Light Chain-Associated Renal Disorders Workup

  • Author: Malvinder S Parmar, MB, MS; Chief Editor: Vecihi Batuman, MD, FACP, FASN  more...

Updated: Nov 21, 2015


Laboratory Studies

Urinalysis

Urinalysis results may indicate low-grade proteinuria. A discrepancy between the results of a urine dipstick test for protein and the findings from a test for 24-hour urine protein excretion should suggest the possibility of light-chain proteinuria. Light-chain proteins in the urine cannot be detected using Albustix or other dipstick methods.

Perform the Putnam heat test or the sulfosalicylic acid (SSA) test (with Exton reagent) to help detect urinary light-chain proteins. The results from either test are insensitive. The Putnam heat test can help detect urinary light chains only when the concentration exceeds 150 mg/dL. False-negative results are common with the SSA test if the specific gravity of urine is less than 1.01.

If a patient has a negative result from the Albustix test (which detects albumin) and a positive result from the SSA test, consider the possibility of light-chain proteinuria.

Urine immunoelectrophoresis

Light-chain proteins are best detected and identified using immunoelectrophoresis with monospecific antikappa and antilambda sera.

CBC count

Anemia may be present in patients with multiple myeloma.

Serum electrolytes and serum bicarbonate with anion gap calculation

Because of the cationic charge of paraproteins, the level of this serum chloride is slightly elevated and the anion gap (see the Anion Gap calculator) is lower than normal.

Peripheral smear

Rouleaux formation is observed in patients with multiple myeloma and Waldenström macroglobulinemia.

Serum calcium

Hypercalcemia may be present in patients with multiple myeloma.

Serum protein electrophoresis and immunoelectrophoresis

These can be used to evaluate and quantitate the abnormal monoclonal spike.

Serum free-light chain (FLC, Freelite) assay

Free light chains (FLC, quantitative assay) have been shown to be sensitive and specific for various light chain–associated disorders. In 110 patients with amyloidosis, the FLC kappa/lambda ratio was positive in 91% of patients (compared with 69% of patients) for serum immunofixation (IFE) and in 83% of patients for urine IFE.[9] The combination of serum IFE and serum FLC detected an abnormal result in 99% of patients. Serum free light assay is mainly helpful in monitoring response to therapy.[10] In some patients with negative serum and urine electrophoresis for monoclonal protein, serum free light chain was helpful in establishing diagnosis.[11]

Serum electrolytes, including serum bicarbonate

Patients with tubular dysfunction may present with low or normal anion gap metabolic acidosis.

Urine for glucose

Glucosuria may be observed in the absence of hyperglycemia.

Nephrotic-range proteinuria

This may be present in patients with AL amyloidosis.

Serum albumin

Hypoalbuminemia and a reversal of the albumin-globulin ratio may be present.

Erythrocyte sedimentation rate

This is often significantly elevated in patients with myeloma.

Hepatic profile

A moderate degree of liver dysfunction may be observed because of the deposition of light chains in the liver or other organs.

Next

Imaging Studies

Renal ultrasound

Renal ultrasound images can help assess renal echogenicity and renal size in patients presenting with renal failure. Findings can also help to rule out renal calcification or stones. One third of the patients may have enlarged kidneys.

Skeletal survey

Results may show lytic bone lesions, osteoporosis, or compression fracture(s) in patients with possible multiple myeloma.

Previous
Next

Procedures

Findings from bone marrow aspiration and biopsy can be used to assess plasma cell infiltration.

Kidney biopsy is not mandatory, but it is useful when causes of renal failure other than myeloma are under consideration.

When AL amyloidosis is suggested, consider performing a biopsy on the affected tissue. The diagnostic yield of various tissue biopsies is as follows:

  • Kidney or liver biopsy - Greater than 90%
  • Abdominal fat pad biopsy - 85%
  • Rectal biopsy - 50-80%
  • Gingival biopsy - 60%
  • Skin biopsy - 58%
Previous
Next

Histologic Findings

Light chain–induced tubular dysfunction (Fanconi syndrome)

Needlelike crystals may be seen in renal tubular epithelial cells of some patients with light-chain proteinuria and Fanconi syndrome.

Classic myeloma kidney (cast nephropathy)

This condition is characterized by eosinophilic, dense, homogeneous casts that are often fractured or laminated and are partially surrounded by multinucleated foreign body–type giant cells. Congo red–positive casts have been reported in a few cases. Intratubular light chains apparently may undergo alteration in situ, resulting in amyloid formation.

Light-chain deposition disease

The most characteristic histologic lesion of LCDD is nodular glomerulosclerosis (see the first image shown below) that is virtually indistinguishable from diabetic glomerulosclerosis when using light microscopy. Routine immunofluorescence findings are negative because the antibodies used to identify the immunoglobulins are directed at the heavy chains of immunoglobulins. Therefore, as the name suggests, special stains for light chains must be used to identify this (see the second image depicted below) using electron microscopy.[12]

Light chain–associated renal disorders. Light micr Light chain–associated renal disorders. Light microscopy (hematoxylin and eosin stain at 25X power) showing nodular glomerulosclerosis (arrow) and thickening of the basement membrane. Courtesy of Madeleine Moussa, MD, FRCPC, Department of Pathology, London Health Sciences Centre, London, Ontario, Canada.
Light chain–associated renal disorders. Immunofluo Light chain–associated renal disorders. Immunofluorescence (25X power) showing deposits of monotypic light chain along the basement membrane. Courtesy of Madeleine Moussa, MD, FRCPC, Department of Pathology, London Health Sciences Centre, London, Ontario, Canada.

Dense granular deposits on the endothelial side of the glomerular basement membrane (as depicted in the first, second, and third images below), on the outer aspect of the tubular basement membrane, or on both may be seen with electron microscopy in persons with LCDD. Classic ultrastructure examination findings include amorphous, noncongophilic, and nonfibrillar deposits. Most of these deposits are of kappa light chains (see the fourth image shown below). At times, the histologic changes are minimal, and occasionally glomeruli may have mesangial deposits. Rarely, glomerular crescents can also be seen in patients with LCDD.

Light chain–associated renal disorders. Immunofluo Light chain–associated renal disorders. Immunofluorescence (25X power) showing deposits of monotypic light chain along the basement membrane. Courtesy of Madeleine Moussa, MD, FRCPC, Department of Pathology, London Health Sciences Centre, London, Ontario, Canada.
Light chain–associated renal disorders. Ultrastruc Light chain–associated renal disorders. Ultrastructure (electron microscopy at 29,000X power) showing deposition of nonfibrillar electron-dense material in the mesangial nodule (arrow). Courtesy of Madeleine Moussa, MD, FRCPC, Department of Pathology, London Health Sciences Centre, London, Ontario, Canada.
Light chain–associated renal disorders. Ultrastruc Light chain–associated renal disorders. Ultrastructure (electron microscopy at 29,000X power) showing deposition of nonfibrillar electron-dense material along the basement membrane (arrows). Courtesy of Madeleine Moussa, MD, FRCPC, Department of Pathology, London Health Sciences Centre, London, Ontario, Canada.
Light chain–associated renal disorders. Immunoelec Light chain–associated renal disorders. Immunoelectron microscopy (immunogold at 29,000X power) showing kappa light-chain deposition. Courtesy of Madeleine Moussa, MD, FRCPC, Department of Pathology, London Health Sciences Centre, London, Ontario, Canada.

Because many patients with LCDD do not have overt myeloma or any other evidence of monoclonal plasma cell proliferation, they may present with renal disease manifesting with proteinuria, renal insufficiency, or renal failure. Therefore, the renal biopsy findings may provide the first clues to the diagnosis of a monoclonal gammopathy.

Immunoglobulin light-chain amyloidosis (AL)

Renal involvement is common in AL amyloidosis. In contrast to LCDD, in which the deposits are usually kappa light chains, the light chains involved in the formation of amyloidosis are usually of the lambda type. The histologic appearance of amyloid is usually quite distinctive and is confirmed easily using Congo red stains or by the ultrastructural demonstration of characteristic fibrils. AA amyloid loses its Congo red positivity when briefly exposed to potassium permanganate, while non-AA amyloid resists this treatment. In the kidney, a diagnosis of non-AA amyloidosis strongly suggests light-chain amyloidosis (AL).

Kappa light-chains are more likely to produce tubular dysfunction (Fanconi syndrome) and nodular nonamyloidotic glomerulosclerosis, while lambda light chains are more likely to be involved in the development of AL amyloidosis.

Previous


Contributor Information and Disclosures
Author

Malvinder S Parmar, MB, MS FRCP(C), FACP, FASN, Associate Professor, Department of Internal Medicine, Northern Ontario School of Medicine; Assistant Professor, Department of Medicine, University of Ottawa Faculty of Medicine; Consulting Physician, Timmins and District Hospital, Ontario, Canada

Malvinder S Parmar, MB, MS is a member of the following medical societies: American College of Physicians, American Society of Nephrology, Canadian Medical Association, Ontario Medical Association, Royal College of Physicians and Surgeons of Canada

Disclosure: Nothing to disclose.

Specialty Editor Board

Francisco Talavera, PharmD, PhD Adjunct Assistant Professor, University of Nebraska Medical Center College of Pharmacy; Editor-in-Chief, Medscape Drug Reference

Disclosure: Received salary from Medscape for employment. for: Medscape.

Christie P Thomas, MBBS, FRCP, FASN, FAHA Professor, Department of Internal Medicine, Division of Nephrology, Departments of Pediatrics and Obstetrics and Gynecology, Medical Director, Kidney and Kidney/Pancreas Transplant Program, University of Iowa Hospitals and Clinics

Christie P Thomas, MBBS, FRCP, FASN, FAHA is a member of the following medical societies: American College of Physicians, American Heart Association, American Society of Nephrology, Royal College of Physicians

Disclosure: Nothing to disclose.

Chief Editor

Vecihi Batuman, MD, FACP, FASN Huberwald Professor of Medicine, Section of Nephrology-Hypertension, Tulane University School of Medicine; Chief, Renal Section, Southeast Louisiana Veterans Health Care System

Vecihi Batuman, MD, FACP, FASN is a member of the following medical societies: American College of Physicians, American Society of Hypertension, American Society of Nephrology, International Society of Nephrology

Disclosure: Nothing to disclose.

References
  1. Smithline N, Kassirer JP, Cohen JJ. Light-chain nephropathy. Renal tubular dysfunction associated with light-chain proteinuria. N Engl J Med. 1976 Jan 8. 294(2):71-4. [Medline].

  2. Herrera GA. Proximal tubulopathies associated with monoclonal light chains: the spectrum of clinicopathologic manifestations and molecular pathogenesis. Arch Pathol Lab Med. 2014 Oct. 138 (10):1365-80. [Medline].

  3. Cohen C, Royer B, Javaugue V, Szalat R, El Karoui K, Caulier A, et al. Bortezomib produces high hematological response rates with prolonged renal survival in monoclonal immunoglobulin deposition disease. Kidney Int. 2015 Nov. 88 (5):1135-1143. [Medline].

  4. Niewmierzycka A, Kurman M, Leśniak M, Winiarska A, Pawłowska A. Prevalence and clinical significance of abnormal serum kappa/lambda light chain ratio in patients with chronic kidney disease. Pol Arch Med Wewn. 2015. 125 (7-8):532-7. [Medline].

  5. Adams W. Mollitis ossium. Trans Pathol Soc London. 1872. 23:186.

  6. Glenner GG, Terry W, Harada M, et al. Amyloid fibril proteins: proof of homology with immunoglobulin light chains by sequence analyses. Science. 1971 Jun 11. 172(988):1150-1. [Medline].

  7. Kaplan B, Ramirez-Alvarado M, Sikkink L, et al. Free light chains in plasma of patients with light chain amyloidosis and non-amyloid light chain deposition disease. High proportion and heterogeneity of disulfide-linked monoclonal free light chains as pathogenic features of amyloid disease. Br J Haematol. 2009 Mar. 144(5):705-15. [Medline].

  8. Bate KL, Clouston D, Packham D, Ratnaike S, Ebeling PR. Lambda light chain induced nephropathy: a rare cause of the Fanconi syndrome and severe osteomalacia. Am J Kidney Dis. 1998 Dec. 32 (6):E3. [Medline].

  9. Katzmann JA, Abraham RS, Dispenzieri A, et al. Diagnostic performance of quantitative kappa and lambda free light chain assays in clinical practice. Clin Chem. 2005 May. 51(5):878-81. [Medline].

  10. Rao M, Yu WW, Chan J, Patel K, Comenzo R, Lamont JL, et al. Serum Free Light Chain Analysis for the Diagnosis, Management, and Prognosis of Plasma Cell Dyscrasias. AHRQ Comparative Effectiveness Reviews. 2012 Aug. [Medline].

  11. Pérez-Suárez G, Raya JM, Alvarez A, et al. Progressive renal failure as the first manifestation of monoclonal light-chain deposition disease with rapid multiple organ involvement. Clin Nephrol. 2009 Mar. 71(3):314-7. [Medline].

  12. Uppin MS, Prayaga AK, Srinivas BH, Rapur R, Desai M, Dakshina Murthy KV. Light chain immunofluorescence in various nephropathies. Indian J Pathol Microbiol. 2011 Jan-Mar. 54(1):55-8. [Medline].

  13. Gharwan H, Truica CI. Bortezomib-based chemotherapy for light chain deposition disease presenting as acute renal failure. Med Oncol. 2011 Apr 9. [Medline].

  14. Firkin F, Hill PA, Dwyer K, et al. Reversal of dialysis-dependent renal failure in light-chain deposition disease by autologous peripheral blood stem cell transplantation. Am J Kidney Dis. 2004 Sep. 44(3):551-5. [Medline].

  15. McCarthy CS, Becker JA. Multiple myeloma and contrast media. Radiology. 1992 May. 183(2):519-21. [Medline].

  16. Zucchelli P, Pasquali S, Cagnoli L, et al. Controlled plasma exchange trial in acute renal failure due to multiple myeloma. Kidney Int. 1988 Jun. 33(6):1175-80. [Medline].

  17. Johnson WJ, Kyle RA, Pineda AA, et al. Treatment of renal failure associated with multiple myeloma. Plasmapheresis, hemodialysis, and chemotherapy. Arch Intern Med. 1990 Apr. 150(4):863-9. [Medline].

  18. Clark WF, Stewart AK, Rock GA, et al. Plasma exchange when myeloma presents as acute renal failure: a randomized, controlled trial. Ann Intern Med. 2005 Dec 6. 143(11):777-84. [Medline].

  19. Leung N. Plasma exchange in multiple myeloma. Ann Intern Med. 2006 Mar 21. 144(6):455; author reply 455. [Medline].

  20. Leung N, Gertz MA, Zeldenrust SR, et al. Improvement of cast nephropathy with plasma exchange depends on the diagnosis and on reduction of serum free light chains. Kidney Int. 2008 Jun. 73(11):1282-8. [Medline].

  21. Clark WF, Garg AX. Plasma exchange for myeloma kidney: cast(s) away?. Kidney Int. 2008 Jun. 73(11):1211-3. [Medline].

  22. Burnette BL, Leung N, Rajkumar SV. Renal improvement in myeloma with bortezomib plus plasma exchange. N Engl J Med. 2011 Jun 16. 364(24):2365-6. [Medline].

  23. Hutchison CA, Cockwell P, Stringer S, et al. Early reduction of serum-free light chains associates with renal recovery in myeloma kidney. J Am Soc Nephrol. 2011 Jun. 22(6):1129-36. [Medline]. [Full Text].

  24. Hutchison CA, Bradwell AR, Cook M, et al. Treatment of acute renal failure secondary to multiple myeloma with chemotherapy and extended high cut-off hemodialysis. Clin J Am Soc Nephrol. 2009 Apr. 4(4):745-54. [Medline]. [Full Text].

  25. Harding S, Provot F, Beuscart JB, et al. Aggregated serum free light chains may prevent adequate removal by high cut-off haemodialysis. Nephrol Dial Transplant. 2011 Apr. 26(4):1438. [Medline].

  26. Firkin F, Hill PA, Dwyer K, et al. Reversal of dialysis-dependent renal failure in light-chain deposition disease by autologous peripheral blood stem cell transplantation. Am J Kidney Dis. 2004 Sep. 44(3):551-5. [Medline].

  27. Herrera GA, Joseph L, Gu X, et al. Renal pathologic spectrum in an autopsy series of patients with plasma cell dyscrasia. Arch Pathol Lab Med. 2004 Aug. 128(8):875-9. [Medline].

  28. Jones HB. Papers on chemical pathology: Prefaced by the Gulstonian lectures, read at the Royal College of Physicians, 1846. Lancet. 1847. 2:88-92.

  29. Klassen RB, Allen PL, Batuman V, et al. Light chains are a ligand for megalin. J Appl Physiol. 2005 Jan. 98(1):257-63. [Medline].

  30. Pozzi C, D'Amico M, Fogazzi GB, et al. Light chain deposition disease with renal involvement: clinical characteristics and prognostic factors. Am J Kidney Dis. 2003 Dec. 42(6):1154-63. [Medline].

  31. Ronco PM, Alyanakian MA, Mougenot B, et al. Light chain deposition disease: a model of glomerulosclerosis defined at the molecular level. J Am Soc Nephrol. 2001 Jul. 12(7):1558-65. [Medline].

  32. Royer B, Arnulf B, Martinez F, et al. High dose chemotherapy in light chain or light and heavy chain deposition disease. Kidney Int. 2004 Feb. 65(2):642-8. [Medline].

  33. Salant DJ, Sanchorawala V, D'Agati VD. A case of atypical light chain deposition disease--diagnosis and treatment. Clin J Am Soc Nephrol. 2007 Jul. 2(4):858-67. [Medline].

  34. Sengul S, Zwizinski C, Batuman V. Role of MAPK pathways in light chain-induced cytokine production in human proximal tubule cells. Am J Physiol Renal Physiol. 2003 Jun. 284(6):F1245-54. [Medline].
