Nasal Implants Treatment & Management

Updated: Oct 26, 2018
  • Author: Garrett A Wirth, MD, MS, FACS; Chief Editor: Deepak Narayan, MD, FRCS  more...
  • Print
Treatment

Surgical Therapy

Several factors must be considered to reach an acceptable outcome in nasal reconstruction. Consider a careful analysis of each patient's individual nasal condition as well as combinations of materials, their relative roles, and required techniques. The fundamental physician-patient relationship must be based on understanding of the overall goal and specific objectives to achieve physician and, more importantly, patient satisfaction. In addition, the limitations of the procedures must be understood clearly.

Materials currently in use are discussed below.

Cartilage

Autogenous cartilage grafts are the most frequently used material for nasal augmentation [4] and are considered the preferred material by many authors. The various reasons for its success and preferred status include ease of use, availability, and biocompatibility. Maas et al stated that cartilage is firm yet flexible and can be carved easily to fit the desired nasal contour. [5] It also provides good structural support while maintaining the consistency of the normal nasal cartilaginous skeleton.

McCarthy and Ortiz-Monasterio et al emphasize that autogenous cartilage grafts have decreased resorption rates and low infection rates. [6, 7] Resorption rates of septal cartilage grafts are estimated at 12-50%. Absorption of autogenous cartilage follows a typical pattern. Absorption begins early, is of short duration, and appears to subside after the initial postoperative period.

Generally, accepted donor sites available for implantation are the nasal septum, auricular conchal cartilage, and rib. Cartilage from these donor sites varies in texture, rigidity, and contour. Use of cartilage from each site is chosen based on need. Clearly, the availability of septal cartilage may be influenced by the underlying cause of the deformity (eg, trauma). Septal cartilage generally does not warp easily and has the advantage of tolerating careful manipulations such as gentle crushing to alter thickness and/or contours.

Unfortunately, cartilage grafts that have been crushed to facilitate contouring tend to undergo significantly higher rates of resorption. However, the compliant nature of septal cartilage that lends itself to providing structural support without the rigid appearance of bone makes it a nearly ideal nasal augmentation material.

If only a small amount of cartilage is required, or when a gentle curvature facilitates reconstruction, the conchal auricular cartilage can be harvested from either the anterior or posterior approach.

Calvarial bone graft and auricular conchal cartila Calvarial bone graft and auricular conchal cartilage. Harvest of auricular conchal cartilage graft from anterior approach. A 61-year-old man required a subtotal nasal reconstruction of a septal squamous cell carcinoma and left cervical radical lymphadenectomy. Reconstruction began with a forehead flap of tissue expanded skin.

The posterior approach generally offers easier access to larger amounts of cartilage without significant scars. The contour of auricular cartilage makes it ideal for internal nasal valve grafts and replacement of the lower lateral cartilages. Its softness makes it less noticeable when used as an onlay graft. Costal cartilage is available in the largest quantity, but conversely offers much greater donor site morbidity. Of the autogenous cartilages available, costal cartilage is the most likely to deform when carved to thin dimensions.

Recently, an increase has occurred in the use of diced autologous cartilage grafts wrapped either in Surgicel, which is manufactured by Johnson & Johnson, [8, 9] or in deep temporal fascia. [10] Controversy exists as to which technique allows better maintenance of the graft, contour correction, and cartilage viability. [11, 12] Survivability of diced cartilage grafts was addressed by Brenner et al. [13] Diced cartilage and bone chips, as well as cartilage allografts, have also been used and are addressed below.

Collagen gel matrix

Britt and Park stated that tissue-engineered cartilage can be produced reliably and that predetermination of graft shape is possible. [14] They further concluded that histologically, allografted rib cartilage represents composites of mature cartilage infiltrated by vasculature and fibrous tissue with delayed osteoid formation. Of note, the tensile strength of the allografted rib cartilage is less than that of native cartilage. However, this histologic finding suggests that tissue-engineered cartilage is a feasible option for a future graft material.

Further evidence that tissue-engineered cartilage is a future material for nasal reconstruction was presented by Lindsey et al using a rat model and an osteoconductive collagen gel matrix. They demonstrated histologically that native, isotonic, neutral pH, space-filling collagen gel implants revealed restoration of the anatomy with a thin plate of immature bone spanning the defect in continuity with the cartilage of the nasal septum and with apparent preservation of maxillonasal suture lines.

The feasibility of using collagen gel for nasal augmentation primarily is due to its ready availability and ability to be molded. The material can be (1) brought to the operative field as a liquid and poured into defects, forming a gelatin at warmer temperatures within the defect; (2) molded at the operating table and then placed into the defect; or (3) arrive preshaped.

Finally, rodent models also are used to study fibrin sealants augmented with osteoprogenitor cells for repair of osseous facial critical size defects. Clearly, these materials merit further investigation and evaluation as their final role in reconstructive surgery of the nose has not been elucidated fully.

Bone

Bone, like cartilage, can be used for augmentation and as a supportive structural framework for nasal tip and internal nasal valve support. Generally considered a second choice after autogenous cartilage, autogenous bone grafts offer advantages of stability, availability, accessibility, and low infection rates in nasal reconstructions. Bone grafts have gained attention in the past few years as alternative grafting material, particularly for reconstruction of total nasal defects and the collapsed nose when structural support is needed. Sites available for bone graft donation include split calvarial grafts (cortical bone), iliac crest (cancellous, cortical), and rib.

Romo and Jablonski stated that the determination to use calvarial grafts was made on the basis of the lack of available auricular and nasal cartilage or the lack of patient consent to use autogenous auricular cartilage. [15] Split calvarial bone grafts can provide a large source of material for grafting, having further advantages of excellent structural support and a high level of tolerance (see below). Another advantage is that calvarial bone graft is harvested from a donor site in the same operative field as in the nasal operation. Conversely, the stiffness of bone can make it difficult to shape and more susceptible to fracture, increased morbidity is associated with the donor site (eg, significantly more pain), and a less natural appearance may result.

Calvarial bone graft and auricular conchal cartila Calvarial bone graft and auricular conchal cartilage. A 61-year-old man required a subtotal nasal reconstruction of a septal squamous cell carcinoma and left cervical radical lymphadenectomy. Reconstruction began with a forehead flap of tissue expanded skin. Right lateral view.
Calvarial bone graft and auricular conchal cartila Calvarial bone graft and auricular conchal cartilage. A 61-year-old man required a subtotal nasal reconstruction of a septal squamous cell carcinoma and left cervical radical lymphadenectomy. Reconstruction began with a forehead flap of tissue expanded skin. Calvarial bone graft harvest site.
Calvarial bone graft and auricular conchal cartila Calvarial bone graft and auricular conchal cartilage. A 61-year-old man required a subtotal nasal reconstruction of a septal squamous cell carcinoma and left cervical radical lymphadenectomy. Reconstruction began with a forehead flap of tissue expanded skin. Sculpted calvarial bone graft.
Calvarial bone graft and auricular conchal cartila Calvarial bone graft and auricular conchal cartilage. A 61-year-old man required a subtotal nasal reconstruction of a septal squamous cell carcinoma and left cervical radical lymphadenectomy. Reconstruction began with a forehead flap of tissue expanded skin. Calvarial bone graft in place and anchored to glabellar area of frontal bone.
Calvarial bone graft and auricular conchal cartila Calvarial bone graft and auricular conchal cartilage. Harvest of auricular conchal cartilage graft from anterior approach. A 61-year-old man required a subtotal nasal reconstruction of a septal squamous cell carcinoma and left cervical radical lymphadenectomy. Reconstruction began with a forehead flap of tissue expanded skin.
Calvarial bone graft and auricular conchal cartila Calvarial bone graft and auricular conchal cartilage. A 61-year-old man required a subtotal nasal reconstruction of a septal squamous cell carcinoma and left cervical radical lymphadenectomy. Reconstruction began with a forehead flap of tissue expanded skin. Sculpted conchal cartilage graft on nasal tip.
Calvarial bone graft and auricular conchal cartila Calvarial bone graft and auricular conchal cartilage. Postoperative frontal view at 1 year. A 61-year-old man required a subtotal nasal reconstruction of a septal squamous cell carcinoma and left cervical radical lymphadenectomy. Reconstruction began with a forehead flap of tissue expanded skin.

During the past few decades, calvarial bone grafts have become increasingly popular because of their widespread use in cranial vault reconstruction. This is in contrast to using either rib or iliac crest bone for nasal reconstructions. Carter first introduced the use of rib as a donor site in 1911. [16] The donor site usually can be hidden within the inframammary fold at approximately the fifth rib or in a more inferior and lateral position using the ninth rib (see the series of images below). As a substitute, Macomber first reported in 1949 the use of iliac bone for the correction of depressed deformities of the nose. [17] Both the iliac and rib sites carry considerable donor site morbidities, not the least of which is the patient's discomfort level.

Rib cartilage graft and Proplast bridge graft. A 4 Rib cartilage graft and Proplast bridge graft. A 46-year-old woman with a congenital deficiency of the nasal bridge underwent a series of reconstruction attempts using septal and conchal cartilage grafts. Front view.
Rib cartilage graft and Proplast bridge graft. A 4 Rib cartilage graft and Proplast bridge graft. A 46-year-old woman with a congenital deficiency of the nasal bridge underwent a series of reconstruction attempts using septal and conchal cartilage grafts. Right side view.
Rib cartilage graft and Proplast bridge graft. A 4 Rib cartilage graft and Proplast bridge graft. A 46-year-old woman with a congenital deficiency of the nasal bridge underwent a series of reconstruction attempts using septal and conchal cartilage grafts. Harvesting of the rib graft.
Rib cartilage graft and Proplast bridge graft. A 4 Rib cartilage graft and Proplast bridge graft. A 46-year-old woman with a congenital deficiency of the nasal bridge underwent a series of reconstruction attempts using septal and conchal cartilage grafts. Postoperative right side view.
Rib cartilage graft and Proplast bridge graft. A 4 Rib cartilage graft and Proplast bridge graft. A 46-year-old woman with a congenital deficiency of the nasal bridge underwent a series of reconstruction attempts using septal and conchal cartilage grafts. Removal of deformed rib cartilage 6 years after reconstruction.
Rib cartilage graft and Proplast bridge graft. A 4 Rib cartilage graft and Proplast bridge graft. A 46-year-old woman with a congenital deficiency of the nasal bridge underwent a series of reconstruction attempts using septal and conchal cartilage grafts. Tailored carved Proplast bridge graft to replace deformed rib cartilage.
Rib cartilage graft and Proplast bridge graft. A 4 Rib cartilage graft and Proplast bridge graft. A 46-year-old woman with a congenital deficiency of the nasal bridge underwent a series of reconstruction attempts using septal and conchal cartilage grafts. Postoperative right side view 4 years after Proplast bridge graft.
Silastic graft and rib bone graft. Preoperative fr Silastic graft and rib bone graft. Preoperative frontal view. A 37-year-old woman presented 10 years following reconstruction of an unreduced naso-orbitoethmoid fracture with silastic H-shaped graft.
Silastic graft and rib bone graft. Preoperative ob Silastic graft and rib bone graft. Preoperative oblique view demonstrating the distortion of the silastic graft secondary to scar tissue. A 37-year-old woman presented 10 years following reconstruction of an unreduced naso-orbitoethmoid fracture with silastic H-shaped graft.
Silastic graft and rib bone graft. Harvest of the Silastic graft and rib bone graft. Harvest of the rib bone graft. A 37-year-old woman presented 10 years following reconstruction of an unreduced naso-orbitoethmoid fracture with silastic H-shaped graft.
Silastic graft and rib bone graft. A 37-year-old w Silastic graft and rib bone graft. A 37-year-old woman presented 10 years following reconstruction of an unreduced naso-orbitoethmoid fracture with silastic H-shaped graft. Fabrication of the osseous H-shaped graft. Removed silastic graft serves as a pattern.
Silastic graft and rib bone graft. A 37-year-old w Silastic graft and rib bone graft. A 37-year-old woman presented 10 years following reconstruction of an unreduced naso-orbito-ethmoid fracture with silastic H-shaped graft. Postoperative frontal view at 10.5 years postreconstruction.
Silastic graft and rib bone graft. A 37-year-old w Silastic graft and rib bone graft. A 37-year-old woman presented 10 years following reconstruction of an unreduced naso-orbitoethmoid fracture with silastic H-shaped graft. Postoperative side view at 10.5 years postreconstruction.

The risk of morbidity associated with bone grafts applies to the split calvarial graft as well as iliac crest or rib graft. Split calvarial grafts also carry a slight risk of cerebral injury. This is a rare but significant complication and should be weighed in the decision to harvest from this site. Zins and Whitaker noted that animal model studies suggest that membranous bone, such as a cranial bone graft, is resorbed less compared to endochondral bone. [18] Powell et al noted that the resorption rates of calvarial bone grafts are estimated at 20-30%. [19] Rates of resorption vary for reasons that remain a mystery although it appears that arguments about the merits of fixation of grafts versus onlay alone merit continued investigation.

Several authors reiterate that bone is more difficult to shape to the recipient site. Romo and Jablonski stated, "We believe that autogenous cartilage is still the ideal replacement material for structural defects of the nose; however, in cases in which cartilage is not available, split calvarial bone grafts are an excellent substitute." [15] In 2004, Celik et al published results using bone chips and diced cartilage for treatment of the nasal dorsum. [20, 21] Results showed satisfactory and durable results correcting deficiencies on the bony part, cartilage part, or both parts.

Temporalis fascia graft

Nasal reconstruction may include the use of temporalis fascial grafts. The fascia generally has been used to augment or complete the contouring of the nose, as it may be used over bone or for filling the soft tissue lower and lateral aspects of the nose (see the images below). Temporalis fascial grafts also may be used in the reconstruction of the nasal septum during a large reconstruction or for an individual with a septal perforation. Guerrerosantos noted that temporalis fascial grafts are used to cover the osteocartilaginous framework (including cartilage or bone grafts), aiming to prevent possible irregularities or sharp edges. [9]

Fascial grafts. A 55-year-old woman sought improve Fascial grafts. A 55-year-old woman sought improvement of radix and upper nasal bridge following an aesthetic rhinoplasty. Preoperative side view. Note the shallow glabella.
Fascial grafts. A 55-year-old woman sought improve Fascial grafts. A 55-year-old woman sought improvement of radix and upper nasal bridge following an aesthetic rhinoplasty. Temporal fascial graft prior to placement.
Fascial grafts. A 55-year-old woman sought improve Fascial grafts. A 55-year-old woman sought improvement of radix and upper nasal bridge following an aesthetic rhinoplasty. Right temporal donor site closure.
Fascial grafts. A 55-year-old woman sought improve Fascial grafts. A 55-year-old woman sought improvement of radix and upper nasal bridge following an aesthetic rhinoplasty. Postoperative side view at 3 months.

Miller noted that these grafts can be used as the sole source of contour augmentation of facial depressions in primary as well as secondary rhinoplasty. [22] Such grafts undergo an initial uniform shrinkage (approximately 20%) during the first 4-6 weeks postoperatively because of compaction and condensation of the fibrous tissue of the fascia; after this shrinkage, the grafts stabilize and become firm. Guerrerosantos stated that the most common complications relating to augmentation rhinoplasty with fascia and cartilage grafts are erythema and resorption of the fascia. [9]

Homografts/Allografts

Homografts, or allografts, refer to those materials that are procured from a similar species (but different patient) for donation and use in reconstruction for the recipient patient. The benefits of homografts include the availability of significant quantities of tissues and the ability to obtain tissue that still contains the property of matrix invasion and adjacent connective tissue replacement without donor site morbidity. The risk of infection associated with these products can present greater problems than for autogenous material. In an effort to minimize the risk of infection, irradiated tissue has been used. Kridel and Konior, as well as Welling et al, have suggested that irradiated cartilage in the nasal dorsum, being relatively immobile, does not demonstrate as much evidence of resorption as in other facial regions. [23, 24]

Irradiated cartilage is shaped and carved easily and can be used in areas where tissue strength is important for structural support, such as in improving nasal valve collapse or improvement of nasal tip projection. In principle, the homograft's pathogens and viruses are destroyed using gamma wave radiation. The graft is stored in a sterile saline solution and then reconstituted in an antibiotic solution prior to implantation. Any questionable material can be further debrided at the time of surgery.

Welling et al concluded that irradiated homologous cartilage grafts in humans are resorbed progressively, complete resorption may be expected, the amount of time necessary for complete resorption varies with each graft but eventual resorption appears inevitable, and fibrous scar tissue provides bulk that may result in a satisfactory aesthetic result. [24] However, irradiated homologous cartilage grafts cannot be recommended for long-term structural support. A contrary opinion has been expressed by Demirkan et al; they proposed that irradiated homologous costal cartilage is a versatile grafting material for rhinoplasty. [25] These authors utilized irradiated costal cartilage for various nasal defects. Results demonstrated no significant resorption, and they concluded that irradiated costal cartilage is a safe and reliable source of cartilage graft for both primary and secondary septorhinoplasties when autogenous septal cartilage is either insufficient or unsuitable. [25]

Burke et al reported that the longevity of irradiated homologous rib cartilage grafts has been favorable for functional, structural, and cosmetic nasal reconstruction, with low levels of resorption identified clinically. [26] Strauch and Wallach stated that "use of irradiated homograft costal cartilage for functional, traumatic, and aesthetic reconstruction of the nose is recommended." [27] They summarized that this cartilage is recommended for correction of contour defects and structural support, has yielded a low rate of complications, and has the added advantages of absence of donor-site morbidity and shorter surgical time required in the absence of surgical harvesting. [27]

AlloDerm (manufactured by LifeCell Corporation, Palo Alto, Calif) is an acellular allograft dermal matrix. In recent years, some interest has focused on the development of a nonimmunogenic, extracellular tissue matrix for permanent transplantation.

Originally popularized for use in full-thickness burns, the material may be used successfully for lip repairs, nasal reconstructions, and repair of septal perforations. This material is prepared from fresh human cadaveric skin. The processing technique of this material results in an acellular dermal matrix with normal collagen bundling and organization with intact basement membrane. [28, 29] The full spectrum of uses and long-term studies has yet to be evaluated, but this material has been available to the plastic and reconstructive surgeon. The use of AlloDerm has been reported in nasal procedures. For example, Ayshford et al reported its successful use with endoscopic repair of nasal septal perforations while also utilizing an inferior turbinate flap. [30] Multiple authors have also used this material for the correction of nasal contour deformities and in secondary rhinoplasty. [31, 32, 33]

Originally, the use of AlloDerm was reported as "encouraging," with long-term "good results, though partial graft resorption occurred in some patients." [31] The use of AlloDerm in secondary rhinoplasty showed that absorption did not seem to relate to the number of layers used and that the material did not appear to shift but still showed the persistent disadvantage of partial, but not complete, resorption. [32] Porcine dermal collagen (Permacol, Tissue Science Laboratories, Aldershot, UK) has also been reported for coverage of osseocartilaginous irregularities in secondary nasal surgery. [34] Its limited use still warrants further investigation.

Prosthetic implants

Porous implants have a greater risk of immediate infection, as increased surface area is present for adherence of bacterial polysaccharide cell surface components. However, porous implants have fewer late-stage infections, as the incorporation of host tissue into implant pores allows access to the site for immune response mediators. Thus, surgeons must account for the chemical and biologic nature of implant materials and the tissue characteristics of the implantation site while paying meticulous attention to sterile implantation technique.

Mersilene: Meshed polymers have the advantage of inciting prolific fibrous ingrowth, but this stability comes at the price of extreme difficulty in removing these implants should they become infected. Polyethylene terephthalate (Mersilene) did not gain widespread acceptance among plastic and reconstructive surgeons as a nasal implant material. Colton and others have continued to support the use of Mersilene based on properties such as relative ease of use, ability to tolerate folding, ability to be sutured in place, and relative early stability. [35] Infection rates as high as 4% have been noted, necessitating removal in 2% of patients. As a polyester mesh, Mersilene does not undergo hydrolytic degradation when implanted.

Proplast: A porous polymer known as Proplast formerly was used in temporomandibular joint reconstructions but was noted to shred under vigorous mechanical forces. The resultant particulate matter caused a response that resulted in intense inflammation and scarring, precipitating removal of its marketing clearance by the Food and Drug Administration. However, in nasal reconstruction, its ability to be "carved" into the desired shape made it popular (see below).

Proplast nasal grafts. A 20-year-old man with a po Proplast nasal grafts. A 20-year-old man with a posttraumatic nasal deformity with septal collapse. Preoperative side view.
Proplast nasal grafts. A 20-year-old man with a po Proplast nasal grafts. A 20-year-old man with a posttraumatic nasal deformity with septal collapse. Carved Proplast graft prior to insertion.
Proplast nasal grafts. A 20-year-old man with a po Proplast nasal grafts. A 20-year-old man with a posttraumatic nasal deformity with septal collapse. Postoperative side view.
Proplast nasal grafts. A 20-year-old man with a po Proplast nasal grafts. A 20-year-old man with a posttraumatic nasal deformity with septal collapse. Carved Proplast graft to place on alveolar ridge to augment the columellar base.
Proplast nasal grafts. A 20-year-old man with a po Proplast nasal grafts. A 20-year-old man with a posttraumatic nasal deformity with septal collapse. Proplast alveolar graft in place.

Medpor: Medpor is another porous polymer. The material traditionally was molded while hot, as it was not sculpted easily once it began to harden. Once this product sets, it is noted to become very hard; as a nasal implant, it may appear unnatural. Medpor is available as a contoured implant or as a sheet. Current Medpor implants can be molded and sculpted more readily. Sclafani et al concluded that because of differences in pore size, Medpor promotes faster fibrovascular ingrowth, and the presence of vascularized host tissue in and around the implant lends stability and resistance to experimentally induced infection. [36] They suggested that conservative treatment of clinical implant infections should be considered if bacterial seeding occurs after substantial fibrovascular ingrowth is present.

Niechajev supported the use of Medpor for secondary rhinoplasties and confirmed histologically the rapid vascularization and both soft tissue ingrowth and collagen deposition with the use of the porous polyethylene implant. [37, 38] Romo et al have reported multiple uses of Medpor as a nasal implant. [39, 40, 41] In cleft lip rhinoplasty (nasal reconstruction), the authors reported that the implant was well tolerated and achieved excellent long-term aesthetic results through fibrovascular ingrowth to the surrounding tissue. [39, 40] Romo also reported safe utilization of polyethylene alloimplants in multiple locations as a nasal implant. For a study of high-density porous polyethylene implants in the Indian population, see Deshpande et al. [42]

Gore-Tex: Gore-Tex (expanded polytetrafluoroethylene [ePTFE]) can be included within the polymer category. The porous nature of the material permits cellular attachment and tissue infiltration with minimal capsule formation. Its ability to be used within the body is well accepted, primarily based on its long-standing history of use in vascular surgery. That said, it has a relatively short history of use for nasal surgery. Long-term studies have not established its true infection rate, extrusion rate, or morbidity at this time, but early information suggests an extrusion rate of approximately 1%.

Ham et al reviewed the literature on ePTFE implants in rhinoplasty and noted that 20 out of 769 procedures produced inflammation or infection that required removal at a rate of 2.6%. [43] Jin et al concluded that Gore-Tex should be used judiciously in rhinoplasty because of a 2.1% infection rate, a risk that is higher still after secondary surgery; moreover, once infected, Gore-Tex implants usually require removal. [44] Maas et al concluded the ePTFE soft-tissue patch appears to be safe and reliable material for augmentation, demonstrating high biocompatibility, low tissue reactivity, and increasing stability over time. [45] Inanli et al recently confirmed Gore-Tex as a good alternative to autogenous tissue but did state that septal cartilage still is the most appropriate graft material used in rhinoplasty and that studies of large numbers of patients with longer follow-up periods are still required for Gore-Tex. [46, 47]

Godin et al concluded that Gore-Tex is a safe and effective implant material to use in primary and revision rhinoplasty when augmentation is needed and autogenous material is not available or desirable. [48] Ham concurs with this by stating that "although the infection rates of Gore-Tex are much higher than the rate of 0.1% for autogenous grafts, Gore-Tex may have a role in carefully selected patients. Only with time will the long-term results be revealed." [43]

Silicone

Silicone in various states of viscosity was a popular alloplast and may, in fact, have been the most commonly used solid alloplastic nasal implant over the past several decades. [49] The body is unable to infiltrate the material and tends to establish a fibrous tissue capsule around the implant. This encapsulation could prove to be disadvantageous. Without tissue infiltration, the implant tended to remain slightly mobile and was noted to have a significant extrusion rate. On a positive note, since no tissue ingrowth occurs, silicone implants may be removed easily if necessary. Silicone also has been used as a columellar strut implant, generally using medium grade silicone rubber. The placement of a silicone columellar strut serves to correct columellar retrusion, improve the nasolabial angle, and increase tip projection by elevating the medial crura of the lower lateral cartilages.

The advantages of the silicone columellar strut are as follows:

  • Low extrusion rate when properly implanted

  • Ability to sculpt and implant the prosthesis to assess the immediate effect of size and shape intraoperatively

  • Use of a harder grade of silicone rubber to permit the insertion of relatively small implants

  • Lack of resorption and elimination of a second procedure to obtain a graft

  • Ability to increase tip projection without disruption of the tip cartilages

  • Easy removal, causing minimal disruption of surrounding tissues

Potential disadvantages include extrusion, infection, migration, and asymmetry. Improved outcomes have been reported with a subperiosteal placement of the silicone, but this operation is more difficult to perform and requires special instruments. [50] Extrusion risks remain for the lifetime of the implant, with rates ranging from 0.5% to 10% for dorsal implants and rates up to 50% for the columellar implants. [51] Solid silicone implants have not survived as popular implants but remain a viable option within the reconstructive surgeon's armamentarium.

Metals and alloys

Metals and alloys such as titanium and vitallium can play an interesting role as nasal implants. These materials have a unique ability to facilitate osteointegration or direct bone adhesion and ingrowth in perforated implants. They are rigid and have limited value in standard nasal reconstruction but may be an excellent alternative to calvarial bone grafts in total nasal reconstruction. A combination of alloplastic materials such as vitallium or titanium and autogenous tissues may be considered in selected patients. Bikhazi et al describe using vitallium or titanium mesh for the dorsal framework formation, a tissue-expanded paramedian forehead flap for soft tissue coverage, and composite chondrocutaneous auricular grafts for tip reconstruction as an example of a combination reconstruction. [52]

Hydroxyapatite, ceramic, and nonceramic implants, and calcium phosphate cement

Other options for nasal implants include surface-active ceramics such as solid hydroxyapatite, bioglass, and nonceramic hydroxyapatite. Nonceramic hydroxyapatite has the advantage of resorption and subsequent replacement by bone. A paste form of hydroxyapatite can be mixed in the operating theater as a combination of tetracalcium phosphate and dicalcium phosphate anhydrous in a water solute. As the material sets it can be molded; it sets rapidly and within hours converts to hydroxyapatite. Okada et al have reported on the use of calcium phosphate cement for nasal augmentation. [53] This material is injected as a paste after elevating the periosteum to create a cavity. The authors reported that this material seems to be suitable for minor augmentation rhinoplasty in the Asian patient, but that its long-term safety and reliability require proof with longer follow-up periods. [53]

Next:

Complications

Complications are discussed individually within each material section above. Depending on the material used, complications range from infection to extravasation. This may necessitate antibiotic therapy, surgical revision, removal of the implant, or a combination of these therapeutic modalities.

Previous
Next:

Outcome and Prognosis

Optimal results include a combination of form and function. The final result may be achieved with a single surgery or may require staged procedures, combinations of implants, surgical revision, or a combination thereof. The choice of nasal implants to be placed in reconstructive surgery of the nose is a difficult but important component in the patient's care. The degree of loss of tip support, bridge contour, or nasal valve collapse may mandate nasal implant reconstruction.

Various materials each have their benefits and pitfalls, which must be balanced against the surgeon's familiarity with each material. Implantation of alloplasts in the nose is controversial; some authors believe the risk of complication, albeit low, does not justify their use.

Because of the nose's central location, minor defects of reconstruction may be particularly noticeable to any casual observer but may play a much larger psychological role in the patient's perception of self. Based on the authors' review of the literature and clinical experience, autogenous cartilage and/or bone are recommended as the primary choices for nasal implants.
