Congenital Anomalies of the Esophagus Treatment & Management

  • Author: Robert K Minkes, MD, PhD; Chief Editor: Marleta Reynolds, MD   more...

Updated: Dec 5, 2011


Medical Therapy

To prevent mucous accumulation, aspiration, and respiratory deterioration continuous or intermittent low-pressure suction of the upper esophageal pouch should be initiated with a double-lumen Replogle catheter. In small infants, intermittent suction may be better. The infant should be positioned to minimize gastric fluid reflux. The infant is typically positioned in a 45 º sitting position. In addition, infant handling should be minimized because excess disturbance may lead to further respiratory complications, increased oxygen consumption, cold stress, and increased regurgitation of gastric contents. Oxygen therapy should be administered as needed to maintain oxygen saturation. Endotracheal intubation is not performed routinely, but it may be required based on the infant's respiratory status. Bag-mask ventilation should be avoided because it may cause gastric distension leading to increased reflux.

Intravenous fluid therapy consisting of 10% dextrose and hypotonic sodium chloride solution is used to maintain fluid, electrolyte, and glucose balance. Broad-spectrum antibiotics should be administered at the time of diagnosis or after cultures are obtained. A vitamin K analog should also be administered before surgery. Under no conditions should the infant be orally fed. If surgical treatment is delayed more than a few days, total parenteral nutrition is used. In addition, the infant should be transferred to a tertiary care pediatric institution with a neonatal ICU and a pediatric surgery team.

Next

Surgical Therapy

The operative procedure for infants with congenital esophageal abnormalities depends on the specific type of anomaly present, the condition of the infant, and the presence of other congenital anomalies.[4, 5]

Gastrostomy

The staged approach for patients with pure esophageal atresia (EA) and in some infants with EA and tracheoesophageal fistula (TEF) includes initial placement of a Stamm gastrostomy, followed later by fistula division and later esophageal reconstruction. Gastrostomies may cause problems in infants with EA and TEF, especially in premature infants with severe respiratory distress syndrome requiring positive-pressure ventilation. Because of the TEF, the infant's respiratory and upper GI tracts function as a single unit. Therefore, the sudden decrease in intragastric pressure may result in preferential airflow through the fistula. Fistula ligation, occlusion of the fistula with a Fogarty catheter, and an underwater seal for the gastrostomy tube are methods used to maintain ventilatory pressure in these cases.

Most surgeons perform a gastrostomy in the first 24 hours of life in an infant with pure EA. This allows enteral feedings while the child grows and the esophageal gap shortens. A gastrostomy may be used in premature or unstable infants with EA and TEF.

Esophageal atresia with tracheoesophageal fistula

Fistula division with primary anastomosis is the surgical treatment for EA with TEF. A posterolateral thoracotomy on the side opposite the aortic arch is used. The patient is typically positioned on the left side with a small axillary roll. The right arm is extended above the head with the neck slightly flexed. Typically, manual ventilation control is used until the fistula is ligated.

For infants in whom ventilation is difficult because of the passage of air through the fistula into the stomach, insertion of a Foley catheter through the fistula into the lower esophagus may be helpful. This can be done through a bronchoscope or performed retrograde through the stomach accessed with a laparotomy incision. A fourth intercostal extrapleural approach is employed through a transverse incision along the inferior angle of the scapula, from the anterior axillary line posteriorly to the paravertebral region. Although some surgeons prefer the transpleural technique for its speed, the extrapleural approach provides added protection against empyema should an anastomotic leak occur. The latissimus dorsi is divided, and the serratus anterior can be divided or reflected to protect its innervation. A muscle-sparing approach can be performed.

The thorax is entered through the fourth intercostal space (ICS) by dividing the intercostal muscles. The extrapleural dissection begins posteriorly and proceeds superiorly, inferiorly, and finally anteriorly, where the risk of a pleural tear is highest. Wet cotton-tipped applicators, gauze swabs, moist peanut dissectors, or gentle finger dissection facilitates the pleural dissection from the chest wall. The azygous vein is identified, ligated and divided, or retracted (see image below). The lung and pleura are medially retracted. The distal esophageal segment is identified by following the right vagus nerve inferiorly, and the connection of the esophagus to the trachea is located. The lower esophagus is dissected circumferentially near the fistula taking care to not damage the vagal fibers or vascularization.

Intraoperative photograph illustrating azygous veiIntraoperative photograph illustrating azygous vein. A right thoracotomy and retropleural dissection has been performed.

Extensive mobilization of the distal pouch is not recommended because of its segmental blood supply. However, distal pouch mobilization may be necessary to achieve a primary anastomosis. The fistula is divided close to the trachea. A 1-mm to 2-mm esophageal cuff should be left on the trachea to minimize the risk of postoperative tracheal stricture. Interrupted 5-0 or 6-0 silk or polypropylene sutures are used to close the fistula. The air-tightness of the tracheal closure should be assessed by filling the chest with saline and looking for any bubbles when positive-pressure is applied by the anesthesiologist. Atraumatic handling of the distal esophagus is important. Two fine-stay sutures in the distal esophagus allow for mobilization and gentle traction without the use of forceps.

The proximal segment is identified by gently advancing the Replogle tube, and traction sutures may be placed. The upper pouch can and should be mobilized all the way to the thoracic inlet. Circumferential mobilization to the thoracic inlet aids in identifying proximal fistulas. Care must be taken during the dissection of the proximal esophagus to avoid injury to the trachea or recurrent laryngeal nerve.

A primary anastomosis should be performed whenever possible. If the esophageal segments cannot be joined without undue tension after mobilization of both ends, a circular myotomy may be performed on the proximal segment. A primary anastomosis is accomplished by opening the proximal pouch at the lower-most point. The opening created in the upper pouch should approximate that of the lower pouch. The distal segment is incised only if it is clearly devascularized or narrow and fibrous. Interrupted absorbable sutures are used to perform the anastomosis. Lateral stay sutures are placed. Ensuring mucosal apposition during the anastomosis is important. Usually, 5-6 sutures are needed to complete the posterior row. After all posterior sutures have been placed, the knots are tied on the inside of the esophageal lumen to prevent subsequent twisting of the esophagus. As the sutures are tied, tension gradually is distributed to the tied sutures. The lateral stay sutures are not tied.

A small feeding tube can be passed across the anastomosis into the stomach to ensure luminal patency and protect the posterior wall of the anastomosis while the anterior wall is sutured. Some surgeons leave the tube in postoperatively to decompress the stomach and provide a postoperative feeding route (see image below).

Chest radiograph immediately following repair of eChest radiograph immediately following repair of esophageal atresia and distal tracheoesophageal fistula (TEF). Note the chest tube (CT) in the retropleural space and the feeding tube passing through the anastomosis (A) into the stomach.

The anterior suture layer of the anastomosis is then completed over the tube, and the knots are tied on the outside (see image below). A muscle or tissue flap may also be placed between the anastomosis and the repaired trachea to decrease the risk of fistula recurrence.

Intraoperative photograph showing primary anastomoIntraoperative photograph showing primary anastomosis (A) between the proximal and distal esophagus.

Most surgeons place a retropleural chest tube with the tip positioned near, but not touching, the anastomosis (see image below). The tube is placed to water seal drainage to avoid an extrapleural pneumothorax. Suction applied to the tube may disrupt the anastomosis. Intubation should be maintained as is clinically required. Premature extubation that results in aggressive bag-mask ventilation and reintubation can be disastrous to the repair.

Chest radiograph following repair of esophageal atChest radiograph following repair of esophageal atresia. The chest tube is placed in the retropleural space (CT). No feeding tube is passing across the anastomosis.

Premature and medically unstable children can be maintained on total parenteral nutrition with a tube in the proximal pouch until surgery. Emergent thoracotomy and fistula ligation is used for infants with respiratory distress when nonoperative management is unsuccessful.

Recently, thoracoscopic techniques have been used to repair tracheoesophageal atresia and distal fistula.

Esophageal atresia with proximal fistula

The repair for a proximal fistula is the same as that described above. If a proximal fistula is present with no distal fistula, a cervical approach may be used instead.

Pure esophageal atresia

Most children with pure EA undergo gastrostomy placement followed by delayed repair. Following a period of growth, repair of EA without fistula consists of a thoracotomy with retropleural dissection, mobilization of the 2 esophageal segments, and a primary anastomosis (see images below). Esophageal continuity can usually be achieved without an esophageal replacement.

Intraoperative photograph during repair of esophagIntraoperative photograph during repair of esophageal atresia. The head is to the left. The azygous vein has been divided. The proximal (P) and distal (D) esophageal pouches can be easily observed. Intraoperative photograph showing primary anastomoIntraoperative photograph showing primary anastomosis (A) between the proximal and distal esophagus.

Several techniques are used to lengthen the esophageal ends to achieve a primary anastomosis. Bougienage is the most common mechanical lengthening procedure. Upper pouch bougienage is performed by passing a weighted bougie through the mouth into the upper pouch and applying forward pressure 1-2 times daily. This procedure is performed for 6-12 weeks followed by a delayed primary repair. Both internal and external traction sutures have been used by some surgeons.

During surgery, lengthening techniques may also be used.[6, 7] Myotomy is a common method that provides a 1-cm increase in length. The muscular layers are divided to create a plane between the muscularis propria and submucosa. Circular myotomies involve a circumferential division, while spiral myotomies preserve the muscular continuity of the proximal pouch and maintain closed submucosal layers. As many as 3 myotomies can be performed. The most proximal myotomy should be performed first. This procedure can be performed on both esophageal segments, but myotomies performed on the distal stump may increase the incidence of gastroesophageal reflux.

When additional length is necessary, a portion of the stomach may be brought up through the diaphragmatic hiatus. This procedure has been successfully used, even in infants with low birth weight. A Collis lengthening procedure may also be used.

A cervical esophagostomy is used when an anastomosis is impossible and in cases of failed surgery. For this procedure, a left transverse incision is performed 1 cm above and parallel to the medial third of the clavicle. The incision is deepened through the platysma. The sternal head of the sternocleidomastoid is divided, the sternothyroid muscle is divided or reflected, and the carotid sheath is retracted. The esophagus is mobilized circumferentially and dissected distally. The esophageal end is brought out to the lateral end of the skin incision and sutured with interrupted absorbable sutures. This procedure allows the child to swallow normally. Sham feeds are administered to stimulate lengthening by a natural bougienage effect and to avoid oral aversion. The infant may be discharged home on gastrostomy feedings until esophageal repair or replacement can be performed.

A variant of this method is the multistaged extrathoracic elongation, which has also been used in long-gap treatment. In this procedure, the upper esophagus is initially mobilized and brought out as an end cervical esophagostomy. Over a period of weeks to months, the esophagus and stoma are progressively translocated down the anterior chest until adequate length is achieved to permit an end-to-end anastomosis. Again, the child is able to swallow and can be discharged home during the intervening period. The use of short-term traction sutures to narrow the esophageal gap has been described.

Esophageal replacement

Esophageal substitutions are used to restore esophageal continuity when the patient's native esophagus is not an option. No esophageal replacement is ideal, and a poorly functioning esophagus may even be preferable to any esophageal substitute. Because of advancements in the surgical techniques to treat EA, the need for esophageal replacement has diminished; however, conditions that necessitate an esophageal substitution are noted.

Many types of conduits have been used, including colon, stomach, gastric tubes, and jejunum. The choice of substitute to be used is influenced by the length and segment of esophagus to be replaced, the presence of any associated anomalies, and the vascular adequacy of the proposed replacement. Most often, the surgeon's preference and experience contributes to the selection.

  • Colon
    • Segments of the right, left, or transverse colon may be used (see image below). The colon interposition may be placed in a posterior mediastinal or retrosternal position within the thorax. Colonic interpositions act as passive conduits, allowing isoperistaltic and antiperistaltic positions within the chest. Reports of spasm, regurgitation, and discomfort with the antiperistaltic colonic conduits indicate some retention of motor function. The isoperistaltic method is often favored. Contrast study demonstrating colonic interpositionContrast study demonstrating colonic interposition. The colon is sutured to the cervical esophagus proximally and the stomach distally. No leak or stricture is noted.
    • Advantages of colonic replacement of the esophagus include the following:
      • Adequate length available
      • Acts as a conduit antiperistaltically or isoperistaltically
      • Good vascular supply via marginal artery
      • Conserves native stomach
      • Can be placed in esophageal bed of posterior mediastinum
      • Has memory (but variable) for propelling solid bolus
      • Has mucous shield, which protects against reflux
      • Responds to acid with a peristaltic rush for clearance
      • May allow preservation of entire native esophagus
      • Minimizes/eliminates tension on the upper and lower esophageal segments
      • May improve esophageal motility and minimize reflux
    • Disadvantages of colonic replacement of the esophagus include the following:
      • Requires 3 anastomoses
      • Empties more slowly than the esophagus
      • Requires preoperative bowel preparation
      • Long surgical procedure with extensive mobilization
      • Dilates and becomes redundant over time
      • Slows food transit
      • Anastomotic leak and stricture
      • Graft necrosis
      • Long-term growth retardation
  • Gastric tube
    • Esophageal replacement can be achieved by fashioning a tube from the stomach. The 2 most common tubes are the reversed (antiperistaltic) tube and the nonreversed (isoperistaltic) tube. Delaying the procedure allows stomach enlargement, and a long tube can then be constructed. Gastrostomy tubes should be placed close to the lesser curvature of the stomach in these infants.
    • The reversed gastric tube is constructed most commonly. It is proximally based and supplied by the left gastroepiploic vessels. This tube can be used to replace the entire esophagus but has a more limited blood supply than the isoperistaltic tube, and care must be taken during the procedure not to injure the spleen. The nonreversed, or isoperistaltic, tube is based distally and supplied by the right gastroepiploic vessels. A 1-stage or 2-stage procedure may be performed. A staged procedure involves constructing the gastric tube and externalizing it in the neck. A cervical anastomosis is completed 4-6 weeks later. The gastric tube and gastric remnant should be studied radiographically before reanastomosis.
    • Advantages of a gastric tube include the following:
      • Thick-walled straight conduit
      • Does not become dilated, tortuous, or redundant
      • Less risk of ischemia because of robust blood supply
      • Simplified construction through stapler use
      • Has a favorable anatomic location in the upper abdomen
      • Possible construction variations
      • Has adequate length
      • Requires fewer anastomoses
      • Has comparable diameter and occupies less space in the thorax and neck
      • Has only one suture line
      • Requires no bowel preparation and is a faster procedure
      • Rapidly transits
    • Disadvantages of a gastric tube include the following:
      • Leaks and strictures
      • Extensive gastroesophageal reflux, which may lead to peptic ulceration, nocturnal coughing, and Barrett epithelium
      • Leaves a small gastric reservoir
      • Creates a long suture line
      • May result in gastric outlet obstruction
      • May be unable to reach high in neck
      • Difficult to place in posterior mediastinum
      • Occasional perforation
  • Gastric transposition
    • In a gastric transposition, the entire stomach assumes an intrathoracic position and serves as a passive conduit (see image below). The fundus of the stomach is joined to the upper esophageal pouch, and the lower esophageal segment is not used. A gastric transposition can be performed in infants and children of all ages but is typically performed around the first year of life. Although some prefer this method of esophageal replacement, others advise against its use in infants and children because of the effects of the gastric capacity crowding the lungs and trachea and the excessive gastroesophageal reflux. An initially placed gastrostomy is not a contraindication. Contrast swallow (oblique view) demonstrating a gaContrast swallow (oblique view) demonstrating a gastric pull-up used as esophageal replacement in a child with pure esophageal atresia. Note stomach in chest.
    • Advantages of gastric transposition include the following:
      • Readily available and easily mobilized stomach
      • Involves single anastomosis
      • Adequate length available
      • Can use numerous surgical approaches
      • Has excellent blood supply
      • Involves a technically easy procedure
      • Has low incidence of leaks and strictures
    • Disadvantages of gastric transposition include the following:
      • Large bulk possibly causing space problems intrathoracically
      • Reflux
      • Barrett epithelium development possible in proximal esophagus
      • Possible stricture or aspiration due to lack of gastroesophageal valve
      • Poor gastric emptying
      • May affect pulmonary function
      • Results in depleted iron stores causing anemia
      • May affect growth
      • Microvasculature easily disturbed with rough handling
      • May not reach as high in neck as other methods because of blood supply
      • Difficult to initiate oral feedings
      • May result in dumping as a common postoperative symptom
  • Jejunum
    • Jejunal esophageal substitution is rarely used. The jejunal replacement is unique because it retains peristaltic activity and, therefore, must always be positioned isoperistaltically. However, peristalsis is not synchronous with swallowing and may slow food transit. Proximal jejunal segments are preferred for graft construction because of their larger and fewer vascular arcades, which can be located and dissected more easily. Jejunal segments may range from 2-12 cm in length, but the tight radii of the superior mesenteric artery branches prevent construction of straight and longer segments. The jejunum is typically used only for replacements of short lower esophageal lengths.
    • Advantages of jejunal replacement of the esophagus include the following:
      • A remarkably disease-free organ
      • Readily available
      • Jejunal caliber similar to that of normal esophagus
      • Functions as reliable food transporter
      • Results in low incidence of leaks and strictures
      • Functions as an effective gastroesophageal barrier
      • Does not require a bowel preparation
      • Jejunal wall at correct thickness for comfortable suture placement
    • Disadvantages of jejunal replacement of the esophagus include the following:
      • Length of conduit limited by blood supply
      • Infarction commonly resulting from passage through chest
      • Procedure more technically difficult
      • Requires 3 anastomoses
      • Has high peptic ulcer susceptibility
      • Blood supply lacking marginal artery
      • Difficult to obtain a straight conduit with sufficient vascularization
      • Has high failure rate (free graft)

Isolated tracheoesophageal fistula

H-fistulas or N-fistulas are typically located at the T1-T3 level, coursing downward from the trachea to the esophagus. Most can be repaired through a cervical approach. An undiagnosed H-type fistula may also be identified while mobilizing the proximal esophagus during surgery for EA (see image below). A right-sided supraclavicular incision 1-1.5 cm above and parallel to the right clavicle is made to minimize risk of injury to the thoracic duct. The sternocleidomastoid muscle is retracted posteriorly, and the sternal head is divided if necessary. The inferior thyroid artery and middle thyroid vein are divided if needed to expose the plane between the trachea and the esophagus.

Contrast swallow (oblique view) demonstrating a gaContrast swallow (oblique view) demonstrating a gastric pull-up used as esophageal replacement in a child with pure esophageal atresia. Note stomach in chest.

Care should be taken to clearly identify and preserve the recurrent laryngeal nerves, vagal nerve fibers, and posterior trachea. The fistula may be located higher than might be expected. The esophagus is encircled with rubber vessel loops to facilitate mobilization. The fistula is also encircled when it is identified (see image above). The fistula is divided close to the esophagus, leaving a 2-mm esophageal cuff on the trachea. Interrupted sutures are used to close the esophagus and trachea (see image below).

Intraoperative photograph demonstrating proximal HIntraoperative photograph demonstrating proximal H-type fistula (F) between the proximal esophagus (P) and trachea (T). The blue vessel loop is around the fistula. The H-type fistula was not diagnosed preoperatively; it was identified while mobilizing the proximal esophagus in a child with congenital esophageal stenosis.

A muscle flap may be interposed between the 2 suture lines to decrease the likelihood of a recurrent fistula. Fistula ligation without division should not be performed. Wound drainage is typically not necessary for an H-fistula repair, and the endotracheal tube should be left in because tracheal swelling is a frequent postoperative occurrence.

Congenital esophageal stenosis, webs, and tracheobronchial remnants

Treatment should relieve the obstructive symptoms and maintain the antireflux mechanism of the gastroesophageal junction. Bougienage or balloon dilation may successfully treat fibromuscular hypertrophy. Membranous webs, complete occlusion, and tracheobronchial remnants usually require surgical excision (see images below). A right thoracotomy is usually used. Lesions in the abdominal esophagus can be approached through the abdomen. A segmental resection and primary anastomosis can be achieved in most instances (see images below). The phrenic and vagus nerves should be identified and preserved. Esophageal replacement may be needed for long segments of fibromuscular hypertrophy.

Intraoperative photograph of an infant thought to Intraoperative photograph of an infant thought to have esophageal atresia. The proximal (P) and distal esophagus was connected by a fibrotic segment of congenital esophageal stenosis (CES) beginning at the azygous vein (A). No distal tracheoesophageal fistula was present. Intraoperative photograph following resection of aIntraoperative photograph following resection of an atretic segment of esophagus and primary anastomosis (A) of the proximal (P) and distal esophagus. The azygous vein (AV) was preserved.
Previous
Next

Postoperative Details

Postoperative care of an infant with EA involves a team approach, typically in the neonatal intensive care unit. A chest radiograph is immediately obtained following surgery (see images below). The infant should be kept in a semiupright position, and the patient's head should be supported to prevent neck extension, which may disrupt the anastomosis. Intravenous fluid replacement should be maintained, and prophylactic antibiotic treatment should be continued. The pharynx should be frequently suctioned to prevent respiratory infection, but deep suctioning should be avoided. Appropriate temperature, humidity, and oxygen atmospheric control are essential. If the anastomosis was performed under extensive tension, some surgeons recommend elective paralysis and mechanical ventilation for several days postoperatively. Otherwise, the patient is weaned from the ventilator as soon as possible.

Chest radiograph immediately following repair of eChest radiograph immediately following repair of esophageal atresia and distal tracheoesophageal fistula (TEF). Note the chest tube (CT) in the retropleural space and the feeding tube passing through the anastomosis (A) into the stomach. Chest radiograph following repair of esophageal atChest radiograph following repair of esophageal atresia. The chest tube is placed in the retropleural space (CT). No feeding tube is passing across the anastomosis.

Contrast esophagraphy is performed postoperatively to assess for esophageal leak, stricture, motility, and gastroesophageal reflux (see image below). The swallowing reflex and positions of the duodenum and ligament of Treitz should also be examined. The timing of the initiation of feeding varies. Some advocate starting gastrostomy or nasogastric feedings on the first or second postoperative day in uncomplicated cases. Other surgeons advise against gastrostomy or nasogastric tube feedings because of the potential for acid reflux and injury to the anastomosis. Total parenteral nutrition should be used when enteral feedings are not started. If no leaks are observed on the postoperative contrast study, feedings are initiated and the chest tube is removed. The child may be discharged when feedings are tolerated and appropriate weight gain is observed.

Esophagogram one week following primary anastomosiEsophagogram one week following primary anastomosis for pure esophageal atresia. No leak or stricture is observed.
Previous
Next

Follow-up

Frequent follow-up visits are necessary during the first year after repair. If the child is doing well, visits can be decreased to 1-2 times per year until school age. Because of scarring at the anastomosis, the child may tolerate only pureed food up to age 12-18 months and then minced food until age 5 years. At age 5 years, the child has typically learned to chew well before swallowing and has developed sufficient teeth to aid in this task. The child's parents should be informed about the signs of gastroesophageal reflux, recurrent fistula, tracheomalacia, and other complications.

Previous
Next

Complications

The severity of complications following esophageal surgery is often dictated by the extent of the repair. Anastomotic tension is involved in 79% of complications, and the most common complications include anastomotic leak, recurrent fistula, stricture, and gastroesophageal reflux.

Anastomotic leakage occurs in anywhere from 14-21% of children that have undergone a surgical esophageal atresia (EA) repair (see following image). Leaks result from the small friable lower segment, ischemia of the esophageal ends, excess anastomotic tension, sepsis, poor suturing techniques, and inaccurate mucosal apposition.

Anastomosis disruption following repair of esophagAnastomosis disruption following repair of esophageal atresia with a tracheoesophageal fistula. Contrast was injected through a gastrostomy and refluxed through the distal esophagus. The leak (L) is draining into the retropleural chest tube.

Early extubation with reintubation also puts infants at increased risk of anastomotic leakage. Most leaks are small, occur late after the first 48 hours, and require only conservative management. Chest tube drainage, antibiotics, and time allow most to heal. Spontaneous healing occurs in 95% of leaks when a mediastinal drain is present. A repeat esophagraphy is performed each week until the leak has resolved. More significant leaks occur early, within the first few days, and should be immediately explored in most cases. Major anastomotic disruptions account for only 3-5% of leaks. Large leaks can be fatal or may lead to fistula recurrence.

Fistula recurrence is observed in 3-14% of patients treated for EA-TEF or isolated TEF. Fistulas usually recur within a few months but may be found as late as 2 years postoperatively. Fistula recurrence is caused by anastomotic leak with local inflammation and erosion at the previous repair site, ischemia, and surgical dissection too near the trachea. Recurrent TEF should be suspected when choking episodes occur during feeding and/or recurrent pneumonia is observed. Esophagography under video fluoroscopy with the patient in the prone position or bronchoscopy provide the best methods of diagnosis. Routine contrast swallows do not reveal 50% of recurrent TEFs. Fistulas do not spontaneously close and require surgical division and suturing.

Recently, attempts have been made to close recurrent fistulas with fibrin glue administered into the fistula. During surgical repair, a tissue flap should be interposed between the suture lines of the trachea and esophagus. Recurrence rates remain in the 10-20% range when repeat surgery is needed.

Esophageal strictures are also common following esophageal surgery. Anastomotic strictures occur in as many as 40% of children with an EA repair (see following images). Strictures can result from the natural healing process, the different sizes of the 2 anastomosed segments, tension, gastroesophageal reflux, and leaks. Asymptomatic narrowing observed on initial esophagography can improve over time without the need for intervention. Strictures are clinically suspected, and the diagnosis can be confirmed via contrast esophagraphy and esophagoscopy.

Esophagogram 1 week after repair of esophageal atrEsophagogram 1 week after repair of esophageal atresia with a distal tracheoesophageal fistula (TEF). Note narrowing at anastomosis (A). The child was asymptomatic and required no dilatations. Image 1 of 3 in series. Follow-up esophagram demonstrating spontaneous impFollow-up esophagram demonstrating spontaneous improvement of narrowing at the anastomosis (A). Image 2 of 3 in series. Esophagogram. Note spontaneous resolution of narroEsophagogram. Note spontaneous resolution of narrowing at the anastomosis (A). No intervention was required in this child. Image 3 of 3 in series. Esophagogram 7 days following repair of esophagealEsophagogram 7 days following repair of esophageal atresia. Note the change in caliber from the proximal esophagus to the distal esophagus at the anastomosis (A). The retropleural chest tube can be observed (CT). This patient had gastroesophageal reflux and developed a progressive stricture. Image 1 of 3 in series. Esophagogram obtained 3 weeks later demonstrating Esophagogram obtained 3 weeks later demonstrating stricture (A) and gastroesophageal reflux (R and green arrow). Medical therapy was initiated. Image 2 of 3 in a series. Esophagogram performed 2 weeks later demonstratingEsophagogram performed 2 weeks later demonstrating worsened anastomotic stricture (A). The patient responded well to Bouginage dilatation and medical management of the reflux. Image 3 of 3 in a series.

Most strictures can be managed with serial dilatations. Multiple dilatations over several months are needed in many cases. Strictures unresponsive to dilation require surgical resection.

Gastroesophageal reflux is a common complication of esophageal surgery, occurring in 40-70% of patients undergoing EA repair. Symptoms of gastroesophageal reflux include coughing, apnea, recurrent pneumonia, failure to thrive, and stricture formation (see following images). Reflux is thought to be related to tension, dysmotility of the lower esophagus, and an altered angle of His from distal esophageal mobilization.

Esophagogram obtained 3 weeks later demonstrating Esophagogram obtained 3 weeks later demonstrating stricture (A) and gastroesophageal reflux (R and green arrow). Medical therapy was initiated. Image 2 of 3 in a series. Esophagogram performed 2 weeks later demonstratingEsophagogram performed 2 weeks later demonstrating worsened anastomotic stricture (A). The patient responded well to Bouginage dilatation and medical management of the reflux. Image 3 of 3 in a series.

Gastroesophageal reflux is clinically diagnosed and may be confirmed with an upper GI series or pH probe. Reflux is initially medically managed. Initial steps include keeping the patient in a prone head-up position after feeding, thickening feeds, and giving smaller more frequent meals. Acid reduction agents (eg, histamine H2 receptor blockers, proton pump inhibitors) and prokinetic agents may be needed. If symptomatic reflux persists, a fundoplication is needed. Fundoplications are required in up to one half of patients with gastroesophageal reflux after an EA repair.

Tracheomalacia is a condition in which weakness of the trachea results in compression of the anterior and posterior walls between the aorta and dilated esophagus during expiration or coughing. This complication occurs more frequently in the presence of a fistula and is present in 10-20% of infants after an EA-TEF repair. The region of compression is typically located at or just above the level of the original fistula but may involve the entire trachea. The marked tracheal anterior-posterior collapse is observed easily during bronchoscopy performed while the patient is awake. Tracheomalacia usually improves slowly with time. In some cases, tracheomalacia may prevent extubation, and intervention with aortopexy, tracheostomy, or tracheal stenting is needed.

Esophageal dysmotility is frequent following surgery for congenital esophageal lesions. Food impaction can occur at the level of the anastomosis, especially if a stricture is present (see following image). Altered esophageal peristalsis has been documented with manometric and radionuclide studies, video fluoroscopy, scintigraphy, and cine esophagraphy after EA repair. Discontinuity of peristaltic function is observed above and below the surgical anastomosis. Dysmotility appears to persist and has been reported in 32-year follow-up studies. Children learn to compensate for the dysmotility by eating in an upright position and drinking frequently during eating.

Esophagogram demonstrating impacted food in a 5-yeEsophagogram demonstrating impacted food in a 5-year-old child with a history of esophageal atresia repair.

Esophageal diverticula may develop at the anastomosis or a site where a circular myotomy was performed. The myotomy site may balloon progressively over time and cause ventilatory obstruction and dysphagia.

Previous
Next

Outcome and Prognosis

The survival rate of patients with esophageal atresia (EA) and/or tracheoesophageal fistula (TEF) has immensely improved since Haight's first successful repair in 1941. Early diagnosis and advancements in neonatal anesthesia, surgical technique, treatment of associated anomalies, and intensive care management have improved the prognosis. Most children treated for EA have a normal lifespan. Despite an increased number of patients with severe congenital anomalies, survival rates have been reported as high as 95%. In uncomplicated cases, survival rates are virtually 100%.

Traditionally, prognosis for children with EA-TEF was based on birth weight and the presence of pneumonia and associated congenital anomalies. Because of advancements in neonatal care, birth weight does not affect survival rate unless it is severely low, and pneumonia may be treated successfully. Currently, cardiac and chromosomal abnormalities are the most significant causes of death. Infants with a birth weight less than 1500 g, major congenital cardiac abnormalities, severe associated anomalies, preoperative ventilator dependence, and/or long gap are at increased risk.

Dysphagia, frequent night coughs, dyspepsia, and recurrent respiratory infections are frequent results of the less distensible esophagus and gastroesophageal reflux. Gastroesophageal reflux occurs in as many as one half of these patients and many require antireflux operations. Feeding difficulties also are common, particularly during the first several years after repair. Choking, vomiting, and food impaction occur. These symptoms, like many following EA repair, diminish over time, and 70-80% of adolescents report no or only occasional swallowing impairment. Most patients who have undergone EA repair have abnormal peristalsis with decreased contractile activity and inefficient clearance capacities.

In one series, after an average of 8.8 years of follow-up care, all patients were reported to eat excellently or satisfactorily, with more than 90% eating no differently than their siblings. Normal respiratory function is observed in half of patients 3 months postoperatively. Tracheomalacia, vascular rings, and decreased lung volumes account for the abnormal respiratory function in the other children. Tracheomalacia occurs in 10% of patients with TEF. Most outgrow this problem; however, some children require more aggressive therapy.

Growth retardation has been observed in some children who have had EA repair, but this observation varies. Patients treated for EA-TEF are at higher risk for developing esophagitis and Barrett epithelium. Reports of esophageal carcinoma decades after EA-TEF repair are becoming more frequent as the first generation of survivors progresses through adulthood. Surveillance esophagoscopy has been proposed to provide early detection for esophageal abnormalities.

Despite the complications, the results of EA-TEF repair have dramatically improved. Many symptoms are alleviated over time, and most children and adults enjoy normal lifestyles and have no complaints concerning their quality of life or eating habits. Even by school age, children who had many complications in infancy reported few restrictions at school or in participation in sports with little or no effect on school attendance and social activities. The outcome for these children and children treated for other congenital lesions is generally good.

Previous
Next

Future and Controversies

The prognosis and treatment course for infants with esophageal atresia (EA) and/or tracheoesophageal fistula (TEF) and other congenital lesions has improved over the past 60 years. Advances in perinatal and neonatal care have been paramount in reducing the morbidity and mortality rates associated with these conditions. Currently, associated congenital anomalies and pulmonary complications contribute most significantly to adverse outcomes.

Infants with very low birth weight or serious cardiac abnormalities are at increased risk for poor outcome. Improvements in the prevention and management of these high-risk infants would improve outcome and survival rates. In addition, enhanced prenatal detection of EA and/or TEF and other congenital anomalies allows for better prenatal counseling and preparation for the delivery at a tertiary medical center.

Esophageal defects are currently repaired with thoracoscopy; robotic-assisted surgery may be used in the future.[8]

Tissue engineering for esophageal replacement, in utero intervention, and minimally invasive techniques such as thoracoscopy and robotic assistance may be used in years to come to further improve treatment of these infants.

Previous

Contributor Information and Disclosures
Author

Robert K Minkes, MD, PhD  Professor of Surgery, University of Texas Southwestern Medical Center at Dallas, Southwestern Medical School; Medical Director and Chief of Surgical Services, Children's Medical Center of Dallas-Legacy Campus

Robert K Minkes, MD, PhD is a member of the following medical societies: Alpha Omega Alpha, American College of Surgeons, American Medical Association, American Pediatric Surgical Association, and Phi Beta Kappa

Disclosure: Nothing to disclose.

Coauthor(s)

Alison Snyder-Warwick, MD  Resident Physician, Department of Surgery, Division of Plastic and Reconstructive Surgery, Washington University School of Medicine

Alison Snyder-Warwick, MD is a member of the following medical societies: Alpha Omega Alpha, Phi Beta Kappa, and Sigma Xi

Disclosure: Nothing to disclose.

Mark V Mazziotti, MD  Assistant Professor of Pediatric Surgery, Department of Surgery, Baylor College of Medicine, Texas Children's Hospital

Mark V Mazziotti, MD is a member of the following medical societies: Alpha Omega Alpha, American Academy of Pediatrics, American College of Surgeons, American Medical Association, American Pediatric Surgical Association, and Phi Beta Kappa

Disclosure: Nothing to disclose.

Jacob C Langer, MD  Professor, Department of Surgery, University of Toronto Faculty of Medicine

Jacob C Langer, MD is a member of the following medical societies: American Academy of Pediatrics, American College of Surgeons, American Pediatric Surgical Association, Association for Academic Surgery, Canadian Medical Association, Ontario Medical Association, Royal College of Physicians and Surgeons of Canada, Society for Surgery of the Alimentary Tract, and Society of University Surgeons

Disclosure: Nothing to disclose.

Specialty Editor Board

Robert Kelly, MD  Chairman, Department of Surgery, Departments of Surgery and Pediatrics, Children's Hospital of the King's Daughters; Associate Professor, Eastern Virginia Medical School

Robert Kelly, MD is a member of the following medical societies: American Academy of Pediatrics, American College of Surgeons, American Medical Association, American Pediatric Surgical Association, American Society of Abdominal Surgeons, Medical Society of Virginia, Norfolk Academy of Medicine, and Southern Medical Association

Disclosure: Nothing to disclose.

Mary L Windle, PharmD  Adjunct Associate Professor, University of Nebraska Medical Center College of Pharmacy; Editor-in-Chief, Medscape Drug Reference

Disclosure: Nothing to disclose.

Deborah F Billmire, MD  Associate Professor, Department of Surgery, Indiana University Medical Center

Deborah F Billmire, MD is a member of the following medical societies: Alpha Omega Alpha, American Academy of Pediatrics, American College of Surgeons, American Pediatric Surgical Association, Phi Beta Kappa, and Society of Critical Care Medicine

Disclosure: Nothing to disclose.

H Biemann Othersen Jr, MD  Professor of Surgery and Pediatrics, Emeritus Head, Division of Pediatric Surgery, Medical University of South Carolina

H Biemann Othersen Jr, MD is a member of the following medical societies: Alpha Omega Alpha, American Academy of Pediatrics, American Association for the Surgery of Trauma, American Burn Association, American Cancer Society, American College of Surgeons, American Medical Association, American Pediatric Surgical Association, American Society for Parenteral and Enteral Nutrition, American Surgical Association, American Thoracic Society, British Association of Paediatric Surgeons, Society for Surgery of the Alimentary Tract, Society of Critical Care Medicine, South Carolina Medical Association, Southeastern Surgical Congress, Southern Medical Association, Southern Society for Pediatric Research, and Southern Thoracic Surgical Association

Disclosure: Nothing to disclose.

Chief Editor

Marleta Reynolds, MD  Professor of Surgery, Northwestern University, The Feinberg School of Medicine; Head, Department of Surgery and Surgeon in Chief, Head, Division of Pediatric Surgery, Children's Memorial Hospital of Chicago

Marleta Reynolds, MD is a member of the following medical societies: American Pediatric Surgical Association

Disclosure: Nothing to disclose.

References
  1. Langer JC, Hussain H, Khan A, et al. Prenatal diagnosis of esophageal atresia using sonography and magnetic resonance imaging. J Pediatr Surg. May 2001;36(5):804-7. [Medline].

  2. Choudhury SR, Ashcraft KW, Sharp RJ, et al. Survival of patients with esophageal atresia: influence of birth weight, cardiac anomaly, and late respiratory complications. J Pediatr Surg. Jan 1999;34(1):70-3; discussion 74. [Medline].

  3. Babu R, Pierro A, Spitz L, Drake DP, Kiely EM. The management of oesophageal atresia in neonates with right-sided aortic arch. J Pediatr Surg. Jan 2000;35(1):56-8. [Medline].

  4. Knottenbelt G, Costi D, Stephens P, Beringer R, Davidson A. An audit of anesthetic management and complications of tracheo-esophageal fistula and esophageal atresia repair. Paediatr Anaesth. Nov 21 2011;[Medline].

  5. Rothenberg SS. Thoracoscopic Repair of Esophageal Atresia and Tracheo-Esophageal Fistula in Neonates: Evolution of a Technique. J Laparoendosc Adv Surg Tech A. Nov 1 2011;[Medline].

  6. Al-Qahtani AR, Yazbeck S, Rosen NG, Youssef S, Mayer SK. Lengthening technique for long gap esophageal atresia and early anastomosis. J Pediatr Surg. May 2003;38(5):737-9. [Medline].

  7. Till H, Muensterer OJ, Rolle U, Foker J. Staged esophageal lengthening with internal and subsequent external traction sutures leads to primary repair of an ultralong gap esophageal atresia with upper pouch tracheoesophagel fistula. J Pediatr Surg. Jun 2008;43(6):E33-5. [Medline].

  8. Lorincz A, Langenburg SE, Knight CG, Gidell K, Rabah R, Klein MD. Robotically assisted esophago-esophagostomy in newborn pigs. J Pediatr Surg. Sep 2004;39(9):1386-9. [Medline].

  9. Agrawal L, Beardsmore CS, MacFadyen UM. Respiratory function in childhood following repair of oesophageal atresia and tracheoesophageal fistula. Arch Dis Child. Nov 1999;81(5):404-8. [Medline]. [Full Text].

  10. Bagolan P, Iacobelli Bd B, De Angelis P, et al. Long gap esophageal atresia and esophageal replacement: moving toward a separation?. J Pediatr Surg. Jul 2004;39(7):1084-90. [Medline].

  11. Bergmeijer JH, Tibboel D, Hazebroek FW. Nissen fundoplication in the management of gastroesophageal reflux occurring after repair of esophageal atresia. J Pediatr Surg. Apr 2000;35(4):573-6. [Medline].

  12. Bhaskar SK, Bin-Sagheer S, Brady PG. Congenital esophageal stenosis. Dig Dis. 2000;18(3):186. [Medline].

  13. Bremner CG, Lynch VP, Ellis FH Jr. Barrett's esophagus: congenital or acquired? An experimental study of esophageal mucosal regeneration in the dog. Surgery. Jul 1970;68(1):209-16. [Medline].

  14. Butterworth SA, Webber EM, Jamieson DH. H-type tracheoesophageal fistula. J Pediatr Surg. Jun 2001;36(6):958-9. [Medline].

  15. Canty TG Jr, Boyle EM Jr, Linden B, et al. Aortic arch anomalies associated with long gap esophageal atresia and tracheoesophageal fistula. J Pediatr Surg. Nov 1997;32(11):1587-91. [Medline].

  16. Chahine AA, Ricketts RR. Esophageal atresia in infants with very low birth weight. Semin Pediatr Surg. May 2000;9(2):73-8. [Medline].

  17. Chavin K, Field G, Chandler J, Tagge E, Othersen HB. Save the child's esophagus: management of major disruption after repair of esophageal atresia. J Pediatr Surg. Jan 1996;31(1):48-51; discussion 52. [Medline].

  18. Chen H, Goei GS, Hertzler JH. Family studies on congenital esophageal atresia with or without tracheoesophageal fistula. Birth Defects Orig Artic Ser. 1979;15(5C):117-44. [Medline].

  19. Chitwood WR Jr, Bost WS Jr, Pories WJ, Gowen MA, Saldahna RL. Laryngotracheoesophageal cleft: endoscopic diagnosis and surgical repair. Ann Thorac Surg. Aug 1989;48(2):292-4. [Medline].

  20. Clark DC. Esophageal atresia and tracheoesophageal fistula. Am Fam Physician. Feb 15 1999;59(4):910-6, 919-20. [Medline].

  21. Cozzi DA, Capocaccia P, Roggini M, et al. Respiratory status of infants with esophageal atresia. Pediatr Surg Int. Mar 2001;17(2-3):92-6. [Medline].

  22. Crisera CA, Grau JB, Maldonado TS, et al. Defective epithelial-mesenchymal interactions dictate the organogenesis of tracheoesophageal fistula. Pediatr Surg Int. 2000;16(4):256-61. [Medline].

  23. Deurloo JA, van Lanschot JJ, Drillenburg P, Aronson DC. Esophageal squamous cell carcinoma 38 years after primary repair of esophageal atresia. J Pediatr Surg. Apr 2001;36(4):629-30. [Medline].

  24. Dunn JC, Fonkalsrud EW, Applebaum H, et al. Reoperation after esophageal replacement in childhood. J Pediatr Surg. Nov 1999;34(11):1630-2. [Medline].

  25. Dutta HK, Mathur M, Bhatnagar V. A histopathological study of esophageal atresia and tracheoesophageal fistula. J Pediatr Surg. Mar 2000;35(3):438-41. [Medline].

  26. Engum SA, Grosfeld JL, West KW, Rescorla FJ, Scherer LR 3rd. Analysis of morbidity and mortality in 227 cases of esophageal atresia and/or tracheoesophageal fistula over two decades. Arch Surg. May 1995;130(5):502-8; discussion 508-9. [Medline].

  27. Erdogan E, Emir H, Eroglu E, Danismend N, Yeker D. Esophageal replacement using the colon: a 15-year review. Pediatr Surg Int. 2000;16(8):546-9. [Medline].

  28. Evans M. Application of Collis gastroplasty to the management of esophageal atresia. J Pediatr Surg. Aug 1995;30(8):1232-5. [Medline].

  29. Filston HC, Chitwood WR Jr, Schkolne B, Blackmon LR. The Fogarty balloon catheter as an aid to management of the infant with esophageal atresia and tracheoesophageal fistula complicated by severe RDS or pneumonia. J Pediatr Surg. Apr 1982;17(2):149-51. [Medline].

  30. Fitoz S, Atasoy C, Yagmurlu A, Akyar S, Erden A, Dindar H. Three-dimensional CT of congenital esophageal atresia and distal tracheoesophageal fistula in neonates: preliminary results. AJR Am J Roentgenol. Nov 2000;175(5):1403-7. [Medline].

  31. Foker JE, Kendall TC, Catton K, Khan KM. A flexible approach to achieve a true primary repair for all infants with esophageal atresia. Semin Pediatr Surg. Feb 2005;14(1):8-15. [Medline].

  32. Foker JE, Linden BC, Boyle EM, Marquardt C. Development of a true primary repair for the full spectrum of esophageal atresia. Ann Surg. Oct 1997;226(4):533-41; discussion 541-3. [Medline]. [Full Text].

  33. Garcia NM, Thompson JW, Shaul DB. Definitive localization of isolated tracheoesophageal fistula using bronchoscopy and esophagoscopy for guide wire placement. J Pediatr Surg. Nov 1998;33(11):1645-7. [Medline].

  34. Giacomoni MA, Tresoldi M, Zamana C, Giacomoni A. Circular myotomy of the distal esophageal stump for long gap esophageal atresia. J Pediatr Surg. Jun 2001;36(6):855-7. [Medline].

  35. Harries PG, Frost RA. Foreign body impaction arising in adulthood: a result of neonatal repair of tracheo-oesophageal fistula and oesophageal atresia. Ann R Coll Surg Engl. May 1996;78(3 (Pt 1):217-20. [Medline].

  36. Holcomb GW, Rothenberg SS, Bax KM, et al. Thoracoscopic repair of esophageal atresia and tracheoesophageal fistula: a multi-institutional analysis. Ann Surg. Sep 2005;242(3):422-8; discussion 428-30. [Medline]. [Full Text].

  37. Kallen K, Mastroiacovo P, Castilla EE, Robert E, Kallen B. VATER non-random association of congenital malformations: study based on data from four malformation registers. Am J Med Genet. Jun 1 2001;101(1):26-32. [Medline].

  38. Kawahara H, Imura K, Yagi M, Kubota A. Clinical characteristics of congenital esophageal stenosis distal to associated esophageal atresia. Surgery. Jan 2001;129(1):29-38. [Medline].

  39. Krug E, Bergmeijer JH, Dees J, de Krijger R, Mooi WJ, Hazebroek FW. Gastroesophageal reflux and Barrett's esophagus in adults born with esophageal atresia. Am J Gastroenterol. Oct 1999;94(10):2825-8. [Medline].

  40. Lessin MS, Wesselhoeft CW, Luks FI, DeLuca FG. Primary repair of long-gap esophageal atresia by mobilization of the distal esophagus. Eur J Pediatr Surg. Dec 1999;9(6):369-72. [Medline].

  41. Manning PB. Long-gap esophageal atresia. Semin Thorac Cardiovasc Surg. Oct 1994;6(4):216-20. [Medline].

  42. Mares AJ, Bar-Ziv J, Lieberman A, Tovi F. Congenital esophageal stenosis. Transendoscopic web incision. J Clin Gastroenterol. Oct 1986;8(5):555-8. [Medline].

  43. Messineo A, Filler RM. Tracheomalacia. Semin Pediatr Surg. Nov 1994;3(4):253-8. [Medline].

  44. Morabito A, MacKinnon E, Alizai N, Asero L, Bianchi A. The anterior mediastinal approach for management of tracheomalacia. J Pediatr Surg. Oct 2000;35(10):1456-8. [Medline].

  45. Moriarty KP, Jacir NN, Harris BH, et al. Transanastomotic feeding tubes in repair of esophageal atresia. J Pediatr Surg. Jan 1996;31(1):53-4; discussion 54-5. [Medline].

  46. Newman B, Bender TM. Esophageal atresia/tracheoesophageal fistula and associated congenital esophageal stenosis. Pediatr Radiol. Jun 1997;27(6):530-4. [Medline].

  47. Nobuhara KK, Gorski YC, La Quaglia MP, Shamberger RC. Bronchogenic cysts and esophageal duplications: common origins and treatment. J Pediatr Surg. Oct 1997;32(10):1408-13. [Medline].

  48. Ohbatake M, Muraji T, Yamazato M, et al. Congenital true diverticula of the esophagus: a case report. J Pediatr Surg. Nov 1997;32(11):1592-4. [Medline].

  49. Orford J, Manglick P, Cass DT, Tam PP. Mechanisms for the development of esophageal atresia. J Pediatr Surg. Jul 2001;36(7):985-94. [Medline].

  50. Othersen HB Jr, Hebra A, Tagge EP. Esophageal replacement for atresia without fistula. Semin Pediatr Surg. May 1998;7(2):134-6. [Medline].

  51. Otten C, Migliazza L, Xia H, Rodriguez JI, Diez-Pardo JA, Tovar JA. Neural crest-derived defects in experimental esophageal atresia. Pediatr Res. Feb 2000;47(2):178-83. [Medline].

  52. Pedersen JC, Klein RL, Andrews DA. Gastric tube as the primary procedure for pure esophageal atresia. J Pediatr Surg. Sep 1996;31(9):1233-5. [Medline].

  53. Pole RJ, Qi BQ, Beasley SW. Abnormalities of the tracheal cartilage in the rat fetus with tracheo-oesophageal fistula or tracheal agenesis. Pediatr Surg Int. 2001;17(1):25-8. [Medline].

  54. Puri P, Khurana S. Delayed primary esophageal anastomosis for pure esophageal atresia. Semin Pediatr Surg. May 1998;7(2):126-9. [Medline].

  55. Ramesh JC, Ramanujam TM, Jayaram G. Congenital esophageal stenosis: report of three cases, literature review, and a proposed classification. Pediatr Surg Int. Mar 2001;17(2-3):188-92. [Medline].

  56. Rothenberg SS. Thoracoscopic repair of tracheoesophageal fistula in newborns. J Pediatr Surg. Jun 2002;37(6):869-72. [Medline].

  57. Ruangtrakool R, Spitz L. Early complications of gastric transposition operation. J Med Assoc Thai. Apr 2000;83(4):352-7. [Medline].

  58. Schier F, Korn S, Michel E. Experiences of a parent support group with the long-term consequences of esophageal atresia. J Pediatr Surg. Apr 2001;36(4):605-10. [Medline].

  59. Sharma AK, Sharma KK, Sharma CS, et al. Congenital esophageal obstruction by intraluminal mucosal diaphragm. J Pediatr Surg. Feb 1991;26(2):213-5. [Medline].

  60. Sharma AK, Shekhawat NS, Agrawal LD, Chaturvedi V, Kothari SK, Goel D. Esophageal atresia and tracheoesophageal fistula: a review of 25 years' experience. Pediatr Surg Int. 2000;16(7):478-82. [Medline].

  61. Shoshany G, Bar-Maor JA. Congenital stenosis of the esophagus due to tracheobronchial remnants: a missed diagnosis. J Pediatr Gastroenterol Nutr. Nov-Dec 1986;5(6):977-9. [Medline].

  62. Snyder CL, Bickler SW, Gittes GK, et al. Esophageal duplication cyst with esophageal web and tracheoesophageal fistula. J Pediatr Surg. Jul 1996;31(7):968-9. [Medline].

  63. Spitz L. Esophageal atresia and tracheoesophageal fistula in children. Curr Opin Pediatr. Jun 1993;5(3):347-52. [Medline].

  64. Spitz L. Esophageal atresia: past, present, and future. J Pediatr Surg. Jan 1996;31(1):19-25. [Medline].

  65. Spitz L. Gastric transposition for esophageal substitution in children. J Pediatr Surg. Feb 1992;27(2):252-7; discussion 257-9. [Medline].

  66. Spitz L, Ruangtrakool R. Esophageal substitution. Semin Pediatr Surg. May 1998;7(2):130-3. [Medline].

  67. Stringer MD, McKenna KM, Goldstein RB, et al. Prenatal diagnosis of esophageal atresia. J Pediatr Surg. Sep 1995;30(9):1258-63. [Medline].

  68. Takamizawa S, Nishijima E, Tsugawa C, et al. Multistaged esophageal elongation technique for long gap esophageal atresia: experience with 7 cases at a single institution. J Pediatr Surg. May 2005;40(5):781-4. [Medline].

  69. Takamizawa S, Tsugawa C, Mouri N. Congenital esophageal stenosis: Therapeutic strategy based on etiology. J Pediatr Surg. Feb 2002;37(2):197-201. [Medline].

  70. Teich S, Barton DP, Ginn-Pease ME, King DR. Prognostic classification for esophageal atresia and tracheoesophageal fistula: Waterston versus Montreal. J Pediatr Surg. Jul 1997;32(7):1075-9; discussion 1079-80. [Medline].

  71. Templeton JM Jr, Templeton JJ, Schnaufer L, et al. Management of esophageal atresia and tracheoesophageal fistula in the neonate with severe respiratory distress syndrome. J Pediatr Surg. Aug 1985;20(4):394-7. [Medline].

  72. Ure BM, Slany E, Eypasch EP, et al. Quality of life more than 20 years after repair of esophageal atresia. J Pediatr Surg. Mar 1998;33(3):511-5. [Medline].

  73. Williams AK, Qi BQ, Beasley SW. Demonstration of abnormal notochord development by three-dimensional reconstructive imaging in the rat model of esophageal atresia. Pediatr Surg Int. 2001;17(1):21-4. [Medline].

  74. Williams J. Diagnosing tracheoesophageal fistula without esophageal atresia. Clin Pediatr (Phila). Feb 1996;35(2):103-4. [Medline].

  75. Wise WE Jr, Caniano DA, Harmel RP Jr. Tracheoesophageal anomalies in Waterston C neonates: a 30-year perspective. J Pediatr Surg. Jun 1987;22(6):526-9. [Medline].

  76. Zaccara A, Felici F, Turchetta A, et al. Physical fitness testing in children operated on for tracheoesophageal fistula. J Pediatr Surg. Sep 1995;30(9):1334-7. [Medline].

  77. Zach MS, Eber E. Adult outcome of congenital lower respiratory tract malformations. Thorax. Jan 2001;56(1):65-72. [Medline].

  78. Zhou B, Hutson JM, Farmer PJ, Hasthorpe S, Myers NA, Liu M. Apoptosis in tracheoesophageal embryogenesis in rat embryos with or without adriamycin treatment. J Pediatr Surg. May 1999;34(5):872-5; discussion 876. [Medline].

Previous
Next

Fetal MRI showing normal esophagus. This study is negative for esophageal atresia. The hypopharynx and proximal esophagus are normal caliber (arrows), and a normal thoracic esophagus (E) is observed.
Fetal MRI that reveals esophageal atresia. The proximal esophagus and hypopharynx are dilated (arrow). The thoracic esophagus is not discernible.
Plain radiograph in a newborn suspected of having esophageal atresia. Air in the stomach and intestine suggest a distal tracheoesophageal fistula.
Pure esophageal atresia. Newborn with tube in proximal pouch. Note that no air is in the stomach or intestine (a gasless abdomen).
Animation illustrating method to estimate distance for esophageal atresia (EA) with distal tracheoesophageal fistula (TEF). A small amount of air has been injected into the upper pouch. The upper pouch and bifurcation of the trachea are marked. The distal fistula is usually posterior to the carina.
Contrast study of the upper pouch in an infant with esophageal atresia and distal tracheoesophageal fistula.
Tracheobronchial remnant in distal esophagus of an infant with pure esophageal atresia.
Gapogram estimating distance between the proximal pouch (P) and the distal pouch (D). The proximal pouch has mercury-weighted dilator, and the distal pouch is filled with contrast injected through a gastrostomy (G). The distance is more than 5 cm and 5 vertebral bodies.
Gapogram demonstrating 3.4-cm gap. The distal pouch is being stretched with radiopaque dilator.
Gapogram demonstrating pure esophageal atresia before surgical repair. Green lines show gap distance less than 2 cm between mercury-weighted dilator in upper pouch and contrast in distal pouch.
Intraoperative photograph illustrating azygous vein. A right thoracotomy and retropleural dissection has been performed.
Intraoperative photograph during repair of esophageal atresia. The head is to the left. The azygous vein has been divided. The proximal (P) and distal (D) esophageal pouches can be easily observed.
Intraoperative photograph showing primary anastomosis (A) between the proximal and distal esophagus.
Contrast study demonstrating colonic interposition. The colon is sutured to the cervical esophagus proximally and the stomach distally. No leak or stricture is noted.
Contrast swallow (oblique view) demonstrating a gastric pull-up used as esophageal replacement in a child with pure esophageal atresia. Note stomach in chest.
Intraoperative photograph demonstrating proximal H-type fistula (F) between the proximal esophagus (P) and trachea (T). The blue vessel loop is around the fistula. The H-type fistula was not diagnosed preoperatively; it was identified while mobilizing the proximal esophagus in a child with congenital esophageal stenosis.
Intraoperative photograph following division and repair of H-type fistula. Note sutures in the esophagus (E) and trachea (T).
Intraoperative photograph of an infant thought to have esophageal atresia. The proximal (P) and distal esophagus was connected by a fibrotic segment of congenital esophageal stenosis (CES) beginning at the azygous vein (A). No distal tracheoesophageal fistula was present.
Intraoperative photograph following resection of an atretic segment of esophagus and primary anastomosis (A) of the proximal (P) and distal esophagus. The azygous vein (AV) was preserved.
Chest radiograph immediately following repair of esophageal atresia and distal tracheoesophageal fistula (TEF). Note the chest tube (CT) in the retropleural space and the feeding tube passing through the anastomosis (A) into the stomach.
Chest radiograph following repair of esophageal atresia. The chest tube is placed in the retropleural space (CT). No feeding tube is passing across the anastomosis.
Esophagogram one week following primary anastomosis for pure esophageal atresia. No leak or stricture is observed.
Anastomosis disruption following repair of esophageal atresia with a tracheoesophageal fistula. Contrast was injected through a gastrostomy and refluxed through the distal esophagus. The leak (L) is draining into the retropleural chest tube.
Esophagogram 1 week after repair of esophageal atresia with a distal tracheoesophageal fistula (TEF). Note narrowing at anastomosis (A). The child was asymptomatic and required no dilatations. Image 1 of 3 in series.
Follow-up esophagram demonstrating spontaneous improvement of narrowing at the anastomosis (A). Image 2 of 3 in series.
Esophagogram. Note spontaneous resolution of narrowing at the anastomosis (A). No intervention was required in this child. Image 3 of 3 in series.
Esophagogram 7 days following repair of esophageal atresia. Note the change in caliber from the proximal esophagus to the distal esophagus at the anastomosis (A). The retropleural chest tube can be observed (CT). This patient had gastroesophageal reflux and developed a progressive stricture. Image 1 of 3 in series.
Esophagogram obtained 3 weeks later demonstrating stricture (A) and gastroesophageal reflux (R and green arrow). Medical therapy was initiated. Image 2 of 3 in a series.
Esophagogram performed 2 weeks later demonstrating worsened anastomotic stricture (A). The patient responded well to Bouginage dilatation and medical management of the reflux. Image 3 of 3 in a series.
Esophagogram demonstrating impacted food in a 5-year-old child with a history of esophageal atresia repair.



All material on this website is protected by copyright, Copyright © 1994-2012 by WebMD LLC.
This website also contains material copyrighted by 3rd parties.

DISCLAIMER: The content of this Website is not influenced by sponsors. The site is designed primarily for use by qualified physicians and other medical professionals. The information contained herein should NOT be used as a substitute for the advice of an appropriately qualified and licensed physician or other health care provider. The information provided here is for educational and informational purposes only. In no way should it be considered as offering medical advice. Please check with a physician if you suspect you are ill.
