Pediatric Myelodysplastic Syndromes Pathology

  • Author: David Head, MD; Chief Editor: Cherie H Dunphy, MD  more...

Updated: Dec 02, 2013


Overview

Myelodysplastic syndrome (MDS) is a set of disorders characterized by marrow failure with peripheral blood cytopenias, a peculiar set of morphologic abnormalities in hematopoietic cells, increased marrow blasts in some cases, frequent characteristic cytogenetic abnormalities, and frequent progression to a subset of acute myeloid leukemia (AML).[1, 2] The incidence of MDS increases exponentially with increasing age; the median age is estimated to be in the 70s.[2, 3, 4] The image below depicts typical morphologic features that may be seen in MDS.

A = binucleate megaloblastoid erythroid precursor; A = binucleate megaloblastoid erythroid precursor; B = megaloblastoid erythroid precursor; C = small megakaryocyte with monolobate nucleus.

Adult MDS includes both low-grade, slowly progressive or nonprogressive subtypes (eg, refractory cytopenia with unilineage dysplasia [RCUD], refractory anemia with ringed sideroblasts [RARS], and 5q- syndrome), and high-grade potentially progressive and life-threatening subtypes (eg, refractory cytopenia with multilineage dysplasia [RCMD] and RA with excess blasts [RAEB]).[1, 2]

AML with background MDS (MDS-related AML or MDR-AML) is difficult to treat, being resistant to cytotoxic chemotherapy, whereas background myelodysplastic hematopoiesis is abnormally sensitive to chemotherapy. If patients with MDR-AML respond to chemotherapy, they typically revert to clonal hematopoiesis (MDS) rather than a polyclonal complete remission. MDR-AML may be preceded by overt MDS or may simply exhibit the cytogenetic changes and hematopoietic dysplasia typical of MDS. At present, MDR-AML, like MDS, is curable only with an allogeneic stem cell transplant.

MDS and MDR-AML are less common in children and young adults than in older adults and elderly persons. Nevertheless, a significant subset of pediatric myeloid disease (estimated at 10-15%) consists of MDS and MDR-AML.[5, 6, 7, 8] The low-grade nonprogressive subtypes of MDS found in older patients (especially 5q- syndrome and RARS) are rare to nonexistent in pediatric patients.

Diagnosis and correct subclassification of MDS-related entities are often difficult, but because both their treatment and their prognoses differ substantially from those of the more common de novo AML [eg, AML with t(15;17), t(8;21), inv(16), or t(9;11)], recognition of MDS and MDR-AML is critical for treatment, prognostication, and analysis of biologic and clinical studies. While these entities typically occur with no antecedent causative event, there are a known set of precipitating causes, which include alkylating agents, platinum derivatives, nitrosoureas, ionizing radiation, and benzene derivatives.

Disorders included in MDS-related diseases of childhood are:

  • MDS (refractory cytopenia of childhood [RCC], RAEB)
  • MDR-AML
  • Therapy-related MDS and AML

Historically MDS and AML in Down syndrome patients have been included in classification with MDR-disease, and they are discussed below, but given their excellent outcome with chemotherapy, their apparent single gene (GATA-1) founder mutation, and their differing morphology from other MDS disease, they should now be considered a separate entity distinct from MDS. See also Pathology of Myeloid Proliferations Related to Down Syndrome.

This discussion does not address juvenile myelomonocytic leukemia, a related disorder with mixed features of MDS and myeloproliferation.

See also the following:

Next

Epidemiology

Myelodysplastic syndrome (MDS) accounts for 10-15% of pediatric myeloid disease, after patients with Down syndrome and juvenile myelomonocytic leukemia have been excluded. Precise incidence figures have proven difficult to ascertain, in part because of diagnostic difficulties and a lack of awareness of diagnostic possibilities in general pediatric medical practice. Best estimates of the incidence of pediatric MDS are in the range of 2 cases/million/year; in comparison, the estimate for acute myeloid leukemia (AML) is 6 cases/million/year, and that of acute lymphoid leukemia (ALL) is 40/million/year.[5, 6, 7, 8]

In contrast with MDS in adults and especially elderly persons, MDS in childhood shows no sex predilection. Especially in pediatric patients, some MDS cases are related to underlying constitutional syndromes, including Fanconi anemia, Shwachman-Diamond syndrome, Kostmann syndrome, familial thrombocytopenia with mutation of AML1, dyskeratosis congenita, and following severe aplastic anemia.

Still other cases of MDS are related to therapy, occurring after treatment with cytotoxic agents that cause cross-link DNA damage (alkylating agents, platinum derivatives, nitrosoureas) or after treatment with ionizing radiation.

Previous
Next

Clinical Features

Myelodysplastic syndrome (MDS) is a marrow failure disorder of unexplained etiology, characterized typically by clonal hematopoiesis, dysplastic morphology in hematopoietic precursors, peripheral cytopenias, a set of characteristic cytogenetic abnormalities, sometimes increased myeloid blasts in marrow or peripheral blood, and normocellular to hypercellular marrow.

The predominant presenting features of MDS relate to cytopenias (ie, anemia, neutropenia, and thrombocytopenia).[1, 2] These features may be symptoms (eg, fatigue, infection, petechiae, bleeding), or they may be abnormalities identified incidentally during the evaluation of another process.

MDS-related disease may be recognized initially by its presentation as acute myeloid leukemia (AML), with morphology demonstrating hematopoietic dysplasia or with cytogenetic changes typical of MDS (eg, -7, +8, 20q-, acquired +21). Therapy-related disease may present with unexplained cytopenias, delayed recovery of counts after chemotherapy, dysplastic morphologic features or increased blasts in blood or marrow, or MDS-type cytogenetic abnormalities.

Patients with an associated constitutional syndrome typically (but not invariably) display the features of that syndrome (eg, skeletal abnormalities in Fanconi anemia or dystrophic nails in dyskeratosis congenita) in addition to features of MDS. Diagnosis of complicating MDS must be based on features that are not directly attributable to the underlying syndrome. For example, features of marrow failure cannot be used as corroborative evidence of MDS in a disease setting that already includes marrow failure, such as Fanconi anemia.

Previous
Next

Morphologic Features

The dysplastic morphologic features of pediatric myelodysplastic syndrome (MDS) are identical to those of adult disease (see the images below), with one important exception[1, 2] ; ringed sideroblasts are rare in pediatric MDS; if they are seen, diagnosis of Pearson syndrome should be considered.[9] The marrow is typically normocellular to hypercellular, but hypocellular MDS is more common in pediatric than in adult patients. None of these features is specific for MDS, nor are they completely sensitive for diagnosis of MDS. Similar morphologic abnormalities are seen in megaloblastic processes, and individual features are seen in a variety of other processes.

A = binucleate megaloblastoid erythroid precursor; A = binucleate megaloblastoid erythroid precursor; B = megaloblastoid erythroid precursor; C = small megakaryocyte with monolobate nucleus.
A = multinucleate erythroid precursor; B = binucle A = multinucleate erythroid precursor; B = binucleate megaloblastoid erythroid precursor; C = dysplastic erythroid nuclei.
A = vacuolated erythroblasts; B = hypogranular ban A = vacuolated erythroblasts; B = hypogranular band.
Internuclear bridge between erythroid precursors ( Internuclear bridge between erythroid precursors (arrow).
Hypogranular Pelger-Huet neutrophils and dimorphic Hypogranular Pelger-Huet neutrophils and dimorphic hypochromic and normochromic red blood cells.
Micromegakaryocytes with single or multiple, small Micromegakaryocytes with single or multiple, small, round nuclei.

Common erythroid abnormalities in pediatric MDS are as follows:

  • Blood: Bimodal red blood cell (RBC) distribution, anisocytosis and poikilocytosis (A&P), basophilic stippling, siderocytes, dysplastic features in circulating precursors
  • Marrow: Cloverleaf nuclei, megaloblastoid change, multinucleation, vacuolization, periodic acid-Schiff (PAS) positivity, and internuclear bridging (INB); while INB is characteristic of congenital dyserythropoietic anemia (CDA)-1, it is also seen occasionally in MDS, and, given the rarity of CDA-1, INB is seen considerably more frequently in MDS; the ringed sideroblasts seen frequently in adult MDS are not seen in pediatric MDS

Common myeloid abnormalities are as follows:

  • Blood: Pelger-Huet anomaly, hypogranulation, hypersegmentation, blasts
  • Marrow: Increased blasts, nucleocytoplasmic asynchrony (immature/blastic nucleus in a cell with differentiating cytoplasm), hypogranulation, myeloperoxidase deficiency, abnormal localization of immature precursors (ALIP) (location of immature myeloid precursors away from boney trabeculae in biopsy sections). Blasts are usually myeloid but may have megakaryoblastic or erythroid differentiation, or may be present in mixed populations. The blast percentage in both blood and marrow should be quantified in Wright-Giemsa stained smears, not by flow cytometry or immunohistochemistry on tissue sections.

Common platelet-megakaryocytic abnormalities include the following:

  • Blood: Large, agranular, or vacuolated platelets
  • Marrow: Small mononuclear megakaryocytes; large megakaryocytes with multiple small nuclei, intermediate-sized megakaryocytes with monolobate nuclei, or large megakaryocytes with hyperchromatic nuclei

Some patients with MDS have mild-to-moderate marrow fibrosis, compromising preparation of air-dried, Romanowsky-stained smears. Most morphologic features in marrow in MDS are difficult to assess with hematoxylin and eosin (H&E)–stained sections. Wright-Giemsa–stained touch preps may be very useful in this setting, and should be prepared with every biopsy. Reticulin staining is helpful to verify and quantify fibrosis.

Previous
Next

Immunophenotypic Features and Methods

There are no specific immunophenotypic features of myelodysplastic syndrome (MDS) with current routine clinical flow cytometry. However, flow cytometry of marrow is useful to separate hematogones (early B precursors, which may spuriously raise the total blast percentage) from myeloid blasts. Flow is also useful for characterization of blasts and for evaluation of T/NK-cell subsets (to rule out large granular lymphocyte [LGL] syndrome, which may mimic some features of MDS). Of note, the blast percentage in blood and marrow should be quantitated by Wright-Giemsa morphology in smears, not by flow cytometry.

With an expanded antibody panel, flow cytometry may demonstrate abnormal differentiation patterns or aberrant antigen expression in myeloid, monocytic, and erythroid elements.[10, 11, 12, 13, 14] Identification of such abnormalities involves use of a larger panel of differentiation antigens than current clinical practice, and it requires a level of expertise in both performance and interpretation for recognition of abnormalities. Although such usage is not yet widespread, this testing is anticipated to become an important adjunct to diagnosis of MDS.

Immunohistochemistry has limited applicability to the diagnosis of MDS. Myeloperoxidase (MPO) or CD117 staining may help demonstrate abnormal localization of immature precursors (ALIPs). CD34 and CD117 may help quantify blasts in difficult cases, but the actual blast percentage should be based on Wright-Giemsa–stained smears. CD41/CD61 are useful for identification of small megakaryocytes and megakaryoblasts. Glycophorin A and E-cadherin are useful for identifying erythroid precursors, and together with MPO and CD41/CD61 are useful for assessing hematopoiesis in tissue sections.

Previous
Next

Molecular/Genetic Features and Methods

Karyotypic analysis of marrow is essential for evaluation of myelodysplastic syndrome (MDS). A large set of cytogenetic abnormalities are found with varying frequency in MDS, most consisting of gain or loss of large segments of chromosomal material. The most common abnormalities in children are -7/7q-, +8, 20q-, and acquired +21. One of the most common abnormalities in adult MDS, 5q-/-5, is virtually absent in pediatric MDS.[2, 15, 16] The molecular biologic correlates of these various cytogenetic abnormalities remain unknown.

A small set of recurring translocations are found uncommonly in MDS. These include inv3(q21q26), t(3;3)(q21;q26), t(1;7), t(2;11), t(11;16), t(3;21), and other 3q abnormalities; some associated molecular abnormalities have been identified.[1, 2, 17, 18] Translocations involving 3q26 up-regulate EVI-1, a competitive inhibitor of GATA-1; GATA-1 is required for differentiation of erythroid and megakaryocytic precursors. Translocations at 11q23 disrupt MLL (HRX), a transcription factor that regulates maturation of hematopoietic progenitors. Translocations at 21q22 disrupt AML1 (RUNX1,CBFa2), a transcription factor that regulates maturation of hematopoietic progenitors.

Most importantly, the common balanced translocations typical of pediatric and young adult AML [t(15;17), t(8;21), inv(16) or t(16;16), t(9;11), t(11;17), t(11;19), t(8;16)] are not found in, and eliminate diagnosis of, MDS-related disease.[19]

Fluorescence in situ hybridization (FISH) analysis for the common abnormalities of MDS is not helpful at diagnosis, as significant abnormalities are observed in the karyotype. If abnormalities are observed in the karyotype, FISH may be added for specific abnormalities to establish a baseline, as FISH may be helpful for follow up to quantify residual disease. Screening for Fanconi anemia with a diepoxybutane (DEB) challenge is recommended, and molecular testing for the genetic abnormalities of specific syndromes (eg, dyskeratosis congenita, Shwachman-Diamond syndrome, and Fanconi anemia) may be considered.

Previous
Next

Diagnosis and Classification

Parameters routinely used to diagnose myelodysplastic syndrome (MDS) are peripheral blood cytopenias, dysplasia, genetic/cytogenetic abnormalities, and blasts in peripheral blood or increased blasts in marrow.[6]

Diagnosis is frequently problematic in that none of these parameters is completely sensitive or specific for this purpose. Peripheral blood cytopenias have myriad causes, as do peripheral blood and marrow dysplasia. Cytogenetic abnormalities similar to those of MDS may appear transiently in other settings, including megaloblastic processes, aplastic anemia, and Fanconi anemia. Monosomy 7 unrelated to any of these settings may be present transiently, regressing spontaneously or with treatment (eg, folate or vitamin B-12 replacement). At least in patients with therapy-related MDS—and presumably, by extension, in other MDS patients—any of these parameters may be lacking, including dysplastic morphology and cytopenias.

Because of these limitations, better methods of diagnosis are needed, but until such methods become available, at least 2 of the 4 cited parameters (unexplained cytopenias, multilineage dysplasia, cytogenetic abnormalities, and increased blasts) should be present to provide some certainty of the diagnosis of MDS.[6]

Parameters used for diagnosis should be unrelated to any underlying preexisting condition (eg, cytopenias in aplastic anemia or Fanconi anemia). A careful analysis to rule out other possible causes of abnormalities is always warranted. As a rule, definitive diagnosis should be deferred until abnormalities are shown to be sustained over several months.

Pediatric MDS comprises a more limited set of diseases than MDS in older patients.[2, 6, 16] In older patients, multiple subtypes of MDS are divisible into 2 broad groups: (1) low-grade disease with little tendency to progress to higher-grade disease (MDS or AML) and (2) high-grade disease with a strong tendency to progress. Low-grade MDS in older patients includes refractory cytopenia with unilineage dysplasia (RCUD), refractory anemia with ringed sideroblasts (RARS), and 5q- syndrome. High-grade MDS in older patients includes refractory cytopenia with multilineage dysplasia (RCMD), RA with excess blasts (RAEB) (subgroups -1 and -2), and therapy-related MDS.

The low-grade MDS subtypes of adults are rare in pediatric patients, and the clinical utility of separating adult RAEB into subgroups on the basis of blast percentages has not been established for pediatric disease. Thus, in practice, only 3 MDS categories are used in pediatric patients: Refractory cytopenia of childhood (RCC, corresponding approximately to RCMD in adults), RAEB, and therapy-related MDS.

Criteria for these 3 subtypes are essentially the same as for the corresponding conditions in adults. RCC should have unexplained cytopenias (anemia, neutropenia, and/or thrombocytopenia), with no increase in blasts in marrow and only rare blasts in peripheral blood. RAEB is similar but with increased blasts in marrow or blood. Therapy-related MDS requires a history of appropriate chemotherapy or ionizing radiation.

Both RCC and RAEB in childhood may follow prolonged courses with little progression of cytopenias or blast percentage over months (RAEB) to years (RCC); therefore, a period of follow up with repeat marrow examination may be prudent before undertaking aggressive treatment such as stem cell transplantation in these patients. Similarly, patients diagnosed as MDR-AML with a relatively low blast percentage (20-30%) may follow a relatively indolent course, similar to RAEB; as with RAEB, a period of follow up may be helpful to define the patient's disease course.

Refractory anemia with excess blasts vs MDS-related AML

Distinguishing between RAEB and MDS-related AML (MDR-AML) is often problematic, and, as noted in the previous paragraph, may be more semantic than biological.[2] This distinction has been based on the progression of blasts beyond a threshold of 20% (historically 30%) of marrow elements, but this approach is simplistic. The intent of a diagnosis of AML is to inform the clinician that the patient has a proliferative disease that may respond to aggressive cytotoxic chemotherapy. However, blasts per se do not prove proliferation, only a lack of differentiation. Blastic chromatin indicates DNA dissociation from histones. For example, blastic chromatin is found in cells with nucleocytoplasmic asynchrony, in which nuclei look blastic but cytoplasmic maturation disproves a significant mitotic rate. Knockout of an appropriate histone deacetylase also results in blastic dissociated chromatin without proliferation.

As noted previously, patients with blasts in the 20-30% range or even higher may have a clinical picture of marrow failure (MDS) rather than progressive tumor burden (AML). Either situation is potentially life threatening, but optimal treatment may differ. Marrow failure patients tend to respond poorly to cytotoxic chemotherapy, which is also virtually never curative. In contrast, proliferating blasts in this setting may respond to chemotherapy, albeit with prolonged cytopenias in many cases because of the sensitivity of background hematopoiesis (MDS); if the chemotherapy is effective, patients typically revert to clonal hematopoiesis (MDS) rather than normal hematopoiesis.

Which pattern of disease a given patient will follow (ie, predominant marrow failure or proliferation) cannot usually be discerned with a single marrow examination. If possible, definitive diagnosis should be delayed for several weeks, with a repeat marrow examination to clarify the patient's course. In patients with a high blast percentage at presentation, diagnosis of MDR-AML is justified.

Therapy-related MDS/MDR-AML versus other therapy-related leukemia syndromes

In the appropriate clinical setting (history of alkylating agent, platinum derivative, or ionizing radiation exposure), diagnosis of therapy-related MDS is based on the presence of prolonged cytopenias after chemotherapy or the onset of cytopenias unrelated to chemotherapy, the appearance of MDS-related cytogenetic abnormalities, dysplastic changes in hematopoietic cells, and/or increased myeloid blasts.[2] If the blast count exceeds 20%, diagnosis of therapy-related MDR-AML is warranted. Patients initially may have only a single feature (eg, monosomy 7 in a marrow sample or unexpectedly prolonged cytopenias after chemotherapy). Dysplastic morphology or increased blasts may be lacking.

Distinction should be made between therapy-related MDS/MDR-AML and 2 other therapy-related leukemia syndromes. Epipodophyllotoxin chemotherapy causes translocations involving the MLL gene at 11q23 and, to a lesser extent, the AML1 gene at 21q22.[20] Therapy-related leukemia with an MLL translocation includes acute lymphoid leukemia (ALL) and AML. Complex therapy including all of the above noted agents plus other chemotherapy (eg, anthracyclines) also causes an increased incidence of AML, with each of the balanced translocations found in AML [eg, t(15;17), t(8;21) or inv(16)]; although the incidence of this complication is not as high as those of the previous 2 syndromes, it is several logs higher than that in the general population.[21] Neither of these latter 2 syndromes is related to MDS.

Previous
Next

Differential Diagnosis

Accurate diagnosis of myelodysplastic syndrome (MDS) is imperative, given the progressive course of disease, the drastic intervention (stem cell transplantation) needed for curative treatment, and the possible serious consequences of other diseases in the MDS differential.

The differential diagnosis of MDS is extensive. Major considerations in childhood are constitutional syndromes (Kostmann syndrome, Shwachman-Diamond syndrome, Fanconi anemia, dyskeratosis congenita, congenital dyserythropoietic anemias, Pearson syndrome and other congenital sideroblastic processes, constitutional megaloblastic anemias, familial thrombocytopenia with AML1 mutation, rare others).

Other major considerations include chronic viral infection (Epstein-Barr virus [EBV], human immunodeficiency virus [HIV], parvovirus B-19, cytomegalovirus [CMV]), folate deficiency, copper deficiency, aplastic anemia, and de novo acute myeloid leukemia (AML) with a recurring balanced translocation [eg, t(8;21)] but a low marrow blast percentage.

Recognition of many of these entities requires only appropriate testing: antibody titers, vitamin and copper levels, and cytogenetic analysis. As discussed earlier, the presence of ringed sideroblasts should suggest a cause other than MDS.

Constitutional syndromes versus MDS

Distinguishing MDS from some of the cited constitutional syndromes may be particularly problematic. These syndromes not only mimic MDS clinically and morphologically, but also may progress to MDS and MDR-AML (eg, Kostmann syndrome, Shwachman-Diamond syndrome, Fanconi anemia, dyskeratosis congenita, familial thrombocytopenia).

Diagnosis of each syndrome is beyond the scope of this article. However, some patients do not present until later in life (eg, patients with mild Fanconi anemia and dyskeratosis congenita) and may be first recognized at the time of progression to MDS or AML. Recognition of the progression of a syndrome to MDS should be based on appearance of at least 2 of the 4 abnormalities stated previously (unexplained cytopenias, dysplasia, clonal cytogenetic abnormalities, increased blasts) that are not directly attributable to the underlying syndrome.[6]

It is important to note again that unsustained clonal cytogenetic abnormalities unrelated to progression to MDS have been reported in some of these entities.

Aplastic anemia versus hypocellular MDS

Distinguishing aplastic anemia from hypocellular MDS may be difficult. As many as 15% of cases of severe aplastic anemia progress over time to MDS or MDR-AML, typically a late complication in long-term survivors.

The interrelationship of MDS and aplastic anemia is poorly understood. Some low-grade cases of MDS respond to immunosuppression, like aplastic anemia, and both aplastic anemia and MDS may have a paroxysmal nocturnal hemoglobinuria (PNH) clone, another interrelationship that is poorly understood. Aplastic anemia may have transient clonal cytogenetic abnormalities similar to those of MDS; if sustained, they suggest progression to MDS. Aplastic anemia generally lacks significant dysplastic morphology, although minor dysplastic changes may be present. Presence of sustained increased blasts suggests progression to MDS.

Previous
Next

Prognosis and Predictive Factors

While some cases of pediatric myelodysplastic syndrome (MDS) may follow a stable or slowly progressive course, the long-term prognosis is generally poor, whether due to cytopenias or progression to AML. The International Prognostic Scoring System (IPSS) for MDS has not proven useful in pediatric MDS.[6, 22, 23] Some evidence suggests that the rate of disease progression in pediatric disease may vary with specific cytogenetic abnormalities.[24] The most frequent abnormalities, monosomy 7 and complex abnormalities, follow an aggressive course with poor survival without treatment. Patients with trisomy 8 are infrequent, but some data suggest they may experience slower progression of disease.[24] Some patients may benefit from immunosuppression, similar to aplastic anemia.

Nevertheless, the only current curative option is allogeneic stem cell transplantation. Aggressive cytotoxic chemotherapy is virtually never curative in this setting and may induce prolonged, life-threatening cytopenias. Alternative approaches, such as demethylating agents (azacytidine, decitabine) and the thalidomide analogue lenalidomide, are not curative, the side effects of long-term treatment (which must be determined before use in a child) are unknown, and extended therapy may be prohibitively expensive.

Even allogeneic stem cell transplantation, with its attendant treatment-related morbidity and mortality, has a high relapse rate. If MDS progresses to MDR-AML, the leukemia tends to be resistant to chemotherapy; primary drug resistance, prolonged therapy-related cytopenias, and short clonal remissions are seen. As with MDS, the only curative treatment is allogeneic stem cell transplantation.

Previous
Next

Myeloid Diseases in Down Syndrome

Transient myeloproliferative disorder

As many as 10% of children with Down syndrome experience a leukemoid reaction in the neonatal period. This reaction is referred to as transient myeloproliferative disorder (TMD) or transient abnormal myelopoiesis, among other names.[25, 26] TMD may also occur in phenotypically and cytogenetically normal children with so-called mosaic Down syndrome, usually corresponding to +21 confined to a hematopoietic clone with normal constitutional cytogenetics.

TMD is characterized by a leukemoid peripheral blood picture with leukocytosis, multilineage immature precursors with dysplastic features, and variable numbers of blasts. The number of circulating blasts may suggest a diagnosis of AML if the overall clinicopathologic setting is not recognized. The patient may be anemic or thrombocytopenic.

Marrow examination shows similar features, with multilineage dysplasia; blasts may be less prominent than in peripheral blood. Blasts often have morphologic and immunophenotypic features of megakaryoblasts: basophilic cytoplasm, surface blebs, binucleation or multinucleation, a tendency to clustering, and positivity for CD41/CD61 by flow or immunohistochemical analysis.

The course of TMD is self-limited, resolving to normal hematopoiesis over 1 to several months. Nevertheless, if the leukemoid reaction or the cytopenias are marked, they may cause life-threatening complications that necessitate intervention. In addition to +21, the abnormal clone in TMD has a loss-of-function mutation of GATA-1, and about one third of patients with TMD develop myelodysplastic syndrome (MDS) and AML over the ensuing 3 years, with features of acute megakaryoblastic leukemia, background dysplasia, and the same GATA-1 mutation as with TMD.[27, 28]

MDS and MDR-AML in Down syndrome

The incidence of MDS and AML in Down syndrome before age 3 years is 1-2%, 3-4 logs greater than that in nonaffected children.[29] The AML has MDS-related features. Patients may follow a progressive course through MDS to AML, although the pre-AML stages are not always documented.

Whereas MDS and MDR-AML in Down syndrome are combined as a single entity in the current World Health Organization (WHO) classification of hematopoietic malignancies, it is useful to distinguish the 2 morphologically and clinically.[30] The morphologic features of each stage are similar to those of disease in non-Down syndrome children and adults, with notable exceptions. Dysplastic features are restricted to erythroid and megakaryocytic lineages, with little to no myeloid dysplasia. Megakaryocytic dysplasia is unique, with a frequent large central eosinophilic inclusion and peripherally displaced nuclei, often forming a ring resembling a Touton giant cell. See the images below.

Bone marrow section, hematoxylin and eosin. Note m Bone marrow section, hematoxylin and eosin. Note megakaryocytes (arrows) with peripheral ring of nuclei (resembling Touton giant cells) and central eosinophilic inclusions displacing nuclei.
Bone marrow aspirate, Wright-Giemsa. Note megakary Bone marrow aspirate, Wright-Giemsa. Note megakaryocyte with central mass displacing nuclei peripherally.

The blasts usually have megakaryoblastic features, although erythroblastic or mixed differentiation is also seen. The common myeloid or monocytic differentiation of AML in other settings is not seen in Down syndrome. Possibly in connection with the megakaryoblastic features, patients often have mild-to-modest marrow reticulin fibrosis, impeding aspiration of a good marrow sample for evaluation.

In addition to +21, the abnormal clone usually has a GATA-1 loss-of-function mutation, and if there was preceding TMD, the GATA-1 mutation is identical.[27, 28] GATA-1 is necessary for normal maturation of erythroids and megakaryocytes. This may explain the predominance of megakaryoblastic and erythroid differentiation of blasts in both TMD and MDS/AML of Down syndrome, and limitation of dysplasia to the same lineages.

Although the relationship of TMD to subsequent MDS and AML remains conjectural, a plausible explanation is that the loss-of-function GATA-1 mutation in TMD prevents maturation of a clone of cells being driven to proliferate by a physiologic cytokine storm in the neonatal period. As the cytokines recede over time, the attendant TMD resolves. The patient retains the GATA-1 mutation in a hematopoietic stem cell and is at later risk to progress to AML if a genetic drive to proliferate is acquired by subsequent mutation in the GATA-1 clone. Presence of the GATA-1 mutation in both TMD and subsequent MDS/AML suggests that it is the founder mutation of the disease process.

Notably, both MDS and MDR-AML before age 3 years in patients with Down syndrome respond favorably to chemotherapy, uniquely among MDS-related diseases, and better than AML in the general pediatric population. Treatment is equally effective whether provided at the stage of MDS or after progression to MDR-AML, and patients may be treated before progression to overt AML. Given this excellent outcome, the presence of an apparent single gene founder mutation (GATA-1) and unique morphology versus other MDS-related disease, Down syndrome appears to be a unique entity that should be distinguished and separated from the rest of MDS-related diseases.

Previous
Next

Additional Resources

For more information of myelodysplastic syndromes (MDS), consult the following references:

  • Head DR, Hamilton K. The myelodysplastic syndromes. In: Jaffe ES, Harris NL, Vardiman JW, Campo E, Arber DA, eds. Hematopathology. Philadelphia, Pa: Saunders; 2010.
  • Head DR, Thompson MA. Diagnosis and classification of the acute myeloid leukemias.. In: Estey EH, Faderl SH, Kantarjian HM, eds. Hematologic Malignancies: Acute Leukemias. Berlin, Germany: Springer; 2008:21-46. [Includes discussion of the role of the MDS in acute myeloid leukemia (AML) pathogenesis.]
Previous

Contributor Information and Disclosures
Author

David Head, MD Professor of Pathology, Vanderbilt University School of Medicine

David Head, MD is a member of the following medical societies: American Association for the Advancement of Science, American Society of Hematology, United States and Canadian Academy of Pathology, Society for Hematopathology, European Association for Haematopathology

Disclosure: Nothing to disclose.

Coauthor(s)

Kelley J Mast, MD Surgical Pathology Fellow, Department of Pathology, Microbiology and Immunology, Vanderbilt University Medical Center

Kelley J Mast, MD is a member of the following medical societies: College of American Pathologists, United States and Canadian Academy of Pathology

Disclosure: Nothing to disclose.

Chief Editor

Cherie H Dunphy, MD FCAP, FASCP, Professor of Pathology and Laboratory Medicine, Diector of Hematopathology and Hematopathology Fellowship, Associate Director, Core, Flow Cytometry, and Special Procedures Laboratories, Department of Pathology and Laboratory Medicine, University of North Carolina at Chapel Hill School of Medicine

Cherie H Dunphy, MD is a member of the following medical societies: American Society for Clinical Pathology, College of American Pathologists, International Academy of Pathology, North Carolina Medical Society, Children's Oncology Group

Disclosure: Nothing to disclose.

References
  1. Brunning RDAO, Germing U, Le Beau MM, et al. Myelodysplastic syndromes/neoplasms, overview. Swerdlow SH, Campo E, Harris NL, et al, eds. WHO Classification of Tumours of Haematopoietic and Lymphoid Tissues. 4th ed. Lyon, France: International Agency for Research on Cancer; 2008. 88-93.

  2. Head DR. Diagnosis and classification of the acute leukemias and myelodysplastic syndrome. Greer JP, Foerster J, Rodgers GM, Paraskevas, et al, eds. Wintrobe's Clinical Hematology. 12th ed. Philadelphia, Pa: Lippincott Williams and Wilkins; 2009. 1808-19.

  3. Aul C, Gattermann N, Schneider W. Age-related incidence and other epidemiological aspects of myelodysplastic syndromes. Br J Haematol. 1992 Oct. 82(2):358-67. [Medline].

  4. Rådlund A, Thiede T, Hansen S, Carlsson M, Engquist L. Incidence of myelodysplastic syndromes in a Swedish population. Eur J Haematol. 1995 Mar. 54(3):153-6. [Medline].

  5. Hasle H, Kerndrup G, Jacobsen BB. Childhood myelodysplastic syndrome in Denmark: incidence and predisposing conditions. Leukemia. 1995 Sep. 9(9):1569-72. [Medline].

  6. Hasle H, Niemeyer CM, Chessells JM, Baumann I, Bennett JM, Kerndrup G, et al. A pediatric approach to the WHO classification of myelodysplastic and myeloproliferative diseases. Leukemia. 2003 Feb. 17(2):277-82. [Medline].

  7. Hasle H, Wadsworth LD, Massing BG, McBride M, Schultz KR. A population-based study of childhood myelodysplastic syndrome in British Columbia, Canada. Br J Haematol. 1999 Sep. 106(4):1027-32. [Medline].

  8. Niemeyer CM, Baumann I. Myelodysplastic syndrome in children and adolescents. Semin Hematol. 2008 Jan. 45(1):60-70. [Medline].

  9. Chan GC, Head DR, Wang WC. Refractory anemia with ringed sideroblasts in children: two diseases with a similar phenotype?. J Pediatr Hematol Oncol. 1999 Sep-Oct. 21(5):418-23. [Medline].

  10. Karmon Y, Manaster J, Chezar J. Immunophenotypic characterization of myelopoiesis in early and late myelodysplastic syndromes: use of CD44 as an aid in early diagnosis. Cytometry. 2002 Aug 15. 50(4):225-30. [Medline].

  11. Kern W, Haferlach C, Schnittger S, Haferlach T. Clinical utility of multiparameter flow cytometry in the diagnosis of 1013 patients with suspected myelodysplastic syndrome: correlation to cytomorphology, cytogenetics, and clinical data. Cancer. 2010 Oct 1. 116(19):4549-63. [Medline].

  12. Miller DT, Stelzer GT. Contributions of flow cytometry to the analysis of the myelodysplastic syndrome. Clin Lab Med. 2001 Dec. 21(4):811-28. [Medline].

  13. Stetler-Stevenson M, Arthur DC, Jabbour N, Xie XY, Molldrem J, Barrett AJ, et al. Diagnostic utility of flow cytometric immunophenotyping in myelodysplastic syndrome. Blood. 2001 Aug 15. 98(4):979-87. [Medline].

  14. Wells DA, Benesch M, Loken MR, Vallejo C, Myerson D, Leisenring WM, et al. Myeloid and monocytic dyspoiesis as determined by flow cytometric scoring in myelodysplastic syndrome correlates with the IPSS and with outcome after hematopoietic stem cell transplantation. Blood. 2003 Jul 1. 102(1):394-403. [Medline].

  15. Antillón F, Raimondi SC, Fairman J, Liang H, Nagarajan L, Head D, et al. 5q- in a child with refractory anemia with excess blasts: similarities to 5q- syndrome in adults. Cancer Genet Cytogenet. 1998 Sep. 105(2):119-22. [Medline].

  16. Baumann I NC, Bennett JM, Shannon K. Childhood myelodysplastic syndrome. Swerdlow SH, Campo E, Harris NL, et al, eds. WHO Classification of Tumours of Haematopoietic and Lymphoid Tissues. 4th ed. Lyon, France: International Agency for Research on Cancer; 2008. 104-7.

  17. Morishita K, Parganas E, William CL, Whittaker MH, Drabkin H, Oval J, et al. Activation of EVI1 gene expression in human acute myelogenous leukemias by translocations spanning 300-400 kilobases on chromosome band 3q26. Proc Natl Acad Sci U S A. 1992 May 1. 89(9):3937-41. [Medline]. [Full Text].

  18. Olney HJ, LeBeau MM. The cytogenetics and molecular biology of the myelodysplastic syndromes. Bennett JM, ed. The Myelodysplastic Syndromes: Pathobiology and Clinical Management. New York, NY: Marcel Dekker, Inc; 2002. 89-119.

  19. Chan GC, Wang WC, Raimondi SC, Behm FG, Krance RA, Chen G, et al. Myelodysplastic syndrome in children: differentiation from acute myeloid leukemia with a low blast count. Leukemia. 1997 Feb. 11(2):206-11. [Medline].

  20. Pui CH, Ribeiro RC, Hancock ML, Rivera GK, Evans WE, Raimondi SC, et al. Acute myeloid leukemia in children treated with epipodophyllotoxins for acute lymphoblastic leukemia. N Engl J Med. 1991 Dec 12. 325(24):1682-7. [Medline].

  21. Sandoval C, Pui CH, Bowman LC, Heaton D, Hurwitz CA, Raimondi SC, et al. Secondary acute myeloid leukemia in children previously treated with alkylating agents, intercalating topoisomerase II inhibitors, and irradiation. J Clin Oncol. 1993 Jun. 11(6):1039-45. [Medline].

  22. Greenberg P, Cox C, LeBeau MM, Fenaux P, Morel P, Sanz G, et al. International scoring system for evaluating prognosis in myelodysplastic syndromes. Blood. 1997 Mar 15. 89(6):2079-88. [Medline].

  23. Hasle H, Baumann I, Bergsträsser E, Fenu S, Fischer A, Kardos G, et al. The International Prognostic Scoring System (IPSS) for childhood myelodysplastic syndrome (MDS) and juvenile myelomonocytic leukemia (JMML). Leukemia. 2004 Dec. 18(12):2008-14. [Medline].

  24. Kardos G, Baumann I, Passmore SJ, Locatelli F, Hasle H, Schultz KR, et al. Refractory anemia in childhood: a retrospective analysis of 67 patients with particular reference to monosomy 7. Blood. 2003 Sep 15. 102(6):1997-2003. [Medline].

  25. Brink DS. Transient leukemia (transient myeloproliferative disorder, transient abnormal myelopoiesis) of Down syndrome. Adv Anat Pathol. 2006 Sep. 13(5):256-62. [Medline].

  26. Massey GV, Zipursky A, Chang MN, Doyle JJ, Nasim S, Taub JW, et al. A prospective study of the natural history of transient leukemia (TL) in neonates with Down syndrome (DS): Children's Oncology Group (COG) study POG-9481. Blood. 2006 Jun 15. 107(12):4606-13. [Medline].

  27. Greene ME, Mundschau G, Wechsler J, McDevitt M, Gamis A, Karp J, et al. Mutations in GATA1 in both transient myeloproliferative disorder and acute megakaryoblastic leukemia of Down syndrome. Blood Cells Mol Dis. 2003 Nov-Dec. 31(3):351-6. [Medline].

  28. Hitzler JK, Cheung J, Li Y, Scherer SW, Zipursky A. GATA1 mutations in transient leukemia and acute megakaryoblastic leukemia of Down syndrome. Blood. 2003 Jun 1. 101(11):4301-4. [Medline].

  29. Fong CT, Brodeur GM. Down's syndrome and leukemia: epidemiology, genetics, cytogenetics and mechanisms of leukemogenesis. Cancer Genet Cytogenet. 1987 Sep. 28(1):55-76. [Medline].

  30. Baumann I, Niemeyer CM, Brunning RD, Arber DA, Prowit A. Myeloid proliferations related to Down syndrome. SH, Campo E, Harris NL, et al, eds. WHO Classification of Tumours of Haematopoietic and Lymphoid Tissues. 4th ed. Lyon, France: International Agency for Research on Cancer; 2008. 142-4.


Previous
Next

A = binucleate megaloblastoid erythroid precursor; B = megaloblastoid erythroid precursor; C = small megakaryocyte with monolobate nucleus.
A = multinucleate erythroid precursor; B = binucleate megaloblastoid erythroid precursor; C = dysplastic erythroid nuclei.
A = vacuolated erythroblasts; B = hypogranular band.
Internuclear bridge between erythroid precursors (arrow).
Hypogranular Pelger-Huet neutrophils and dimorphic hypochromic and normochromic red blood cells.
Micromegakaryocytes with single or multiple, small, round nuclei.
Bone marrow section, hematoxylin and eosin. Note megakaryocytes (arrows) with peripheral ring of nuclei (resembling Touton giant cells) and central eosinophilic inclusions displacing nuclei.
Bone marrow aspirate, Wright-Giemsa. Note megakaryocyte with central mass displacing nuclei peripherally.
