- Author: Senad Osmanovic, MD; Chief Editor: Hampton Roy, Sr, MD more...
A scleral buckle is performed in order to repair a retinal detachment by reestablishing the anatomic proximity of separated retina from its underlying tissue. An acute retinal detachments is an ophthalmologic emergency that can rapidly progress to irreversible vision loss in the affected eye.
The neurosensory retina depends on its underlying layers (the retinal pigment epithelium and choroid) for delivery of oxygen, trophic factors, and nutritional substrates. Therefore, any damage or disruption in the conduit between the layers has great potential to lead to ischemic damage and cell death. The vast majority of detachments are caused by the formation of tears (rhegma) in the retina, which allow the entrance of liquefied vitreous into the subretinal space, leading to subsequent separation of the retina from the underlying retinal pigment epithelium.
The principle of scleral buckling is based on the need to collapse the anatomic space created between the detached sensory retina and the retinal pigment epithelium. This is done by the inward indentation of the sclera from the exterior, creating a ridge (or buckle) that reduces the fluid underneath the tear and allows for the re-apposition of separated layers, thus reestablishing their physiologic connection. The sclera itself is most commonly indented by placement of a permanent explant with sutures, although temporary buckles have been used in variations.
The external indentation from the buckle explant reduces the volume of the globe, and in doing so relieves a portion of the vitreous traction contributing to the retinal tear and detachment. Although this procedure involves exposure of the globe and considerable intraorbital manipulation, it is most often performed on an outpatient basis.
In addition to the placement of the explant to displace the eye wall inward, it is important that the retinal tears are sealed by the formation of chorioretinal adhesions. This is performed by inducing a chorioretinal scar via cryotherapy, diathermy, or laser energy. In conjunction with the generation of such adhesions, the physical closure of the break by the explant enables the attachment of the retina. The dynamic forces that generated the detachment (vitreoretinal traction and inflow of liquefied vitreous) are thus countered by these maneuvers.
Once secured, the normal physiologic and metabolic forces preventing separation may then maintain retinal attachment. Depending on the extent of detachment, the degree of fluid and any associated pathologies, there may also be indications for auxiliary procedures during the placement of the scleral buckle, such as the removal of accumulated subretinal fluid and/or the injection of intravitreal gas.
Although modalities such as vitrectomy and pneumatic retinopexy are increasingly used to manage retinal detachments, buckling continues to be an important and useful approach in many clinical scenarios. In addition to the placement of scleral buckles as a primary and solitary procedure, they are often used in combination with pars plana vitrectomy in order to address complicated retinal detachments and provide further support. Given the poor visual outcomes that attend the course of an uncorrected detachment, scleral buckling is most often performed on an emergent to urgent basis, especially in the setting of macula-sparing detachments.
Scleral buckling is indicated for the following conditions:
Rhegmatogenous retinal detachment, especially in phakic eyes
Young patients with attached posterior hyaloid
Detachments due to dialysis without retinal tear
Complex retinal detachments involving multiple tears
The most common mechanism causing retinal detachments is the formation of rhegmas or full-thickness tears in the retina. Rhegmatogenous detachments account for 90% of detachments, resulting from the traction exerted on the retina by the posterior vitreous. As the rhegma forms, liquefied vitreous is allowed access to a pathway into the subretinal space. It subsequently acts as a wedge to separate the retina from the retinal pigment epithelial.
Although the initial presentation of patients with symptomatic detachment can vary widely, there are common salient features, including the following symptoms:
Photopsia (flashing lights related to mechanical stimulation of the retina through vitreous traction)
Floaters (due to detachment of vitreous)
Visual field defects (often described by the patient as a sudden black curtain or veil that may enlarge over time)
Decreased visual acuity (noted in detachments involving or threatening the macula)
Detachments may be due to dialysis, in which the retina detaches circumferentially from its insertion point at the ora serrata on the retinal periphery. This is a less common etiology and is most often seen in the setting of trauma and in young patients.
Rhegmatogenous retinal detachments complicated by tractional forces from proliferative vitreoretinopathy, as well as other proliferative processes such as diabetic retinopathy, require vitrectomy along with scleral buckling when the traction is present in the peripheral retina in order to achieve high success rates of reattachment. These surgeries may require also advanced surgical techniques, such as membrane peeling, silicone oil instillation, and creation of retinectomies (incisions in the retina).
Detachments that emanate from breaks anterior to the equator (the anterior-posterior circumferential midpoint of the globe) are more amenable to placement of buckles. Breaks significantly posterior to the equator are anatomically more difficult to approach owing to hindrances from the bony orbit and poor surgical exposure. As such, posteriorly located breaks are best addressed with vitrectomy.
Opaque media may preclude visualization of retinal tears and thus proper accounting of all the breaks. This is most often seen in scenarios of vitreous hemorrhage, such as in the setting of severe retinal neovascularization due to diabetic retinopathy.
In patients with significant vitreoretinal traction, such as with proliferative vitreoretinopathy and diabetic neovascularization, using a scleral buckle exclusively is usually insufficient to reattach the retina. However, buckling may be used as part of the surgical approach in addition to vitrectomy.
Nonetheless, many surgeons prefer to avoid possible anterior ischemia caused by buckling in patients with vaso-occlusive disease, such as sickle cell anemia and, to a lesser extent, severe diabetic retinopathy.
If there is a significant tractional component to the retinal detachment, such as in proliferative vitreoretinopathy and proliferative diabetic retinopathy, a vitrectomy approach needs to be used in order to mechanically peel away the causative membranes.[3, 4, 5]
If subretinal drainage is used, it is important to rule out retinal incarceration in the drainage tract.
The most crucial aspect of any approach to treating rhegmatogenous detachments is the ability to localize and account for all of the retinal tears. Failure to locate and treat a tear would predispose any technique to failure because it allows for the new influx of subretinal fluid. When placing a primary buckle, this is performed with indirect ophthalmoscopy via the aid of a condensing lens, typically a 20- or 28-D lens. The use of scleral indentation to bring the peripheral retina into view is necessary in order to achieve full visualization.
Initially, full visual acuity testing should be performed to assess the patient’s baseline level of vision. This is crucial in the primary care or emergency department setting. A drastically reduced visual acuity may be an indication of macular involvement and thus may lessen the need for a more urgent intervention. However, even macula involving detachment are best repaired within 7-10 days for optimum visual acuity recovery.
Extraocular muscle testing is important to establish a baseline because strabismus may develop postoperatively.
Tonometry is indicated because retinal detachment frequently lowers intraocular pressure. Postoperatively, buckling may increase intraocular pressure as a function of volume reduction. As such, it is important to establish any history of glaucoma.
Laboratory tests, as guided by the medical history, may be requested as part of the preoperative evaluation. Coexisting systemic diseases may increase anesthetic and surgical risks, as well as the potential for local complications (eg, thrombocytopenia).
Postsurgical visual outcomes are related to the extent of initial macular involvement. Anatomic reattachment is achieved in close to 90% of cases. However, there is a significant discrepancy between favorable anatomic correction and functional visual outcomes.
The most important issue dictating success in restoring visual acuity is the presence of macular involvement. In macula-off detachments (in which the detachment includes the central retina, the macula), only 50%-60% of patients have restored visual acuity of 20/50 or better. Visual restoration is much more likely in detachments sparing the macula, with one large series reporting that 90% of such patients had vision of 20/40 or better following surgery.
Factors predicting poor visual function include the following:
Age (>70 y)
Macular detachment occurring more than 7 days prior to surgery
Severe proliferative vitreoretinopathy
Overall, and not surprisingly, the most reliable predictor for poor postoperative outcome is poor preoperative visual acuity.
The sensory retina, composed of photoreceptors and adjacent ganglion cells, overlies the retinal pigment epithelium. The blood supply for the sensory retina is derived from two circulations, both originating from the ophthalmic artery. The anterior circulation comes from the retinal artery as it branches into arterioles that course along the surface of the sensory retina and supply the inner (more proximate to the vitreous) layers. Changes in this circulation are seen with vitreous retinopathy, most commonly in patients with diabetes, who are predisposed to tractional detachments. The posterior (uveal) circulation supplies the outer segments of the retina (the photoreceptors and the retinal pigment epithelial). It is the loss of contact with this supply that proves disastrous in the course of detachment.
The peripheral edge of the retina is defined by the ora serrata, the junction with the ciliary body located anteriorly. In this region, the inner and outer retinal layers are tightly adherent.
The sclera is the protective outer covering of the eye composed of fibrous connective tissue. It has the structural integrity to support the placement of an explant. The sclera itself is contained within the Tenon capsule, which merges anteriorly with the conjunctiva. These two structures must be penetrated to place the buckle.
For more information about the relevant anatomy, see Retina Anatomy.
Equipment for sclera buckling includes the following:
Operating room overhead spot lights
Indirect ophthalmoscope and condensing lenses (28 and 20 D)
Surgical loupes or operating microscope may be used, but are not essential
Stevens scissors (curved)
Various forceps, including 0.12 forceps, needle holders, Nugent forceps, Bishop forceps
Sleeve expander forceps
Needles and blades for subretinal fluid drainage, depending on preferred technique
Hemostasis cautery is used by some surgeons
Localizer (variable instrumentation, such as a marking depressor or diathermy probe) Retinopexy applicator of choice, such as cryotherapy (most common), diathermy, or laser
Silicone buckling elements include the following (see image below):
Silicone hard rubber
Silicone encircling band
See the image below.
Air, SF6, and C3 F8 gas (in select cases requiring pneumatic retinopexy) are also used if internal tamponade is desired.
Scleral buckling may be performed under either local or general anesthesia. Retrobulbar local anesthesia with sedation may be used. However, some surgeons routinely use general anesthesia for buckling owing to pain and discomfort associated with manipulation of the recti muscles. Retrobulbar blocks often do not sufficiently anesthetize the posterior insertion of these muscles. General anesthesia is almost always used in pediatric patients. Often, a block is also performed to augment general anesthesia.
There are two principal approaches to administration of local anesthetic: retrobulbar block or peribulbar block.
With retrobulbar block, anesthetic is injected posterior to the globe into the retrobulbar space. The most concerning risks of retrobulbar injection of anesthetic are the potential for retrobulbar hemorrhage, optic nerve damage, injection of anesthetic into the subarachnoid space, and perforation of the globe.
With peribulbar block, anesthetic is introduced more anteriorly, into the muscle cone surrounding the globe. This reduces some of the risks associated with the more posterior injection necessary in the retrobulbar approach, such as optic nerve damage and retrobulbar hemorrhage.
Both of these techniques provide both sensory anesthesia and akinesia of the rectus muscles. A mixture of bupivacaine (0.75%) and lidocaine (2%) is the most commonly administered local anesthetic for both approaches. This provides both a long-acting anesthetic (bupivacaine) and a short-acting agent (lidocaine). Epinephrine should be avoided given the risk of central artery occlusion that exists with resulting vasoconstriction.
Patients are positioned in supine manner on an eye bed with the head flat, and placed under the operating room spotlights.
Monitoring & Follow-up
Patients should be seen the next day to assess for emerging postoperative complications, such as choroidal detachment, high intraocular pressure, or persistent retinal detachment. Further follow-up varies, performed approximately at postoperative weeks 1, 4, 8, 12, and 30, with annual examinations afterward, or as dictated by a complicated postoperative recovery.
Poor visual acuity may be a function of chronicity of the macular detachment, cystoid macular edema, macular pucker, or the presence of subretinal fluid. These may be further assessed with imaging such as fluorescein angiography and/or optical coherence tomography.
General complications may include the following:
Refractive error (due to the increased axial length from pressure of buckle)
Strabismus (if explant is placed so that it entraps a rectus muscle)
Extrusion of the explant
Ischemia of the anterior segment of eye (from the use of encircling bands; often revealed by corneal edema or clouding)
Elevated intraocular pressure (due to reduction of total globe volume)
Macular edema or macular pucker
Other complications may result from the drainage of subretinal fluid, including the following:
Choroidal or subretinal hemorrhage
Retinal incarceration within the sclera perforation
Neovascularization or proliferative retinopathy
Patients may have increased myopic refractive error due to axial lengthening of the globe.
Macular edema and macular pucker may cause worsening vision several days after surgery.
After anesthetic is administered, the eye is prepared and draped in sterile fashion and a lid speculum is placed. A conjunctival peritomy is made and the conjunctiva is reflected back using forceps and Westcott scissors. A relaxing radial incision is often made at the horizontal meridians to prevent tearing of the conjunctiva. A 360° peritomy is usually made, but a smaller incision may be made if the culprit tear is localized to a single retinal quadrant. The Tenon capsule is then dissected bluntly using Stevens scissors and similarly reflected back from the insertion point of the rectus muscles. Cotton applicators or other means to bluntly push back are also frequently used. The four rectus muscles themselves are isolated with muscle hooks and secured with sling sutures (2-0 silk sutures), as shown in the image below.
The most crucial aspect of any approach to treating rhegmatogenous detachments is the ability to localize, characterize, and seal all of the retinal tears. Not locating a tear would predispose any technique to failure because it allows for the continued influx of subretinal fluid and the promotion of the detachment. The initial survey is performed through indirect ophthalmoscopy via the aid of a condensing lens (20 or 28 D). To view the peripheral retina, it is necessary to indent the sclera to bring possible breaks into the viewing field. This task becomes significantly more difficult in the setting of opaque media, such as vitreous hemorrhage or exudates. As a result, if the retina cannot be reliably visualized, the operator cannot be confident that all tears and areas of degeneration are identified. In this case, vitrectomy should be considered.
The location of the breaks may be marked on the sclera with the use of a localizer (eg, marking depressor, diathermy probe). Tears are preferentially marked at their anterior edge, which is the area with the most vitreoretinal traction that must be opposed. Care must be taken to only depress the sclera, not the shaft, with the tip of the localizer. Otherwise, false localization may result in erroneous buckling. A marking pen may be applied over the initial mark to make it visible for longer time, as shown in the image below.
When all of the breaks have been identified and marked appropriately, they may be treated with retinopexy. Retinopexy is achieved by one of three principal mechanisms:
Cryopexy, which is an external application of cold burn and the most commonly used mechanism
Laser coagulation via indirect ophthalmoscope, which is used less frequently because it only works once the retina is attached
Diathermy, which is an electrical-induced inflammatory lesion that is of limited use in current practice because of the significant risk of scleral necrosis
Cryopexy of a particular region is ceased once the ice ball is seen to involve the retina to avoid progression to necrosis.
The retinopexy applications should be contiguous surrounding the tear but not overlap considerably, as this may cause excessive damage to the tissue. There should be 1-2 mm of treatment extending past the edge of the break.
Choice of Buckle Element (Segmental or Encircling)
The explant material is made from either hard silicon rubber or silicon sponge material. These come in a variety of shapes and sizes that allow the surgeon to tailor the buckling amount and distribution of pressure to each case.
When choosing a buckling element, the primary factor is the number and location of the breaks. The patient’s phakic status, presence of glaucoma, and any comorbid diseases should also be considered.
Encircling bands are most likely to be placed in the following scenarios:
For many breaks or breaks that are scattered over more than two quadrants
When there are possible undetectable breaks
For elevated breaks with copious subretinal fluid (bullous detachments)
Where segmental buckling has previously failed
The rationale of employing an encircling approach is that it allows for numerous seen and unseen breaks to be bottled, thus preventing the intrusion of vitreous that maintains the detachment. Many surgeons prefer to use encircling buckles because of their higher success rate over segmental buckles. Encircling also favorably changes the geometry of the globe by alleviating vitreoretinal traction.
Segmental buckles should be placed in the following scenarios:
With significant pre-existing glaucoma damage to the optic nerve, for which encircling bands have more potential to elevate intraocular pressure
For patients with sickle cell disease because of an increased risk of anterior segment ischemia (although consider a vitrectomy instead of buckling)
For a small number of breaks within 1 or 2 clock hours of each other, which may be approached with radial or segmental buckles
In addition to an encircling buckle in an area where higher indentation is desired
The buckle elements are soaked in an antibiotic solution and then placed underneath the rectus muscle. Securing scleral sutures (5-0 polyester with spatulated needle) are placed parallel to the buckle with partial thickness depth. Care is taken not to perforate the globe with the suture needle, which should be spatulated. The previously placed marks localizing the tears on the sclera are used to decide where to secure the buckle.
With the buckle temporarily in place, indirect ophthalmoscopy is used to confirm the following:
Adequate placement of the buckle underneath the retinal break
The break has not fish-mouthed
The patency of the central retinal artery
It is important that the buckling element extends past the posterior edge of the break. The sutures may be released and buckle repositioned accordingly. At this juncture, the operator may decide to extend the procedure and include drainage of subretinal fluid if indicated (see images below). Depending on the size of the tears, depth of the detachment, and associated vitreoretinal pathology, the operator may choose a degree of height for the buckle or amount of indentation.
The choice of draining the subretinal fluid is an often-debated subject among retinal surgeons. It is often a matter of surgeon preference and its implementation varies widely. However, several compelling indications exist for initiating drainage:
For a highly elevated detachment due to significant fluid
When the retina is anchored to the vitreous, usually by proliferative vascular disease
For inferior detachments, in which the vitreous will pool in dependent areas and may reform the tear
When there is concern for intraocular pressure elevation in glaucomatous eyes and eyes with thin sclera
For chronic detachments, in which the subretinal fluid tends to assume more viscosity with age of detachment and its reabsorption is prolonged
If drainage is thought to be preferable, the temporarily secured buckle is loosened to allow access and drainage is performed via a sclerotomy beneath the fluid collection. This site should ideally be covered by the buckling element afterward so as to prevent egress of further fluid. The actual entry and drainage can be performed with a 27- or 30-gauge needle. Some surgeons perform the drainage while inspecting the retina through indirect ophthalmoscopy. Other surgeons prefer to do a cut-down on the sclera to reach the choroid, which is cauterized prior to draining.
Should a drainage approach be chosen, it is important to re-examine the site afterward and confirm that the retina has not become incarcerated into the drainage tract. Once adequate fluid removal occurs, some surgeons close the sclerotomy tract with suture (5-0 nylon). If the eye becomes too soft from the amount of fluid drained, restoring vitreous volume can be achieved with air, gas, or fluid.
During the course of surgery, corneal epithelial edema frequently develops from the combination of increased intraocular pressure during surgical maneuvering, or sometimes from preservatives in the wetting agents used to keep corneal clarity. By avoiding the use of wetting agents with toxic preservatives, corneal epithelial edema can be delayed and the need for epithelial debridement with a surgical blade to improve visibility can be reduced.
Once the buckle is satisfactorily created, the Tenon capsule and conjunctiva are closed with absorbable suture (polyglactin or gut). An antibiotic (typically cefazolin or vancomycin in patients with a penicillin allergy) and steroid (dexamethasone or triamcinolone) are then placed via subconjunctival injection. The eyelid speculum is removed and antibiotic ointment is placed on the exterior of eye. A temporary eye patch is placed and kept on until the patient can be examined the following day.
If a nondrainage approach is chosen, it may be necessary to counter intraocular pressure elevation via medical or surgical means (eg, anterior chamber paracentesis). This situation is more likely in cases for which encircling bands were employed, given their higher potential for volume reduction.
Significant intraocular pressure elevation may be emergently reduced by either systemic osmotic therapy with 20% mannitol or surgical paracentesis (drainage of the aqueous humor from the anterior chamber, although this only temporarily reduces the pressure).
