Haley Gittleman, Paul Farah, Annie Ondracek, Yanwen Chen, Yingli Wolinsky, et al. CBTRUS Statistical Report: Primary Brain and Central Nervous System Tumors Diagnosed in the United States in 2006-2010. Neuro-Oncology. November/2013. 15:ii1-ii56. [Medline].

  3. Emanuele Crocetti, Annalisa Trama, Charles Stiller, Adele Caldarella, Riccardo Soffietti, Jana Jaal, et al. Epidemiology of glial and non-glial brain tumours in Europe. European Journal of Cancer. 2012. 48:1532-1542. [Medline].

  4. Julius Griauzde, Ahmad Khaldi, Edward Melian, Ricarchito Manera, Margaret Primeau, Darrin M. Aase, et al. Pilocytic Astrocytojma: A Comprehensive Review. Contemporary Neurosurgery. June 30, 2011. 33:1-6.

  5. Fleury A, Menegoz F, Grosclaude P, et al. Descriptive epidemiology of cerebral gliomas in France. Cancer. 1997 Mar 15. 79(6):1195-202. [Medline].

  6. Nader Pouratian, Ahok Asthagiri, Jay Jagannathan, Mark E Shaffrey, David Schiff. Surgery Insight: the role of surgery in the management of low-grade gliomas. Nature Clinical Practice. Neurology. November/2007. 3:628-639. [Medline].

  7. Hiroko Ohgaki, Paul Kleihues. Epidemiology and etiology of gliomas. Acta Neuropathologica. 2005. 109:93-108. [Medline].

  8. C. Bettegowda, M. Sausen, R. J. Leary, I. Kinde, Y. Wang, N. Agrawal, et al. Detection of Circulating Tumor DNA in Early- and Late-Stage Human Malignancies. Science Translational Medicine. February/2014. 6:1-11. [Medline].

  9. Ajlan A, Recht L. Supratentorial low-grade diffuse astrocytoma: medical management. Semin Oncol. 2014 Aug. 41(4):446-57. [Medline].

  10. Lunsford LD, Somaza S, Kondziolka D, Flickinger JC. Survival after stereotactic biopsy and irradiation of cerebral nonanaplastic, nonpilocytic astrocytoma. J Neurosurg. 1995 Apr. 82(4):523-9. [Medline].

  11. Recht LD, Bernstein M. Low-grade gliomas. Neurol Clin. 1995 Nov. 13(4):847-59. [Medline].

  12. Pedersen CL, Romner B. Current treatment of low grade astrocytoma: a review. Clin Neurol Neurosurg. 2013 Jan. 115(1):1-8. [Medline].

  13. Sanai N, Snyder LA, Honea NJ, Coons SW, Eschbacher JM, Smith KA, et al. Intraoperative confocal microscopy in the visualization of 5-aminolevulinic acid fluorescence in low-grade gliomas. J Neurosurg. 2011 Oct. 115(4):740-8. [Medline].

  14. Christian Senft, Andrea Bink, Kea Franz, Harmut Vatter, Thomas Gasser, Volker Seifert. Intraoperative MRI guidance and extent of resection in glioma surgery: a randomised, controlled trial. Lancet Oncology. 2011. 12:997-1003. [Medline].

  15. Chang EF, Clark A, Smith JS, Polley MY, Chang SM, Barbaro NM. Functional mapping-guided resection of low-grade gliomas in eloquent areas of the brain: improvement of long-term survival. Clinical article. J Neurosurg. 2011 Mar. 114(3):566-73. [Medline].

  16. Sanai N, Mirzadeh Z, Berger MS. Functional outcome after language mapping for glioma resection. N Engl J Med. 2008 Jan 3. 358(1):18-27. [Medline].

  17. Chang EF, Clark A, Jensen RL, Bernstein M, Guha A, Carrabba G, et al. Multiinstitutional validation of the University of California at San Francisco Low-Grade Glioma Prognostic Scoring System. Clinical article. J Neurosurg. 2009 Aug. 111(2):203-10. [Medline].

  18. Kim YH, Nobusawa S, Mittelbronn M, Paulus W, Brokinkel B, Keyvani K. Molecular classification of low-grade diffuse gliomas. Am J Pathol. 2010 Dec. 177(6):2708-14. [Medline].

  19. Alvord EC, Lofton S. Gliomas of the optic nerve or chiasm. Outcome by patients' age, tumor site, and treatment. J Neurosurg. 1988 Jan. 68(1):85-98. [Medline].

  20. Clark GB, Henry JM, McKeever PE. Cerebral pilocytic astrocytoma. Cancer. 1985 Sep 1. 56(5):1128-33. [Medline].

  21. Constantini S, Houten J, Miller DC, et al. Intramedullary spinal cord tumors in children under the age of 3 years. J Neurosurg. 1996 Dec. 85(6):1036-43. [Medline].

  22. Duffau H, Lopes M, Arthuis F, Bitar A, Sichez JP, Van Effenterre R. Contribution of intraoperative electrical stimulations in surgery of low grade gliomas: a comparative study between two series without (1985-96) and with (1996-2003) functional mapping in the same institution. J Neurol Neurosurg Psychiatry. 2005 Jun. 76(6):845-51. [Medline].

  23. Franzini A, Leocata F, Cajola L, Servello D, Allegranza A, Broggi G. Low-grade glial tumors in basal ganglia and thalamus: natural history and biological reappraisal. Neurosurgery. 1994 Nov. 35(5):817-20; discussion 820-1. [Medline].

  24. Hakyemez B, Erdogan C, Ercan I, et al. High-grade and low-grade gliomas: differentiation by using perfusion MR imaging. Clin Radiol. 2005 Apr. 60(4):493-502. [Medline].

  25. Komotar RJ, Mocco J, Carson BS, et al. Pilomyxoid astrocytoma: a review. MedGenMed. 2004. 6(4):42. [Medline].

  26. Laws ER, Taylor WF, Clifton MB, Okazaki H. Neurosurgical management of low-grade astrocytoma of the cerebral hemispheres. J Neurosurg. 1984 Oct. 61(4):665-73. [Medline].

  27. Lote K, Egeland T, Hager B, et al. Survival, prognostic factors, and therapeutic efficacy in low-grade glioma: a retrospective study in 379 patients. J Clin Oncol. 1997 Sep. 15(9):3129-40. [Medline].

  28. Macdonald DR. Low-grade gliomas, mixed gliomas, and oligodendrogliomas. Semin Oncol. 1994 Apr. 21(2):236-48. [Medline].

  29. McCormack BM, Miller DC, Budzilovich GN, et al. Treatment and survival of low-grade astrocytoma in adults--1977-1988. Neurosurgery. 1992 Oct. 31(4):636-42; discussion 642. [Medline].

  30. McCormick PC, Stein BM. Spinal cord tumors in adults. Neurological Surgery. 1996. 4:3102-122.

  31. Morantz R A. Low-grade astrocytomas. Kaye AH, Laws ER Jr, eds. Brain Tumors: An Encyclopedic Approach. New York: Churchill Livingstone; 1995. 433-48.

  32. Salcman M. Radical surgery for low-grade glioma. Clin Neurosurg. 1990. 36:353-66. [Medline].

  33. Teixidor P, Gatignol P, Leroy M, Masuet-Aumatell C, Capelle L, Duffau H. Assessment of verbal working memory before and after surgery for low-grade glioma. J Neurooncol. 2007 Feb. 81(3):305-13. [Medline].

  34. Vandenberg SR, Sampaio Lopes MB. Classification. Berger MS, Wilson CB, eds. The Gliomas. Philadelphia: WB Saunders; 1999. 172-91.
