- Author: Michael J Schneck, MD, MBA; more...
Radiation necrosis, a focal structural lesion that usually occurs at the original tumor site, is a potential long-term central nervous system (CNS) complication of radiotherapy or radiosurgery. Edema and the presence of tumor render the CNS parenchyma in the tumor bed more susceptible to radiation necrosis. Radiation necrosis can occur when radiotherapy is used to treat primary CNS tumors, metastatic disease, or head and neck malignancies. It can occur secondary to any form of radiotherapy modality or regimen.
In the clinical situation of a recurrent astrocytoma (postradiation therapy), radiation necrosis presents a diagnostic dilemma. Astrocytic tumors can mutate to the more malignant glioblastoma multiforme. Glioblastoma multiforme's hallmark histology of pseudopalisading necrosis makes it difficult to differentiate radiation necrosis from recurrent astrocytoma using MRI. See Medscape Reference articles Neurologic Manifestations of Glioblastoma Multiforme and Low-Grade Astrocytoma.
Therapeutic effects of radiotherapy
Radiation creates ionized oxygen species that react with cellular DNA. Tumor cells have less ability than healthy cells for DNA repair. Thus, between fractionation doses, healthy cells have a greater probability than tumor cells of repairing themselves. With each subsequent mitosis, the cumulative effects of unrepaired DNA result in apoptosis (cell death) of these tumor cells.
Central nervous system syndromes secondary to radiotherapy
Radiation necrosis is part of a series of clinical syndromes related to CNS complications of radiotherapy. These syndromes occur in a distinct chronologic order and have characteristic pathophysiology. While the term radiation necrosis is used to refer to radiation injury, pathology is not limited to necrosis and a spectrum of injury patterns may occur.
Acute encephalopathy occurs during and up to 1 month after radiotherapy. This acute encephalopathy is due to disruption of the blood-brain barrier.
Early delayed complications occur 1-4 months after radiotherapy. Early delayed complications are caused by white matter injury characterized by demyelination and vasogenic edema. Early delayed changes may produce a somnolence syndrome in children, reappearance of the initial tumor's symptomatology, temporary decline in long-term memory, and encephalopathy. In early delayed complications, patients may have increased edema and contrast enhancement on MRI (both symptomatic and asymptomatic) that may resolve spontaneously over a few months. Both the acute and early delayed complications are steroid responsive.
Treatment-induced leukoencephalopathy is the leading toxicity after primary CNS lymphoma and may be seen both early and as a delayed consequence of treatment. It may be seen in greater than 90% of patients older than 60 years who have been successfully treated with combination chemotherapy and whole-brain radiation. A relationship between increased blood-brain barrier permeability and radiation therapy has been posited to contribute to this leukoencephalopathy and to methotrexate-induced vasculopathy. This also may be an etiology for the changes seen with radiation necrosis.
Radiation necrosis and diffuse cerebral atrophy are considered long-term complications of radiotherapy that occur from months to decades after radiation treatment. As opposed to the focal nature of radiation necrosis, diffuse cerebral atrophy is characterized by bihemispheric sulci enlargement, brain atrophy, and ventriculomegaly. Diffuse cerebral atrophy clinically is associated with cognitive decline, personality changes, and gait disturbances.
Liu et al reported that in children with pontine gliomas, a nearly always fatal brain tumor, bevacizumab may provide both therapeutic benefit and diagnostic information. They note that although radiation therapy can provide some palliation in such patients, it can also result in radiation necrosis and neurologic decline. In a study of 4 children, 3 children showed significant clinical improvement with bevacizumab and were able to discontinue steroid use, which, according to the authors, can have numerous side effects that significantly compromise a patient's quality of life. In 1 child who continued to decline on bevacizumab, it was later determined that the patient had disease progression, not radiation necrosis. In all cases, according to the investigators, bevacizumab was well tolerated.
Barajas et al attempted, in a study of 57 patients, to determine whether T2-weighted dynamic susceptibility-weighted contrast material-enhanced (DSC) MRI can differentiate radiation-therapy-induced necrosis from glioblastoma multiforme. They found that mean, maximum, and minimum relative peak height and relative cerebral blood volume were significantly higher in patients with recurrent glioblastoma multiforme than in patients with radiation necrosis. In addition, they determined that mean, maximum, and minimum relative percentage of signal intensity recovery values were significantly lower in patients with recurrent glioblastoma multiforme than in patients with radiation necrosis.
Levin et al designed a class 1 double-blind study to compare the treatment of cerebral radiation necrosis with bevacizumab or placebo in 14 patients. Their protocol use, clinical, imaging, and other measures clearly demonstrated a beneficial effect of bevacizumab. They used 4 cycles at 3-week intervals. The dose was 7.5 mg/kg. Theoretically, bevacizumab blocks the effect of vascular endothelial growth factor (VGEF) and decreases vascular permeability, a critical component of radiation-mediated injury in the brain. The long-term benefit is not known. One of the study patients required an additional dose.
Plimpton et al used MRI to retrospectively study 101 children with solid brain tumors. Median follow-up for all patients was 13 months (range 3-51 mo). They concluded that findings in pediatric patients treated with radiotherapy for solid brain tumor suggests children may have an increased likelihood to develop radiation necrosis compared with adults.
Radiation necrosis is coagulative and predominantly affects white matter. This coagulative necrosis is due to small artery injury and thrombotic occlusion. These small arteries demonstrate endothelial thickening, lymphocytic and macrophagic infiltrates, presence of cytokines, hyalinization, fibrinoid deposition, thrombosis, and finally occlusion.
The primary mechanism of the delayed injury in radiation associated with necrosis is secondary to vascular endothelial injury or direct damage to oligodendroglia. As a result, white matter tissue is often more affected than gray matter tissue. Radiation may have effects on fibrinolytic enzyme systems, with an absence of tissue plasminogen activator and an excess in urokinase plasminogen activator impacting tissue fibrinogen and extracellular proteolysis with subsequent cytotoxic edema and tissue necrosis. Whether immune-mediated mechanisms may also contribute to radiation-induced neurotoxicity is unclear, but an autoimmune vasculitis has been postulated as a secondary host response to tissue damage.
Animals exposed to radiation and given antibodies to cytokines (tumor necrosis factor, interleukin-1, tissue growth factor) have decreased survival compared to animals that do not receive these antibodies. These cytokines may be involved in initially protecting healthy tissue from the effects of radiation. With prolonged radiation exposure, these particular cytokines are overexpressed and result in a cascade of inflammatory events and vascular injury.
In addition to vessel occlusion with resultant tissue necrosis, telangiectatic vessels, which may hemorrhage, occasionally form. Demyelination, oligodendrocyte dropout, axonal swelling, reactive gliosis, and disruption of the blood-brain barrier also can be observed.
Natural history of the tumor in terms of prognosis and survival may affect the occurrence of radiation necrosis in a particular tumor population. In glioblastoma multiforme or metastatic disease with a poor long-term prognosis, the patient may not live long enough to develop radiation necrosis. Radiation necrosis can occur as soon as a few months or as long as decades after treatment. It generally occurs 6 months to 2 years after radiation therapy. Radiation injury may occur in 5-37% of patients treated for intracranial neoplasms.
Radiation necrosis can be fatal. It also can cause problems associated with a mass lesion, such as seizures, focal deficits, increased intracranial pressure, and herniation syndromes.
Lai R, Abrey LE, Rosenblum MK, DeAngelis LM. Treatment-induced leukoencephalopathy in primary CNS lymphoma: a clinical and autopsy study. Neurology. 2004 Feb 10. 62(3):451-6. [Medline].
Liu AK, Macy ME, Foreman NK. Bevacizumab as therapy for radiation necrosis in four children with pontine gliomas. Int J Radiat Oncol Biol Phys. 2009 Nov 15. 75(4):1148-54. [Medline].
Barajas RF Jr, Chang JS, Segal MR, Parsa AT, McDermott MW, Berger MS, et al. Differentiation of recurrent glioblastoma multiforme from radiation necrosis after external beam radiation therapy with dynamic susceptibility-weighted contrast-enhanced perfusion MR imaging. Radiology. 2009 Nov. 253(2):486-96. [Medline]. [Full Text].
Levin VA, Bidaut L, Hou P, et al. Randomized double-blind placebo-controlled trial of bevacizumab therapy for radiation necrosis of the central nervous system. Int J Radiat Oncol Biol Phys. 2011 Apr 1. 79(5):1487-95. [Medline]. [Full Text].
Plimpton SR, Stence N, Hemenway M, Hankinson TC, Foreman N, Liu AK. Cerebral Radiation Necrosis in Pediatric Patients. Pediatr Hematol Oncol. 2013 May 7. [Medline].
Kureshi SA, Hofman FM, Schneider JH, Chin LS, Apuzzo ML, Hinton DR. Cytokine expression in radiation-induced delayed cerebral injury. Neurosurgery. 1994 Nov. 35(5):822-9; discussion 829-30. [Medline].
Langleben DD, Segall GM. PET in differentiation of recurrent brain tumor from radiation injury. J Nucl Med. 2000 Nov. 41(11):1861-7. [Medline].
Cheng KM, Chan CM, Fu YT, Ho LC, Cheung FC, Law CK. Acute hemorrhage in late radiation necrosis of the temporal lobe: report of five cases and review of the literature. J Neurooncol. 2001 Jan. 51(2):143-50. [Medline].
Ruben JD, Dally M, Bailey M, Smith R, McLean CA, Fedele P. Cerebral radiation necrosis: incidence, outcomes, and risk factors with emphasis on radiation parameters and chemotherapy. Int J Radiat Oncol Biol Phys. 2006 Jun 1. 65(2):499-508. [Medline].
Shah R, Vattoth S, Jacob R, Manzil FF, O'Malley JP, Borghei P, et al. Radiation necrosis in the brain: imaging features and differentiation from tumor recurrence. Radiographics. 2012 Sep-Oct. 32(5):1343-59. [Medline].
Asao C, Korogi Y, Kitajima M, et al. Diffusion-weighted imaging of radiation-induced brain injury for differentiation from tumor recurrence. AJNR Am J Neuroradiol. 2005 Jun-Jul. 26(6):1455-60. [Medline].
Dequesada IM, Quisling RG, Yachnis A, Friedman WA. Can standard magnetic resonance imaging reliably distinguish recurrent tumor from radiation necrosis after radiosurgery for brain metastases? A radiographic-pathological study. Neurosurgery. 2008 Nov. 63(5):898-903; discussion 904. [Medline].
Reddy K, Westerly D, Chen C. MRI patterns of T1 enhancing radiation necrosis versus tumour recurrence in high-grade gliomas. J Med Imaging Radiat Oncol. 2013 Jun. 57(3):349-55. [Medline].
Miyashita M, Miyatake S, Imahori Y, Yokoyama K, Kawabata S, Kajimoto Y, et al. Evaluation of fluoride-labeled boronophenylalanine-PET imaging for the study of radiation effects in patients with glioblastomas. J Neurooncol. 2008 Sep. 89(2):239-46. [Medline].
Xiangsong Z, Weian C. Differentiation of recurrent astrocytoma from radiation necrosis: a pilot study with 13N-NH3 PET. J Neurooncol. 2007 May. 82(3):305-11. [Medline].
Mogard J, Kihlstrom L, Ericson K, Karlsson B, Guo WY, Stone-Elander S. Recurrent tumor vs radiation effects after gamma knife radiosurgery of intracerebral metastases: diagnosis with PET-FDG. J Comput Assist Tomogr. 1994 Mar-Apr. 18(2):177-81. [Medline].
Kahn D, Follett KA, Bushnell DL, et al. Diagnosis of recurrent brain tumor: value of 201Tl SPECT vs 18F-fluorodeoxyglucose PET. AJR Am J Roentgenol. 1994 Dec. 163(6):1459-65. [Medline].
Chung JK, Kim YK, Kim SK, et al. Usefulness of 11C-methionine PET in the evaluation of brain lesions that are hypo- or isometabolic on 18F-FDG PET. Eur J Nucl Med Mol Imaging. 2002 Feb. 29(2):176-82. [Medline].
Rock JP, Hearshen D, Scarpace L, et al. Correlations between magnetic resonance spectroscopy and image-guided histopathology, with special attention to radiation necrosis. Neurosurgery. 2002 Oct. 51(4):912-9; discussion 919-20. [Medline].
Chuba PJ, Aronin P, Bhambhani K, et al. Hyperbaric oxygen therapy for radiation-induced brain injury in children. Cancer. 1997 Nov 15. 80(10):2005-12. [Medline].
Ashamalla HL, Thom SR, Goldwein JW. Hyperbaric oxygen therapy for the treatment of radiation-induced sequelae in children. The University of Pennsylvania experience. Cancer. 1996 Jun 1. 77(11):2407-12. [Medline].
Levin VA, Bidaut L, Hou P, Kumar AJ, Wefel JS, Bekele BN, et al. Randomized double-blind placebo-controlled trial of bevacizumab therapy for radiation necrosis of the central nervous system. Int J Radiat Oncol Biol Phys. 2011 Apr 1. 79 (5):1487-95. [Medline].
Boothe D, Young R, Yamada Y, Prager A, Chan T, Beal K. Bevacizumab as a treatment for radiation necrosis of brain metastases post stereotactic radiosurgery. Neuro Oncol. 2013 Sep. 15 (9):1257-63. [Medline].
Glantz MJ, Burger PC, Friedman AH, Radtke RA, Massey EW, Schold SC Jr. Treatment of radiation-induced nervous system injury with heparin and warfarin. Neurology. 1994 Nov. 44(11):2020-7. [Medline].
Wong ET, Huberman M, Lu XQ, Mahadevan A. Bevacizumab reverses cerebral radiation necrosis. J Clin Oncol. 2008 Dec 1. 26(34):5649-50. [Medline].
Gonzalez J, Kumar AJ, Conrad CA, Levin VA. Effect of bevacizumab on radiation necrosis of the brain. Int J Radiat Oncol Biol Phys. 2007 Feb 1. 67(2):323-6. [Medline].
Buchpiguel CA, Alavi JB, Alavi A, Kenyon LC. PET versus SPECT in distinguishing radiation necrosis from tumor recurrence in the brain. J Nucl Med. 1995 Jan. 36(1):159-64. [Medline].
Cerghet M, Redman B, Junck L, Forman J, Rogers LR. Prolonged survival after multifocal brain radiation necrosis associated with whole brain radiation for brain metastases: case report. J Neurooncol. 2008 Oct. 90(1):85-8. [Medline].
Chen W. Clinical applications of PET in brain tumors. J Nucl Med. 2007 Sep. 48(9):1468-81. [Medline].
de Vries B, Taphoorn MJ, van Isselt JW, Terhaard CH, Jansen GH, Elsenburg PH. Bilateral temporal lobe necrosis after radiotherapy: confounding SPECT results. Neurology. 1998 Oct. 51(4):1183-4. [Medline].
Deshmukh A, Scott JA, Palmer EL, Hochberg FH, Gruber M, Fischman AJ. Impact of fluorodeoxyglucose positron emission tomography on the clinical management of patients with glioma. Clin Nucl Med. 1996 Sep. 21(9):720-5. [Medline].
Ishikawa M, Kikuchi H, Miyatake S, Oda Y, Yonekura Y, Nishizawa S. Glucose consumption in recurrent gliomas. Neurosurgery. 1993 Jul. 33(1):28-33. [Medline].
Kumar AJ, Leeds NE, Fuller GN, et al. Malignant gliomas: MR imaging spectrum of radiation therapy- and chemotherapy-induced necrosis of the brain after treatment. Radiology. 2000 Nov. 217(2):377-84. [Medline].
Lee AW, Foo W, Chappell R, et al. Effect of time, dose, and fractionation on temporal lobe necrosis following radiotherapy for nasopharyngeal carcinoma. Int J Radiat Oncol Biol Phys. 1998 Jan 1. 40(1):35-42. [Medline].
McPherson CM, Warnick RE. Results of contemporary surgical management of radiation necrosis using frameless stereotaxis and intraoperative magnetic resonance imaging. J Neurooncol. 2004 May. 68(1):41-7. [Medline].
Nelson MD Jr, Soni D, Baram TZ. Necrosis in pontine gliomas: radiation induced or natural history?. Radiology. 1994 Apr. 191(1):279-82. [Medline].
Nelson SJ, Huhn S, Vigneron DB, et al. Volume MRI and MRSI techniques for the quantitation of treatment response in brain tumors: presentation of a detailed case study. J Magn Reson Imaging. 1997 Nov-Dec. 7(6):1146-52. [Medline].
Olivero WC, Dulebohn SC, Lister JR. The use of PET in evaluating patients with primary brain tumours: is it useful?. J Neurol Neurosurg Psychiatry. 1995 Feb. 58(2):250-2. [Medline].
Omuro AM, Leite CC, Mokhtari K, Delattre JY. Pitfalls in the diagnosis of brain tumours. Lancet Neurol. 2006 Nov. 5(11):937-48. [Medline].
Packer RJ, Zimmerman RA, Kaplan A, et al. Early cystic/necrotic changes after hyperfractionated radiation therapy in children with brain stem gliomas. Data from the Childrens Cancer Group. Cancer. 1993 Apr 15. 71(8):2666-74. [Medline].
Peterson K, Clark HB, Hall WA, Truwit CL. Multifocal enhancing magnetic resonance imaging lesions following cranial irradiation. Ann Neurol. 1995 Aug. 38(2):237-44. [Medline].
Posner JB. Side effects of radiation therapy. Neurologic Complications of Cancer. No. 54. Philadelphia, Pa: FA Davis; 1995. 311-37.
Rizzoli HV, Pagnanelli DM. Treatment of delayed radiation necrosis of the brain. A clinical observation. J Neurosurg. 1984 Mar. 60(3):589-94. [Medline].
Slizofski WJ, Krishna L, Katsetos CD, et al. Thallium imaging for brain tumors with results measured by a semiquantitative index and correlated with histopathology. Cancer. 1994 Dec 15. 74(12):3190-7. [Medline].
